Stationary exhaust system

NESTRO

Condition: used, Year of construction: 2018, functionality: fully functional, overall weight: 250 kg, Grinding table, model NESTRO, with 2 suction cups, year of manufacture 2018, in new condition. Kodpexltrujfx Anwjdn

Condition: used, Year of construction: 2016, input voltage: 400 V, input current: 32 A, input frequency: 50 Hz, type of input current: three-phase, volume flow: 6,927 m³/h, suction capacity: 9,500 m³/h, intake manifold diameter: 350 mm, filter area: 42 m², noise level: 74 dB, total height: 2,420 mm, total length: 5,000 mm, total width: 1,250 mm, overall weight: 1,500 kg, Dust extraction system, wood chip extraction system, NESTRO NE 350 P self-cleaning negative pressure filter. Automatic filter cleaning with a pneumatic actuator. The fan is located on the clean air side, minimizing the risk of explosion. The unit is suitable for wide-belt sanding machines and all types of dry dust generated during various manufacturing processes. Fan power: 11 kW. Capacity: up to 9500 m3/h. Rated capacity: 6927 m3/h. Negative pressure: 2400 Pa. Nozzle diameter: 350 mm. Filtration area: 42 m2. Year of manufacture: 2016. Dimensions: Length: 5.00 m Depth: 1.25 m Height: 2.42 m Weight: 1500 kg Stock number: 1143 Ksdpfx Ajzdddysnwodn

Condition: not inspected (used), Year of construction: 1999, Dimensions (L/W/H) 3500 x 3500 x 6000 mm Filter capacity 216 m² Number of filters 121 (11x11) St. From the closure of the window construction company ----- Nestro filter system with various fans Automatic shaking-extinguishing line including Heizomat feed for wood chips with transport to the silo Kedpey Hl Itefx Anwsdn ----- Info: Outside: Intermediate filter, Heizomat, fans and pipes must be dismantled by yourself. Switch cabinets (fans, control, Heizomat feed) already disconnected by electrician and ready for shipping. Dimensions approx.: ----- Filter system: upper part: length 3.4 m x depth 3.4 m x height 3.0 m lower part: length 3.0 m x depth 3.0 m x height 1.9 m adjustable feet: height approx. 0.9 m filter hose length probably 2,500 mm filter area probably 216 m2 heating system feed length 3.8 m x depth 1.4 m (technical information according to manufacturer - no guarantee!

Year of construction: 2012, condition: good (used), functionality: fully functional, Rotary Airlock Valve / Rotary Valve Nestro, year of manufacture 2012, for the separation / differentiation of paper chips or paper edge strips Technical data: Manufacturer: Nestro Lufttechnik GmbH Year of manufacture: approx. 2012 Motor: 4 kW Max. volumetric flow: 28,000 m³/h Max. inlet diameter: 450 mm Speed: 22 rpm Rotor width: 1,500 mm Rotor diameter: 1,200 mm Dimensions: 2,200 x 2,200 x 2,500 mm (LxWxH) Weight: approx. 3,000 kg Remarks: The machine is in good condition. It has been inspected and tested at our facility in 28816 Stuhr. You can find the video above on our website or on our YouTube channel. Kdsdpey Tiagjfx Anwen Inspections, including under power, are possible at any time by prior arrangement. We are happy to answer your questions about the machine by phone, Monday to Thursday from 08:00 to 14:00. On Fridays, we are available from 08:00 to 13:00. Please note: All technical data is based on information provided by the manufacturer. We do not accept liability for the stated information or possible errors. Offers are non-binding, subject to prior sale, and may be withdrawn at any time. Inspections are possible by arrangement. Sale is ex-works, advance payment required, without warranty or guarantee.

Condition: new, Year of construction: 2024, New dust extractor Year of manufacture: 2024 Technical specifications: Certified according to BGHM H3* / CE / GS Power consumption: 2.2 kW Current draw IE2: 4.4 A Filter area: 9.5 m² Dimensions: 1575 x 910 x 2110 mm Dust bin volume: 1 x 160 l Weight: 405 kg Kdsdpsy R E Uuofx Anwsn Suction nozzle: 160 mm, right Operating air volume: 2300 m³/h Volumetric flow max/nom.: 1780/1447 Vacuum at nominal air flow: 2450 Pa Vacuum before fan at VNenn: 3160 Pa Maximum sound pressure level: 74 dB(A) Filter regeneration: pneumatic, max. 7.5 bar Operating mode: continuous operation Compressed air connection required Availability: short notice Location: Hochheim

Condition: used, Year of construction: 1997, Suction nozzle diameter: 200 mm Maximum volumetric flow rate: 3,200 m³/h Nominal volumetric flow rate: 2,862 m³/h Volumetric flow monitoring: Differential pressure display Negative pressure: 2,336 Pa Filter surface area: 16.8 m² Kedpfx Anex Edmvewedn Residual dust content: less than 0.2 mg/m³ Sound pressure level: dB Chip bag volume: l Filter cleaning: Pneumatic Motor power: 4 kW Machine length: 2,300 mm Machine width: 900 mm Machine height: 2,200 mm Weight: 350 kg

Condition: ready for operation (used), Year of construction: 2022, functionality: fully functional, filter area: 160 m², Equipment: documentation/manual, NESTRO Extraction System Year 2022 – Modern Industrial Installation – Top Condition NESTRO Extraction Jet NFHSU 11125, 160 m² filter area, incl. 2x electric diverter valves, excl. spark extinguishing system, year 2022 Description For sale is a high-quality, modern extraction system from NESTRO Lufttechnik GmbH, built in 2022. The system comes from an industrial environment and is accordingly in a very good, well-maintained condition. Thanks to its recent year of manufacture, it offers the latest technology, high energy efficiency, and state-of-the-art control components. 👉 Ideal for joineries, woodworking, manufacturing businesses, and industrial applications where dust and chips are generated. Key Technical Data (Excerpt) Manufacturer: NESTRO Lufttechnik GmbH Year of manufacture: 2022 Duct diameter: Ø 300 mm Electric diverter valves included Motor power diverter valve: 0.12 kW Operating voltage: 400 V Frequency: 50 Hz Robust industrial design Scope of delivery - Filter plant / filter housing - Fan / negative pressure fan - Control system (incl. modern control components) - Piping and components (as per inventory) - Diverter valves - Steel structure / installation Condition ✔ Year 2022 – very modern condition ✔ The system has been in use and is proven ✔ Well-maintained overall system ✔ Inspection possible any time Special Features ✔ Very recent year of manufacture ✔ Premium manufacturer (NESTRO) ✔ Modern control technology ✔ Energy-efficient and future-proof ✔ Significantly cheaper than comparable new equipment ✔ Ideal for rapid integration into existing operations Kdodpfx Ajywfl Honwjn Important Notes Sale is made in the current condition Dismantling and loading by purchaser Support for dismantling can be organized upon request Sale without warranty Condition / Warranty The machine offered is sold as used equipment. The sale is under exclusion of any liability for material defects. The machine is sold as inspected and without any warranty. The seller does not guarantee functionality, performance, or suitability for any particular purpose. Disclaimer Any liability for material defects is excluded. This does not apply to damages resulting from injury to life, body or health, or to grossly negligent or intentional behavior by the seller. Dismantling and Transport Dismantling of the machine is the responsibility of the buyer at their own expense and risk. The buyer bears all costs and risks associated with dismantling, loading, and transport. Transfer of Risk Risk passes to the buyer at the latest when dismantling or loading begins. Other Provisions No liability is accepted for hidden defects. All information on the machine (e.g. year of manufacture, operating hours, technical data) is given to the best of our knowledge but without guarantee.

Year of construction: 2018, condition: excellent (used), Technical datas: - Max. volume flow: 4500 m3 / h Kdsdpfx Anofl Uagjwjn - Motor power: 2.2 kW - Speed: 1/1410 rpm - Connection: d = 450 mm

Condition: excellent (used), Year of construction: 2015, Dust extractor for capturing, conveying, and sorting all types of wood dust and chips from their sources, as well as extracting and separating settled wood chips and dust.
1 x Modular vacuum filter 9/4-30, 3 units. Fans: 2 x US-FHN 15kW
Conveyor device: 1 x rotary airlock NZRS 2140x665 Total volumetric flow: 30,000 m3/h Kedpfoy Edxuex Anwodn

Condition: used, With bottom extraction attachment Extraction surface (W x H): 2400 x 1600 mm Airflow: 7000 m³/h Height: 2600 mm Depth: 800 mm Complete air supply system included (Wolf KG100 type) With drip tray Comes with control system Kjdpfx Aoyxm Ekjnwodn
