Horizontal lathes Okuma MacTurn 350-W 2006

Okuma

Condition: ready for operation (used), Year of construction: 2005, operating hours: 44,673 h, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 900 mm, controller model: OSP-E100M, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 320, No minimum price – guaranteed sale to the highest bidder! Hsdpezd Tapefx Anpsp Submitting a bid commits you to collecting the machine on time in week 30 of 2026! TECHNICAL DETAILS Travel range X-axis: 1,000 mm Travel range Y-axis: 900 mm Travel range Z-axis: 900 mm Spindle speed: 12,000 rpm Tool holder: BT50 Tool positions: 320 Tool positions for 600 mm tools: 80 Part accuracy: 0.001° MACHINE DETAILS Control system: OSP-E100M Number of axes: 4 Coolant pressure: 30 bar Dimensions & Weight Machine: 4800 x 2980 x 3150 – 21.5 t Tool magazine: 4500 x 2800 x 3150 - 6–7 t Chip conveyor: 4500 x 1600 x 2400 – 2 t, including high-pressure pump Repo: 3000 x 1200 x 1500 mm, 0–0.5 t Operating hours NC cycle time: 71,235 h Spindle running time: 56,241 h Machining time: 44,673 h EQUIPMENT ATC with 320 positions 80 positions for 600 mm tools 2 pallets Balluff writing/reading system NC table Absolute scales in X, Y and Z Renishaw MP10 measuring probe Tool breakage monitoring MOP tool monitoring 30-bar coolant system Mayfran Consep 2000 chip conveyor

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, turning length: 500 mm, turning diameter: 300 mm, spindle bore: 75 mm, spindle speed (max.): 3,800 rpm, controller model: OSP 5000L-G CNC-System, No minimum price – guaranteed sale to the highest bidder! Turning machine with integrated Okuma robot! TECHNICAL DETAILS Turning diameter over cross slide: 450 mm Turning length: 500 mm Turning diameter: 300 mm Spindle bore: 75 mm Spindle speed: 70 - 3,800 rpm Spindle power: 11 kW (30 min) / 7.5 kW continuous operation Travel X-axis: 400 mm Travel Z-axis: 500 mm Rapid traverse X-axis: 12 m/min Rapid traverse Z-axis: 12 m/min Feed rate XZ: 12,000 mm/min Data transmission: RS232 Tool turret: 12 positions Hedpfx Anjzc E Dfspep MACHINE DETAILS Control system: OSP 5000L-G CNC system Data transmission: RS232 Tool turret: 12 positions Power supply: 3 × 400 V Rated machine power: 21 kVA Maximum load current: 36 A Dimensions & Weight Dimensions (L (with chip conveyor) x W x H): 3,900 x 1,800 x 1,800 mm Machine weight: approx. 4,500 kg EQUIPMENT Integrated Okuma robot Automatic parts feeding Ideal for series and automated turning operations Stable and durable design

Condition: good (used), Year of construction: 2005, functionality: fully functional, turning length: 700 mm, turning diameter: 210 mm, spindle speed (max.): 5,000 rpm, overall weight: 7,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Max.: 210 mm Bench turning diameter: 400 mm Max. machinable length: 700 mm X/Z travel: 192/700 mm Stroke against spindle (W-axis): 730 mm C-axis: 0.001° Rapid traverse X/Z: 30/32 m/min Main spindle speed: 5000 rpm Motor: 11/7.5 kW 2 turrets: 12 stations Machine dimensions: 2700 x 2000 x 1980 mm Machine weight: 7000 kg Equipment: 2 turrets, 12 stations, VDI 30 Hjdpfezhwnrjx Anpop Measuring tool IRCO SiMag

Condition: used, Year of construction: 2015, functionality: limited functionality, machine/vehicle number: MW130, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse W: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3,000 rpm - Continuous power (100% duty cycle): Left – 15 kW / Right – 7.5 kW - Maximum swing over bed: 520 mm - C-axis positioning accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Counter-Spindle: - Spindle speed: 6,000 rpm - Maximum bar diameter: 53 mm - C-axis positioning accuracy: 0.001° - Travel: 520 mm Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-station lower turret, all positions driven - Maximum milling speed: 4,500 rpm - Milling motor power: 4.5 kW Electrical Equipment - Operating voltage: 400V, 3-phase, fuse: 151 A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3,200 × 2,200 × 1,900 mm - Weight: 5,500 kg Main Features and Capabilities: - Horizontal construction: Optimal chip evacuation, parts catcher + custom parts conveyor belt - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measuring system (Q SETTER) - Broken tool detection system: Load monitoring auto-learning analyzer controlled by OSP-P300L-R - Workpiece detection on counter-spindle: Low-pressure compressed air gauges - Spindle cooling system - Documentation: Available electronically and as a hard copy Hjdjxxrbbspfx Anpsp Machine status: Operative only with main spindle – sub spindle requires repair Optional Equipment - Bar feeder: TopAutomazione model FU352 - Bar feeder dimensions (L×W×H): 3,500 × 800 × 1,200 mm - Weight: 1,500 kg

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: MW141, Technical characteristics: Work area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X-axis travel: 250 mm / Rapid traverse X: 24 m/min # Z-axis travel: 460 mm / Rapid traverse Z: 24 m/min # W-axis travel: 520 mm / Rapid traverse W: 24 m/min Main Spindle # Spindle mount: A2-8 # Maximum spindle speed: Left 3000 rpm # Continuous power (100% duty cycle): Left - 15 kW / Right - 7.5 kW # Max workpiece diameter over bed: 520 mm # C-axis indexing accuracy: 0.001° # Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle: # Spindle speed: 6000 rpm # Max bar diameter: 53 mm # C-axis indexing accuracy: 0.001° # Travel: 520 mm Motorized Tool Turret # Tool interface: Okuma interface # Number of stations: 12-position lower turret, all stations powered # Maximum speed: 4500 rpm, Milling motor power: 4.5 kW Electrical equipment # Supply voltage: 400V 3-phase # Connected load: 22.5 kVA Dimensions # Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm; Weight: 5500 kg Main features and capabilities: # Horizontal design: optimal chip evacuation, parts catcher + custom parts conveyor belt # Additional coolant tank with 10 bar pressure for cutting tool cooling # CNC control: OSP-P300L-R # Chip conveyor # Fire protection system # Tool measuring system (Q SETTER) # Broken tool detection: Load force auto-learning analyzer managed by OSP-P300L-R Hjdpsxxifkjfx Anpjp # Workpiece detection on counter-spindle: Low-pressure compressed air sensors # Spindle cooling system # Documentation: Available electronically and as hardcopy Optional: Bar feeder: FMB model Turbo 10-72XT/3200/A # Bar feeder dimensions (L×W×H): 3500 × 800 × 1200 mm; Weight: 1500 kg Machine status: In operation

Condition: used, Year of construction: 2017, functionality: limited functionality, machine/vehicle number: MW149, Technical specifications: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left spindle 3000 rpm - Continuous power (100% duty cycle): Left spindle – 15 kW / Right spindle – 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Sub-Spindle (Counter Spindle) - Spindle speed: 6000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-position lower turret, all driven stations - Maximum speed: 4500 rpm, Milling motor power: 4.5 kW Electrical System - Operating voltage: 400V 3-phase, fuse protection 151A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm - Weight: 5500 kg Hsdpexxiiiofx Anpop Main Features and Capabilities: - Horizontal design for optimal chip evacuation - Parts catcher and custom-made parts conveyor strip - Additional emulsion tank with 10 bar pressure for cutting tool cooling - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measurement system (Q SETTER) - Broken tool detection: Load force auto learning analyzer, controlled by OSP-P300L-R - Part detection at sub spindle with low-pressure compressed air gauges - Spindle cooling system - Documentation: available electronically and as manual Option: Bar feeder: TopAutomazione FU352SX - Bar feeder dimensions (L×W×H): 3500 × 800 × 1200 mm - Weight: 1500 kg Machine status: Machine operational only with main spindle – sub spindle requires repair.

Condition: used, Year of construction: 2016, functionality: limited functionality, machine/vehicle number: MW127, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Max. speed: Left spindle 3000 rpm - Power at 100% duty cycle: Left spindle - 15 kW / Right spindle - 7.5 kW - Max. swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle: - Spindle speed: 6000 rpm - Max. bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Holder with Driven Tools - Tool interface: Okuma interface - Number of tool stations: 12-position lower turret, all positions driven - Max. speed: 4500 rpm / Milling motor power: 4.5 kW Electrical Equipment - Operating voltage: 400V 3-phase, fused at 151A - Connected load: 22.5 kVA Machine Dimensions - Dimensions (L×W×H): 3200 × 2200 × 1900 mm - Weight: 5500 kg Main Features and Capabilities - Horizontal design: optimized chip evacuation, parts catcher and custom-made parts conveyor - Additional emulsion tank with 10 bar pressure for cutting tool cooling - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system Hsdpexxihfsfx Anpep - Tool measuring system (Q Setter) - Broken tool detection: Load force auto-learning analyzer controlled by OSP-P300L-R - Part detection at counter spindle: low-pressure compressed air gauges - Spindle cooling system - Documentation: Available electronically and in printed format Machine Status: Currently operating with main spindle only - sub spindle requires repair OPTIONAL: Bar feeder: TopAutomazione model Fu352 SX - Bar feeder dimensions (L×W×H): 3500 × 800 × 1200 mm - Weight: 1500 kg

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: MW144, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3000 rpm - Power at 100% duty cycle: Left – 15 kW / Right – 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Sub-Spindle: - Spindle speed: 6000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-position lower servo turret, all stations driven - Maximum speed: 4500 rpm - Milling motor power: 4.5 kW Electrical Equipment - Mains voltage: 400V 3-phase - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm - Weight: 5500 kg Hodoxxidaopfx Anpop Main Features and Capabilities: - Horizontal design: optimized chip evacuation, parts catcher + custom parts conveyor belt - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measurement system (Q SETTER) - Broken tool detection: Load monitoring and automatic force analysis via OSP-P300L-R - Workpiece detection at sub-spindle: Low-pressure compressed air monitoring - Spindle cooling system - Documentation: Electronic / Hard copy available OPTIONAL Bar feeder: TOP Automazione, model FU 352 - Bar feeder (L×W×H): 3500 × 800 × 1200 mm; Weight: 1500 kg Machine Condition: NOT WORKING - Turret disassembled for repair - X-axis ballscrew to be replaced - Heat exchanger / lubrication unit to be replaced - Hydraulic unit to be replaced - Sub-spindle to be repaired - Spindle position encoder to be replaced - Chip conveyor to be repaired - Set of bar clamping guide and accessory kit - Set of bearings for pusher head

Condition: repair required (used), Year of construction: 2015, functionality: not functional, machine/vehicle number: MW137, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 Hedpfx Aoxxh Udonpsp - Maximum speed: Left 3,000 rpm - Continuous power (100% duty cycle): Left - 15 kW / Right - 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle - Spindle speed: 6,000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Turret with Driven Tools - Tool interface: Okuma interface - Number of positions: 12 lower turret stations, all driven - Maximum speed: 4,500 rpm; Milling spindle power: 4.5 kW Electrical Equipment - Operating voltage: 400V (3-phase), fuse protection: 151A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3,200 × 2,200 × 1,900 mm; Weight: 5,500 kg Main Features and Capabilities: - Horizontal design: Optimal chip evacuation, parts catcher + custom-made conveyor belt - Additional emulsion tank with 10 bar pressure for cutting tool cooling - CNC control: OSP-P300L-R - Swarf (chip) extraction conveyor - Fire suppression system - Tool measuring system (Q SETTER) - Broken tool detection: Load monitoring with auto-learning analyzer via OSP-P300L-R - Workpiece detection on counter-spindle: Low-pressure compressed air gauges - Spindle cooling system - Documentation: Electronic and print manual available Optional: - Bar feeder: FMB Model: Turbo 10-72XT/3200/A - Bar feeder dimensions (L×W×H): 3,500 × 800 × 1,200 mm; Weight: 1,500 kg Machine status: NOT OPERATIONAL - X-axis encoder: faulty

Condition: ready for operation (used), Year of construction: 2003, spindle speed (max.): 12,000 rpm, travel distance X-axis: 505 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 2,000 mm, controller manufacturer: OKUMA, controller model: OSP-U100L, number of slots in tool magazine: 44, number of axes: 6, This 6-axis Okuma MacTurn350-W was manufactured in 2003. It features a Z-axis travel of 2000 mm and a spindle speed of 12,000 RPM. The machine is equipped with an automatic tool changer that holds 44 tools and is ready for robotic integration. If you are looking to get high-quality turning and milling capabilities, consider the Okuma MacTurn350-W turn-mill centre we have for sale. Contact us for further details. • Y-axis: yes • Through-spindle coolant (water) • Lower turret: no live tooling Hsdpfxozhnb Aj Anpsp • Simultaneous machining: not available • Auto door • Robot interface: ready Additional equipment • SMW chucks: 10" and 8" to be supplied • Note: chucks currently installed on the machine are not included Technical Specification Counter Spindle Yes Driven Tools No Taper Size HSK 63 Through-spindle Coolant Yes
