Center Lathe

Präziwe celtic 12

Condition: refurbished (used), functionality: fully functional, machine/vehicle number: 844 12 64, turning diameter over cross slide: 215 mm, spindle bore: 40 mm, turning diameter: 380 mm, center height: 190 mm, center width: 1,250 mm, quill stroke: 120 mm, total length: 3,020 mm, total width: 950 mm, total height: 1,500 mm, spindle speed (max.): 2,800 rpm, spindle speed (min.): 14 rpm, overall weight: 1,850 kg, quill mount: MK 3, workpiece weight (max.): 300 kg, Trade show lathe, available from stock. After Trens filed for bankruptcy, we made an effort and had TOS and later Trens lathes completely overhauled. All machines were disassembled down to the last screw. Fedpfx Aov Hzqxsa Njpp Here is a run-through of a general overhaul at our company: 1. Machine cleaning, disassembly of the individual machine components 2. Grinding: bed, slide, cross support, spindle, tailstock quill 3. Grinding + scraping of the upper support guideways, replacement: trapezoidal screw with nut and V-ledge 4. Scraping of the guide surfaces: spindle, slide, cross support, and tailstock to geometric positions according to the accuracy report 5. Replacement: screw with nut, V-ledge, and Multifix base body for the cross support (including 2 turning tool cartridges) 6. Complete disassembly and replacement of the necessary spare parts in the lock case, threaded housing, headstock, gear box, tailstock, cross support, and upper support 7. Installation, replacement if necessary, of racks, repair of the lead screw and feed screw 8. Complete bearing replacement in all machine assemblies 9. Complete replacement of machine plates 10. Priming of the machine, sealing, sanding, polyurethane topcoat, and painting of the machine accessories - white RAL 9003, anthracite RAL 7016 11. New control cabinet with electrical components, replacement: main motor, rapid traverse motor, hydraulic pump, cabling, and LED lighting of the work area 12. Preparation of the accuracy report and the electrical test report 13. Inspection and machine acceptance at the factory All refurbished machines have a CE certificate and a 12-month warranty. CE version: - Chuck guard with limit switch - Front chip guard mounted on slide - Rear chip guard - Lead screw and feed screw covers - Brakes after emergency stop within 2 seconds Special accessories (used): - Three-jaw lathe chuck Ø 190 mm - Four-jaw lathe chuck Ø 190 mm - Three-jaw lathe chuck Ø 240 mm - Four-jaw faceplate Ø 320 mm - Support center for bed slide - Various chuck jaws (10 pieces) - Collet set Ø 2 - 25 mm with collet chuck + drawbar - Special collet set (10 pieces) with collet chuck - 4-way tool holder

Condition: new, Year of construction: 2025, CORMAK 400 metal lathes is a new, improved version of the popular metal processing lathes. Among other things, the tool holder cover, spindle bearing system, new digital readout have been improved. They are suitable for production plants, workshops and tool shops. They are perfect for unit and small lot production. NEW, IMPROVED MODEL !!! high-quality and reinforced spindle bearing system new guards system compliant with CE standards the latest model of digital axis reading reinforced and modernized lathe base with drawers for tools and an extendable chip tray Characteristics of the machine REINFORCED, RIBBED SURFACE OF THE LATHE'S BED PROVIDES MAXIMUM REDUCTION OF VIBRATION, ADDITIONALLY PRECISE GRINDED, HARDENED BED DIGITAL READOUT OF THE AXIS IN STANDARD EQUIPMENT LARGE SPINDLE BORE PROVIDES OPTIMUM PERFORMANCE 52 mm THE APPROPRIATE BED WIDTH ENSURES STABLE AND PRECISE WORKING CONDITIONS MACHINE EQUIPPED WITH HIGH-QUALITY AND HARDENED SPINDLE BEARING SYSTEM EFFICIENT MACHINING THANKS TO TWO AUTOMATIC FEEDS AND EQUIPMENT WITH A ROLLER AND A DRAFT BOLT HARDENED WHEELS IN THE SPINDLE GEAR ADJUSTABLE CLUTCH OVERLOADS ON THE PULL SHAFT POSSIBILITY TO MACHINE THE FULL RANGE OF THREADS WITHOUT REPLACING THE WHEELS IN THE GUITAR FEED CHOICE LOCK: THROUGH SCREW OR SHAFT THE REMOVABLE BRIDGE ENABLES THE WORKING OF ELEMENTS WITH AN INCREASED DIAMETER RETRACTABLE CHIP DRAWER AND TOOL DRAWERS FOR BETTER AND EFFICIENT WORK Technical data MAXIMUM TURNING DIAMETER 400 mm MAXIMUM TURNING DIAMETER OVER THE BED 250 mm MAXIMUM TURNING DIAMETER IN THE SELECTION OF THE BRIDGE 520 mm TURNING LENGTH IN DEAD CENTRES 1000 mm BED WIDTH 218 mm SPINDLE END CAMLOCK D5 SPINDLE CONE MK6 SPINDLE BORE 52 mm SPINDLE ROTATION RANGE 65-1810 rpm SPINDLE SPEED NUMBER 16 ranges RANGE OF LONGITUDINAL FEED (40) 0,053 - 1,291 mm RANGE OF TRANSVERSE FEED (40) 0,011-0,276 mm THE MAXIMUM DIMENSION OF THE TOOL 20 mm x 20 mm METRIC THREAD 0,4-7 mm INCH THREAD 4-60 T.P.I. MODULAR THREAD (22) 0,4-3 mm THREAD D. P. (28) 8-84 D. P. TAILSTOCK QUILL DIAMETER 50 mm TAILSTOCK QUILL STROKE 110 mm TAILSTOCK TAPER MT4 ENGINE POWER 2,2 kW PUMP POWER 0,1 kW WEIGHT 640 kg Fpodpoiz Tczofx Aa Nop DIMENSIONS 2000x820x1650 mm EQUIPMENT digital readout steady rest follow rest 200 mm 3-jaw chuck 200 mm 4-jaw chuck face plate 280 mm dead center MK4 x 2 reduction sleeve MK6/MK4 keys Factory new machine, under warranty For more information you can visit our web page.

Condition: new, turning diameter over bed 410 mm turning diameter over slide rest 240 mm turning length 1000 mm turning diameter in the gap 530 mm turning speeds 65 - 1810 U/min centre height 205 mm spindle bore 52 mm tailstock quill taper MT 4 total power requirement 2,2 kW weight of the machine ca. 0,9 t dimensions of the machine ca. 1,9 x 0,8 x 1,3 m Center lathe with: 3-axis digital measuring system fully assembled electromagnetic main spindle brake auto. Feed in longitudinal and transverse direction safety relay Micrometer end stop coolant device 3-jaw lathe chuck with 1 set of turning and drilling jaws German operating instructions. Fodpfx Aaom Rlb Nj Nspp

Condition: used, turning diameter 210 mm turning length 1000 mm swing diameter over bed slide 435 mm centre height 210 mm greates pass round over bed 435 mm spindle head DIN 55027 / DIN ISO 702-3 spindle bore 52 mm turning speeds 44 - 2.000 U/min transmission ratio 12 feed per revolution 0,036 - 2 U/mm diameter of quill 65 mm quill stroke 120 mm Fpsdoxqrdyspfx Aa Njp taper bore DIN 228 MK4 total power requirement 5,5 kW -Lead screw and feed screw cover -Brake for main spindle -Toolmaker precision according to DIN 8605 -High drive power and high torque on the main spindle -Large thread cutting range -Convenient operation -Digital position display (HEIDENHAIN ND 7013) 3-axis display for bed, cross slide, and top slide Tool memory for 16 tools Tool memory with one reference point per axis Sum button for Z and Zo Inch/metric switchable Plane path X as radius or diameter display Display resolution up to 1 µ Taper calculator -LED machine light -Coolant device

Condition: good (used), functionality: fully functional, turning diameter: 400 mm, turning diameter over top slide: 240 mm, center height: 200 mm, turning length: 1,100 mm, total length: 2,500 mm, total width: 1,100 mm, total height: 1,900 mm, spindle speed (max.): 2,500 rpm, overall weight: 1,500 kg, three-jaw chuck diameter: 240 mm, TECHNICAL SPECIFICATIONS & EQUIPMENT: Operating voltage: 380 V Frequency: 50 Hz Rated current: 21 A Spindle speed: 75–2500 rpm Spindle bore: approx. 52 mm Centre distance: 1100 mm Centre height over bed: approx. 200 mm Swing over bed: 400 mm Centre height over cross slide: 120 mm Swing over cross slide: approx. 240 mm The machine is equipped with a tailstock, a Multifix tool holder, and a 3-jaw chuck Diameter: 240 mm Including two-axis digital readout by manufacturer FAGOR REFERENCE NUMBER: 14 Fodpew U Tn Nsfx Aa Njpp DIMENSIONS & WEIGHT: 2500 x 1100 x 1900 mm 1500 kg PICK-UP INFORMATION: The item will be available from September 2025. A collection date must still be arranged on a specific day from 01.09.2025 onwards FCA: 73235 Weilheim an der Teck (DE), loaded onto truck

Condition: good (used), Year of construction: 2010, functionality: fully functional, Swing dia ober bed 505 mm Swing dia over cross slide 270 mm Swing dia in bridge 700 mm Center distance 1000 mm Fpsdpsxtwvmsfx Aa Njp Bed width 340 mm Spindle bore D77 mm Spindle power 7,5 kW Spindle speed 12,5 - 2000 rpm Tailstock taper MT5 Weight 2300 kgs Dimensions LxWxH = 2600 x 1100 x 1525 mm Accessories: - 3 axis DRO - Multifix tool holder set - Halogen machine lamp - 3 jaws chuck - Face plate - Steady rest - Coolant tank - and more other accessories

Condition: used, Year of construction: 2015, Technical details: turning diameter over bed: 420 mm turning diameter over support: 255 mm turning length: 1000 mm turning dia. in gap: 580 mm centre height: 205 mm Fjdpfx Aevaxi Esa Nspp spindle bore of work spindle: 52 mm range of revolution per miute: 30 - 550 / 550 - 3000 (FU gesteuert) / 2 step U/min feed:: längs: 0,05 - 1,7 mm/U feed:: plan: 0,025 - 0,85 mm/U tailstock quill taper MT: 4 tailstock quill adjustment:: 120 mm total power requirement: 5,5 kW weight of the machine ca.: 1,5 t dimension machine xH: 2,1 x 1,1 x 1,5 m Thread cutting possible, e.g. metric thread and inch thread Infinitely variable speed control 3-axis position indicator 3-jaw chuck Ø 200mm Multifix size B quick-change tool holder *

Condition: new, Precision lead screw and feed screw lathe Manufacturer: GDW Model: LZ 400 V economyline Fpedpfjxg Emysx Aa Nsp Condition: New machine with stepless speed control to the highest safety standard Centre height: 200 mm Centre distance: 1,000 mm Spindle bore: 62 mm Standard configuration includes: -- 3-axis digital readout, 7" colour display with constant V feature - LED machine light, integrated into machine enclosure - Electromechanical limit switch system for threading and feed operations - Quick-change toolpost size B with turning tool holder - Main drive brake system (spindle brake) - Sliding chuck guard with interlock monitoring - Removable chip guard rear panel - Sliding splash guard - Extendable chip tray - Simple bed stop - Central lubrication system - Set of change gears (number of teeth: 21-33-84-120) - Reducing sleeve for main spindle inner taper ME 70/MK 4 - Protective flange for spindle nose DIN 55027-6 - Additional service socket - 2 fixed centres DIN 806-MK 3 - Set of operating tools, keys and oil gun - Spare shear pins - Operating manual with spare parts list and electrical documentation

Condition: new, turning length 1000 mm turning diameter 420 mm swing diameter over bed slide 255 mm turning dia. in gap 580 mm spindle bore 52.0 mm turning speeds 45 - 1800 U/min bed width 250 mm spindle taper DIN 55029 D 1-6 taper in tailstock 4 MK quill travel 140 mm total power requirement 3.0 / 4.5 kW weight of the machine ca. 1220 kg range L-W-H 2070 x 900 x 1600 mm Equipment: - 3-axis digital display ES-12 V with LCD display - 3-jaw chuck DK11-200 mm / D6 - Clamping disk 350 mm - Fixed steady rest - passage diameter max. 135 mm - Follow-on steady rest - passage diameter max. 65 mm - Coolant system - Quadruple tool holder - Protective device for quadruple tool holder - Micrometer longitudinal stop - Slip clutch - Turret stop with fine adjustment - Thread gauge - Motor with magnetic brake according to CE standard - Foot pedal with brake function according to CE - Initial filling with Shell Tellus 46 - LED machine light - Change gears - Reduction sleeve Fpodpjxaavvefx Aa Nep - 2 centering points - Chip back wall - Operating tools - Operating instructions

Condition: used, functionality: fully functional, Distance between centers: 1250 mm Swing diameter over bed: 400 mm Swing diameter over cross slide: 245 mm Swing diameter in gap: 585 mm Spindle bore: 55 mm Spindle speeds: 15-2500 RPM Accessories: Fpedpfxexu Ario Aa Nop - 3-jaw chuck - 4-jaw chuck - Fixed steady rest - Traveling steady rest - Quick-change toolpost - Digital readout (Mitutoyo) - Coolant system
