Universal CNC tool milling machine

PRO RICHYOUNG PMU 50 CNC (FMU50 CNC)

Condition: ready for operation (used), Deckel FP 2 NC Universal Milling Machine Universal Milling Machine TNC 320 / 321 Travel distances: x- 300mm | y- 300mm | z- 400mm Stepless spindle speed 31.5 - 5000 rpm Feed rates 2-4000 mm/min Rapid traverse 4000 mm/min Tool holder SK 40 Hsdexfkm Aepfx Ai Tew Quill stroke 80 mm Machine weight 1350 kg You are welcome to arrange an inspection appointment. We can also organise affordable shipping for you! You will receive a proper invoice. For international customers, we can also provide a net invoice. The requirement is a valid VAT ID number. Subject to prior sale. Visit our shop and take a look at our other offers. The specified company names and trademarks are the property of their respective owners and are used for identification and description purposes only. Variations in technical data or errors in the description of the item may occur and are subject to change.

Condition: used, Year of construction: 2016, Milling machines Travel distance X: 661 mm Hsdozwnfyjpfx Ai Tjw Travel distance Y :407 mm Travel distance Z: 508 mm Number of axis: 3 milling machine / machining center Control: Hurco Max 5 / WinMax spindle chuck: ISO 40 / DIN 69871 spindle revolutions: 10000 rpm Speed range to: 10000 U/min table size X: 762 mm table size Y: 406 mm max. workpiece weight: 1500 kg tool changer: 20 - time input Power : 11 kW Torque: 72 Nm Rapid traverse: 28 m/min spindle cooling chip conveyor CNC vertical machining center HURCO VM10i, year 2016, equipped with HURCO MAX 5 control and WinMax software. Travels X/Y/Z: 661 x 407 x 508 mm. Table size: 762 x 406 mm, max. table load 1,500 kg. Spindle speed up to 10,000 rpm, spindle power 11 kW, torque 72 Nm, ISO 40 tool holder. 20-position automatic tool changer, rapid traverse 28 m/min, coolant system and chip auger

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 2025-09/2404095, turning diameter over cross slide: 224 mm, spindle bore: 51 mm, center height: 180 mm, quill diameter: 32 mm, quill travel distance: 100 mm, total length: 1,680 mm, total height: 1,400 mm, TECHNICAL DATA: Centre distance: 1000 mm Centre height: 180 mm Swing diameter over bed: 360 mm Swing diameter over cross slide: 224 mm Swing diameter without gap bridge: 502 mm Gap bridge length: 235 mm Cross slide travel: 170 mm Top slide travel: 95 mm Max. turning tool cross section: 16x16 mm Chuck mounting: D1 - 4 Spindle mounting (lathe spindle): MT 6 Spindle bore: 51 mm Spindle speed: 70 - 2000 rpm Number of speed ranges: 8 Longitudinal feeds: (32) 0.052 - 0.392 mm/rev Cross feeds: (32) 0.014 - 0.380 mm/rev Metric thread pitch: (26) 0.4 - 7 mm Metric module threads: (26) 0.4 - 7 mm Inch threads, TPI: (34) 4 - 56 TPI Inch module threads, TPI: (34) 4 - 56 TPI Leadscrew pitch: 4 mm Leadscrew diameter: 32 mm Quill mounting: MT 3 Quill diameter: 32 mm Quill travel: 100 mm Motor power: 1500 W Coolant pump: 40 W Electrical connection: 400/50 V/Hz Total length: 1680 mm Total height: 1400 mm Weight: 520 kg Standard accessories: - RÖHM 3-jaw chuck Ø 200 mm - 4-jaw faceplate chuck Ø 200 mm - Face plate Ø 320 mm - 2 fixed centre points - Live centre MT 3 - Travelling steady - Fixed steady - Quick-change tool post set ME - Thread dial and change gear set - Halogen machine lamp - Emergency stop button / No-voltage release - Chuck guard with safety switch - Machine base / chip tray / splash guard Hodpfxsxykafs Ai Tow - Tool kit / operating manual / CE

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 4397, Ladies and Gentlemen, We are selling a Weiler Praktikant 160 AC lathe built in 1998 with original Weiler 3-axis digital readout. This newer version "AC" stands out above all due to the infinitely variable speed control, which makes working on the otherwise very user-friendly machine even easier. The machine has been extensively overhauled in our workshop so that it is technically and visually in excellent condition. All guides are in good order, the gears run quietly and the levers are easy to operate. You are welcome to visit us on site to see the condition for yourself. Availability: on request Machine no. 4397 Year of manufacture: 1998 Center height: 160mm Hodpfsq H D U Eex Ai Tsw Center width: 650mm Spindle passage: Ø 40mm Spindle speed: 20-3000 rpm stepless Tailstock taper holder: MK3 Quill stroke: 85mm Feed range longitudinal slide: 0.020 - 0.630 mm/rev Feed range cross slide: 0.006 - 0.200 mm/rev Possible thread types: Metric, inch, module, diametral pitch Metric thread pitches: 0.25 - 8mm Spindle brake: switchable Total connected load: 7.5 kvA Voltage: 400V Dimensions: approx. 1.58x0.9x1.5m (LxHxW) Weight: approx. 720kg Further equipment and accessories: 3-axis digital display, coolant device, chuck protection, jaw chuck and other accessories on request... Our service promise to you: - We are a certified master company in the field of mechanical engineering - All machines are thoroughly checked - All lubricants and any worn parts are replaced in advance - On request, we can completely or partially overhaul your chosen machine - On request, we can repaint the selected machine in the color of your choice - On request, you can order additional accessories such as tools etc. directly with the machine - On request, we can install additional accessories such as safety devices etc. - We are happy to take care of shipping and/or installation

Condition: excellent (used), functionality: fully functional, Weiler Primus LZ/G lead and feed screw lathe in special paint finish light gray !!! Technical data: >> Year of construction ca.1990 Machine-No.3150 >> Center height 120 mm >> Center width 430 mm >> Speed: 60 - 3000 rpm in 18 gear steps >> spindle passage 23 mm >> Short taper spindle head DIN 4 >> Tailstock MK 2 >> Feed rates from 0.03 to 0.15 mm /rev >> Possible threads metric, inch, module and diametral pitch Hjdjvivmyepfx Ai Tow >> Metric thread pitches from 0.25 to 2.5 mm >> Switchable spindle brake >> Weight approx. 360 kg >> Length 1.2 m, height 1.3 m, depth 0.65 m Accessories and equipment: >> 1 piece three-jaw chuck NEW 125mm with 2 sets of jaws >> Mulifix size A with 2 steel holders >> collet chuck device new with collets from 3 to 26mm 1 mm increasing new >> To the machine : We are offering a Weiler Primus lathe in very good condition. The machine is of course fully functional. The slides all run smoothly and evenly. The bed guides are in very good condition. The Primus was used in a training company. This newer generation of Weiler lathes is very user-friendly and surfaces can be produced as if ground. Take the opportunity to inspect this machine on site under power and see the condition for yourself.

Year of construction: 2019, condition: used, Travel X/Y/Z: 650mm/500mm/475mm, table dimensions X/Y: 1530mm/450mm, max. table load: 400kg, spindle taper: SK40, max. spindle speed: 4000rpm, spindle power: 7.5kW, milling head swivel range: 140°, control: Heidenhain TNC 620. Weight: approx. 2750kg, machine dimensions X/Y/Z: approx. 2200mm/2300mm/2050mm. An on-site inspection is possible. Hsdpfx Aijzwgido Tjw

Condition: excellent (used), Year of construction: 2022, operating hours: 798 h, functionality: fully functional, machine/vehicle number: S102221332GKBCP, travel distance X-axis: 660 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, feed rate X-axis: 28 m/min, feed rate Y-axis: 28 m/min, feed rate Z-axis: 28 m/min, torque: 74 Nm, total height: 2,564 mm, total length: 3,264 mm, total width: 2,930 mm, overall weight: 2,850 kg, spindle speed (max.): 10,000 rpm, operating hours of spindle: 98 h, spindle nose: SK 40, number of slots in tool magazine: 24, Equipment: chip conveyor, documentation/manual, HURCO VM10i A vertical machining center in compact format, in almost new condition. !!! 98 operating hours of the spindle !!! Hsdpfx Asz Ei Amoi Tjw Work area Spindle nose - table (mm) 102 - 610 Table - clamping surface L x W (mm) 762 x 406 T-slots (DIN 650) 3 x 18 H8 x 100 Table load (uniformly distributed) (kg) 1500 Travel X-axis (mm) 660 Y-axis (mm) 406 Z-axis (mm) 508 Feed rate Rapid traverse X-axis / Y-axis / Z-axis 28 / 28 / 28 Main spindle Spindle taper (DIN 69871 A) SK40 Spindle speed max. (rpm) 10,000 Spindle power max. (kW) 11 Spindle torque max. (Nm) 74 Tool changer Magazine slots 24 Tool diameter max. (mm) 80 Tool length max. (mm) 250 Tool weight max. (kg) 7 Includes coolant tank (62 liters) and chip conveyor, as well as extensive accessories (machine vises, chucks, software for processing DXF files). An inspection is possible at any time. The Hurco is currently still connected and can be tested.

Condition: as good as new (ex-display), Year of construction: 2026, Optiturn L28 HS CNC lathe directly from the manufacturer. L28 HS - The OPTIMUM CNC lathe with Siemens control SINUMERIK 808D Advanced PPU 150. Strutted machine bed made of gray cast iron - Elaborate spindle bearings - Emergency stop impact switch - Central lubrication - Reference switch - Maintenance-friendly protective housing - Rear access flap for maintenance - Safety switch on the front sliding door - Turning turret is located behind the turning center (left turning tool) - Linear guide - Software package "SINUMERIK 808D on PC" included. (Practical training software, so that workpieces can be programmed and simulated offline on the PC. Free to download free of charge - Two-year SIEMENS warranty included Technical data Electrical connection 400 V / 3 Ph ~50 Hz Total connected load 3.75 kVA Spindle Drive motor S1 operation 2.2 kW Torque drive motor S1 operation 14 Nm Torque at the spindle 28 Nm Spindle holder DIN 6350 A2-3 Spindle cone 5C Spindle bore Ø 30 mm Cooling lubricant system Coolant pump output 95 W Tank capacity 25 liters Machine data Center height 169 mm Center width 430 mm Rotation Ø over cross slide Ø 200 mm Rotation Ø over machine bed Ø 300 mm Speed range Spindle speeds* 40 - 4,000 min-1 Tool turret Type electric Number of tool positions 6 tools Mounting height, width square max. 16 mm Mounting diameter of boring bar max. 16 mm Accuracy Repeat accuracy ± 0.01 mm Hjdpfxezi Er Ie Ai Tow Positioning accuracy ± 0.01 mm Bhajn7pvcu Travel distance X-axis 145 mm Z-axis 465 mm Feed speed X-axis 10,000 mm/min. Z-axis 12,000 mm/min. Machine leasing possible via Siemens Finance. Liquidity required.

Condition: used, Year of construction: 2022, Milling machines Travel distance X: 610 mm Travel distance Y :355 mm Travel distance Z: 460 mm Number of axis: 3 milling machine / machining center Control: Siemens 828D ShopMill spindle revolutions: 10000 rpm Speed range to: 10000 U/min table size X: 700 mm table size Y: 350 mm max. workpiece weight: 350 kg tool changer: 16 - time Hsdpfx Aszwktyoi Tew spindle cooling chip conveyor control Siemens Siemens 828D ShopMill control X/Y/Z travels: 610 × 355 × 460 mm Spindle speed: 10,000 rpm 16-position tool changer Table size: 700 × 350 mm Max. table load: 350 kg Through-spindle coolant with 20-bar high-pressure pump Chip conveyor Electronic handwheel Renishaw TS27R tool measurement system Renishaw OMP40-2 touch probe RJ45 network connection

Condition: used, Year of construction: 1992, functionality: fully functional, Weiler Praktikant 160 B Lead and Draw Spindle Lathe, built in 1992, with a new 3-axis digital display from K&C, from a vocational training workshop! Technical data: >> Year of manufacture 1992, Machine No. 92-160-2994 >> Center height 160 mm >> Distance between centers 650 mm >> Spindle speeds: from 24 to 2500 rpm >> Spindle bore 40 mm >> Short taper spindle head, DIN 55027, size 5, with bayonet lock >> Tailstock, MK 3 >> Feeds from 0.02 to 0.63 mm/rev >> Possible threads: metric, inch, module, and diametral pitch >> Metric thread pitches from 0.25 to 8 mm >> Weight approx. 680 kg >> Spindle brake, switchable >> Length 1.6 m, height 1.25 m, depth 0.7 m Accessories and equipment: >> 3-axis digital display from K&C with operating manual Functions: Switching mm/inch, coordinate selection ABS/INC, halving of the display value, reference mark, tool programming 200 pieces, taper calculation, radius/diameter, quick zeros, switching of the counting direction >> 3-jaw chuck 160 mm with 1 set of jaws >> Tool clamping system with 2 steel holders >> Bed stop >> Centering point >> Coolant system >> Rear panel >> Machine feet >> Electronic spindle protection >> Operating manual Additional accessories such as collets, 4-jaw chucks, steady rests, and more are available at an extra charge. For safety: Electronic spindle protection, cover for the lead and draw spindle, 2 emergency stop buttons, spindle brake, electronic door protection for the change gears. Hodpfx Aezd Tycei Tew About the machine: Offered is a Weiler Praktikant 160 B lead and draw spindle lathe in very good condition. All slides run smoothly and evenly. Even at high speeds, the Weiler runs quietly. This newer generation of Weiler lathes is very user-friendly and allows surfaces to be produced that are as smooth as if they had been ground. Take advantage of the opportunity to inspect this machine on-site while it is powered up and see its condition for yourself.
