PROFILE AND PIPE HAUL-OFF, PROTEC/VON HE

PROTEC

Condition: good (used), load capacity: 250 kg, Equipment: foot remote control, Euen welding turntable, 250 kg load capacity, with chuck. Height horizontal: 940 mm. Height tilted to center: 770 mm. Pedpfx Agsy Hl Hcj Degk

Condition: good (used), functionality: fully functional, load capacity: 10,000 kg, Welding positioner 10 tons, height-adjustable Height horizontal min. 1.3 m plus approx. 0.6 m Pedpfx Agjy Hl Elj Dsgk Height tilted min. 1.0 m plus approx. 0.6 m Length 2.5 m Width 1.8 m Clamping plate diameter approx. 1.9 m with remote control Speed steplessly adjustable

Condition: new, Year of construction: 2026, overall weight: 1,350 kg, Top quality 3D perforated table 3000 x 1500 x 200 mm, 100 mm grid, plate thickness 20 mm, hole diameter 28 mm, surface machined, very robust, weight approx. 950 kg With table legs, height adjustable in 6 steps Price without accessories, surcharge €500 Pedox Nihijpfx Ag Dogk Packed in wooden crate, shipping upon request

Condition: new, Year of construction: 2024, Welding rotary table 1000 Kg load capacity with hand and foot remote control diameter 1000 mm Bore 100mm height 580mm speed stepless 0 - 0,6 rpm Motor AC 380 V Pgodpfjgfqkwsx Ag Dsk

Condition: new, Year of construction: 2025, load capacity: 500 kg, 3-Axis Rotation and Tilting Positioner – 500, 1000, 2000, 3000 kg Load Capacity, Clamping Plate Diameter 0.5, 0.65, 0.8, 1.0 meters HDL 500: - Minimum height: 1000 mm - Maximum height: 1500 mm - Clamping plate diameter: 500 mm - Reach radius: 800 mm (cantilever) - Speed: 0.1 – 1 rpm These positioners have proven themselves in the fields of construction and agricultural machinery, commercial vehicles, industrial trucks, as well as in the aerospace and energy sectors. They are suitable for welding, assembly, machining, and more. With their stable and robust construction, flexible three-axis positioning (including overhead), and easy operation, they facilitate welding, assembly, and handling of large workpieces. - Faster production and increased productivity - Optimal positioning of the workpiece improves welding quality and enables higher deposition rates - Enhanced safety by significantly reducing dangerous crane handling - Simultaneous positioning along up to three axes without cumbersome re-clamping - Easy and ergonomic operation protects and relieves the operator - Flexibility thanks to modular adaptability and custom configurations Basic Principle: Due to the arrangement of the swivel arm rotation axis above the clamping plate, the arm acts as a counterweight to the workpiece. As a result, these machines are significantly more powerful than tilt rotary tables or tilt-rotational positioners. This principle allows handling of the specified loads in any position. Thanks to the endless rotation of two axes and additional height adjustment, all workpiece positions (including overhead) are possible. Table rotation speed is continuously adjustable from 0.1 to 1.0 rpm; from 2000 kg load capacity, 0.05 to 0.6 rpm. Supplied with wireless remote control. Psdpfsulaxbsx Ag Dogk - Rotation range: 360° continuous - Swivel range: 360° continuous - Lift: 1000 – 1500 mm; from 2 tons load capacity: 1250 – 2000 mm - Arm outreach up to 1000 kg: 1 meter; from 2000 kg: 1.5 meters

Condition: used, functionality: fully functional, load capacity: 2,000 kg, Equipment: foot remote control, 3-axis welding positioner, 2-ton load capacity, in good condition Incl. hand remote control (foot control available on request) Inclination and rotation speed continuously adjustable 0.05 - 1.0 rpm Clamping plate diameter: 1.0 meter Height tilted to center min. approx. 0.7 m, horizontal 0.9 m Height tilted to center max. 1.6 m, horizontal 1.8 m Podpfxoyupgze Ag Degk Length 2.2 m, width 1.35 m

Condition: new, Year of construction: 2025, functionality: fully functional, load capacity: 1,000 kg, Column lift rotary device 1 tonne load capacity Protec turning device / positioner Syncrolift Double column, remote control wireless and manual Column adjustment: 2x movable Load capacity: 1000 kg Minimum working height: 600 mm Pgjdpox Th N Hjfx Ag Dok Maximum working height: 1500 mm Speed: 1 rpm Clamping plate diameter: 500 mm Rotary drive: 0.37 kW Upon request, 2 to 10 tonne load capacities available

Condition: new, Year of construction: 2025, load capacity: 1,200 kg, Equipment: foot remote control, 1200 kg Load Capacity Welding Positioner, CE Certificate Load capacity horizontal: 1200 kg Load capacity tilted: 1200 kg with a load center at 250 mm Very robust Continuously adjustable speed from 0.05 to 0.7 rpm (higher speeds available at extra conversion cost) Turntable diameter: 1200 mm Tilting up to 120° Height horizontal: 1,050 mm, tilted up to center: 880 mm Hand and foot remote control Dimensions: 1.35 m (length) x 1.2 m (width) Chuck or quick-change chuck available for extra charge, depending on size As shown, diameter 1000 mm, price: €2,900 (special price, only available when purchased with the welding positioner) Counter bearing with steps: €480, counter bearing with screw adjustment: €880; load capacity 4000 kg Pedpfx Asxq S Nisg Djgk

Condition: new, Year of construction: 2025, functionality: fully functional, load capacity: 1,500 kg, Perforated Table 1200 x 2400 x 200 mm Tabletop thickness: 20 mm, borehole diameter: 28 mm Includes wireless remote control Swivel range: 360° Height adjustment: Hydraulic motor, 800 to 1200 mm Podpfsx Thyrex Ag Dsgk Rotation speed: 0.5 rpm Motor power: 0.75 kW We offer tables in various sizes and load capacities: - Load capacity 500 kg, dimensions: 1000 mm x 1500 mm x 200 mm, borehole 28 mm, height adjustment manual or automatic - Load capacity 1000 kg, dimensions: 1000 mm x 2000 mm x 200 mm, borehole 28 mm, height adjustment manual or automatic - Load capacity 1500 kg, dimensions: 1200 mm x 2400 mm x 200 mm, borehole 28 mm, height adjustment manual or automatic - Load capacity 2000 kg, dimensions: 1200 mm x 2400 mm x 200 mm, borehole 28 mm, height adjustment manual or automatic - Load capacity 3000 kg, dimensions: 1200 mm x 2400 mm x 200 mm, borehole 28 mm, height adjustment manual or automatic - Load capacity 5000 kg, dimensions: 1500 mm x 3000 mm x 200 mm, borehole 28 mm, height adjustment manual or automatic

Condition: new, Year of construction: 2025, Column lift rotary device 1 tonne load capacity Protec turning device / positioner Syncrolift Double column, remote control wireless and manual Column adjustment: 2x movable Load capacity: 1000 kg Minimum working height: 600 mm Maximum working height: 1500 mm Speed: 1 rpm Clamping plate diameter: 500 mm Podpox Thvyefx Ag Djgk Rotary drive: 0.37 kW Upon request, 2 to 10 tonne load capacities available
