Horizontal machining center

QUASER HX404BP/15C

Condition: used, Year of construction: 2004, Technical details: x-travel: 1500 mm y-travel: 1000 mm z-travel: 1000 mm control for program: TNC 530 spindle hours: noch nicht bekannt h milling head speed: 1: 30 bis 930 und 2: 930 bis 4000 / steples U/min tool taper: horiz./vertical: SK 50 (DIN 69871/Din 69872 Form A) max. torque on the spindle: 1000 Nm spindle head swivable left - right: 90 ° feed: 1 - 6000 mm/min feed power: 30 kN kN rapid traverse: 15 m/min Number of tools: 1 St. table clamping surface LxW: 1600 x 800 mm Nedpfx Aeu Nc Risqxjdc table load: 40 kN kN voltage: 400 V / 50 HZ V total power requirement: 42 kW Weight approx.: 15,2 t compressed air: 6,3 bar dimension machine xH: 3,1 x 4,7 x 2,6 m dimensions: Kühlfilter: 1,9 x 1,6 x 1,4 mm space requirements approx. LxWxH: ca. 38,5 m² m² Applications: Milling, drilling; tapping, boring. with direct coded length measuring systems the guideways of the 3 axes are on flat guideways CTS and external cooling Milling head position controlled +/-90° milling spindle nominal drive power 22 kW with integrated hydraulic power unit up to 100bar operating pressure with coolant unit with filtration, with high pressure pump 60 bar (internal cooling), nominal delivery 20 l/min. and low pressure pump 4 bar (external cooling) as well as spray gun Hinged belt chip conveyor DGS, type SSF 600 P50 Accessories: Measuring probe SK40 Reference tool SK40 Milling head SEMPUCO *

Condition: excellent (used), Year of construction: 2011, TECHNICAL DETAILS CNC control: MSX-501III X axis mm: 560 Y axis mm: 560 Z axis mm: 660 B axis deg.: 360.000 Table load capacity kg: 400 Cutting feed rate mm/min X,Y,Z: 60,000 Max. rapid traverse m/min X,Y,Z: 50 Spindle speed rpm: 12,000 Spindle power kW: 15 Taper type: ISO-40 Torque Nm: 120 Tool changer type: Chain Tool changer positions: 60 Max. tool diameter mm: 70 Max. tool diameter with adjacent positions empty mm: 170 Max. tool length mm: 450 Max. tool weight kg: 8 Coolant tank capacity l: 500 Through-spindle coolant (high-pressure): Yes EQUIPMENT Double chip conveyor Nsdexfka Njpfx Aqxsdc ISO-40 taper High-pressure through-spindle coolant with pump Tool breakage detection probe Part measuring probe RENISHAW MACHINE DIMENSIONS Length mm: 3,755 Width mm: 2,300 Height mm: 2,610 Weight kg: 7,600

Condition: good (used), Year of construction: 1983, Machine number: 316204/22 Type / Model: FSS 315/E Travel ranges x-y-z: 850 – 280 – 355 mm Table: 1,200 x 370 mm Clamping area: 1,060 x 260 mm Speed range: 28 to 1,400 rpm Spindle mount: SK 50 Quill stroke: 80 mm Feeds for x and y axes: 16 to 800 mm/min Feed for z axis: 5 to 250 mm/min Power: 8 kW Ndjdpsfli Afsfx Aqxjc Accessories/Equipment: Head swivels Condition: good Weight: 4 t Dimensions: 2,000 x 2,000 x 2,400 mm

Condition: good (used), Year of construction: 1990, CNC milling machine, manufacturer: TOS, type: FGS40CNC Control system: Heidenhain TNC 355, year of manufacture: 1990 Travel distances: X 1000 mm, Y 500 mm, Z 500 mm Spindle mount: ISO 50. Njdpfx Aqedtfhqjxedc

Condition: excellent (used), Year of construction: 2011, operating hours: 11,000 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 565 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, total height: 2,700 mm, total length: 4,000 mm, total width: 2,400 mm, table width: 400 mm, table length: 400 mm, spindle speed (max.): 8,000 rpm, operating hours of spindle: 6,383 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Offered here is a horizontal machining center from the manufacturer Doosan. Operating hours: 11,320 h Spindle hours: 6,383 h The machine is in very good condition and can be inspected under power in our facility. Both clamping towers are included in the scope of delivery. Manufacturer: Doosan Model: HC 400 Year of manufacture: 2011 Control: Fanuc Series 32i-MODEL A Technical data: Travel X-Y-Z: 600x560x565 mm B-axis: 1° increment (indexing table) Rapid traverse X-Y-Z: 40 m/min Feed rates: 20,000 mm/min Ndedoyl Iu Espfx Aqxec Pallet size: 400x400 mm Spindle speed: 8,000 rpm Tool holder: SK40 Machine weight: 11,000 kg

Year of construction: 2007, condition: excellent (used), X AXIS: 762 MM Y AXIS: 560 MM Z AXIS: 460 MM SPINDLE SPEED: 15,000 RPM SPINDLE CONE: BT 40 TABLE DIMENSION: 460 X 760 MM Njdpfjpyg Rkjx Aqxodc MAXIMUM LOAD: 400 KG RAPID FEEDS X/Y AXIS: 40,000 MM/MIN Z AXIS RAPID FEEDS: 32,000 MM/MIN WORKING FEED: 32,000 MM/MIN TOOL WAREHOUSE: 20 PLACES TOOL CHANGE TIME: 1.2 SEC – 3.8 SEC MAXIMUM TOOL WEIGHT: 8 KG MAXIMUM TOOL LENGTH: 300 MM CONTROL: OSP-P200M

Condition: used, Year of construction: 1990, spindle diameter 150 mm x-travel 4000 mm y-travel 3000 mm z-travel 1000 mm w-travel 1500 mm Table area 2000x2000 mm Table load 30 t Feed 3-3500 mm/min Rapid movement 5000 mm/min transmission ratio 2 spindle power 37 kW voltage 380 V frequency 50 Hz Control Heidenhain type ITNC mm The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More Ndedpeyqtf Tefx Aqxoc than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 700 mm, spindle speed (max.): 2,000 rpm, table length: 1,100 mm, table width: 842 mm, X axis: mm 1.000 Y axis: mm 700 Spindle travel: mm 300 Table dimensions: mm 1.100 x 842 Spindle speed: rpm 40 – 2.000 Spindle cone: MT 4 Max power: kW 10 Max loading on table: ton 1 Machine weight: ton 15 EQUIPPED WITH A LOT OF ACCESSORIES Nodpfxjzizgbs Aqxodc

Condition: used, Year of construction: 1971, Technical details: max. diameter of face turning: ca. Ø 900 mm revolution per minute: Spindel: 12,5 - 00 / 24 step U/min revolution per minute: Planscheibe: 8 - 190 / 12 step U/min Nodpfeu Idtpox Aqxsdc feed steps: Planscheibe: 0,03 - 3 / step rapid traverse: alle Bewegungen: 2000 / 4000 m/min tool taper: der Arbeitsspindel: ISO 50 / SK50 table clamping surface:: 700 x 800 table rotating: 360° Grad drill table adjustment: quer: 800 mm max. table load: 1500 kg total power requirement: ca. 11,0 kW weight of the machine ca.: 7800 kg dimension machine xH: 3,0 x 2,0 x 2,6 m dimensions electric cabinet: 1800 x 400 x 1950 mm Ø of the face plate 420mm Movement of the face slide 180mm largest Ø during facing approx. 900mm Longitudinal movement of the column 700mm Vertical movement of the headstock 700mm Feed drive of column, headstock and clamping table: -for spindle operation=0,20 - 10 mm/rev with 34 speeds -for operation with faceplate= 0,16 - 16 mm/rev with speeds Equipment: optical fine measuring device/measuring system for axes X/Y/Z/B-axis hydraulics machine feet/footplates control panel with boom *

Year of construction: 1989, condition: ready for operation (used), A Maho CNC 4-axis universal bed-type milling machine is available. Travel X/Y/Z: 1600mm/800mm/800mm, table dimensions X/Y: 1250mm/800mm, max. table load: 3000kg, spindle mount: SK50, main spindle speed: 4000rpm, power: 22kW. Tool positions: 36, max. tool diameter: 160mm/210mm, max. tool length: 315mm/400mm, max. tool weight: 15kg, feed rate: 4m/min, rapid traverse: 10m/min. Machine dimensions X/Y/Z: approx. 5000mm/3700mm/3000mm, weight: approx. 16000kg, control: Philips CNC 232. An on-site inspection is possible. Ndjdpsv Ubqnjfx Aqxec
