Servo press brake, die bending machine with 4-axis CNC control, electrically driven press brake mach

SAFAN SMK-P 50-2550 TS1

Servo press brake SAFAN Type SMK-P 50-2550 TS1

Downstroke bending machine with 4-axis CNC control
Serial No. MK 285 Year of manufacture: 1998
CNC control SAFAN software version 5.07 TS1
Hedsxpqy Dspfx Amgon
Press force: 500 kN (50 tons)
Working length: 2550 mm
Stroke: 215 mm
Clearance between side frames: 2700 mm
Tool installation height: max. 414 mm
Table width: 55 mm
Table height above floor: 950 mm
Approach speed: approx. 75 mm/s
Return speed: approx. 75 mm/s
Working speed: approx. 1.6 to 15 mm/s
Motor power: 9 kW
Power supply: 400 Volt, 50 Hz, 9 kW
- 4-axis CNC control SAFAN software version 5.07 TS1, Y1 and Y2 axis for ram
- 2-axis backgauge, X-axis (backgauge depth adjustment), R-axis (backgauge height adjustment)
- 2 backgauge fingers, laterally adjustable by hand (Z1, Z2)
- Ram drive via 2 servomotors and belt drive
- Working speed steplessly adjustable
- Operation via electric foot switch and/or two-hand control panel
- 13 clamping holders for the upper tool (UKB system, type 50.571, UKB System A)
- Tool holder for lower tool, 55 mm wide with 13 mm groove, 21 mm groove depth (Trumpf system or UKB System B)
- Supplied without bending tools (a new set from UKB costs approx. 3,600 EUR net)
- Displayed total operating hours = 8,120 h
- Number of working strokes: 1,049,789 strokes
Space requirements (L x W x H): 3450 x 1850 x 2650 mm
Weight: 5,000 kg
Good condition
