SEMI AUTOMATICCASE MAKER MACHINE

SAMED DARIX EVOLUTION LIGHT

Condition: good (used), Year of construction: 2016, DARIX EVOLUTION LIGHT Semi-Automatic Case Maker Year/Model: 2016 Knodpfxowzh Ife Afpjc Minimum size (open case): L 190 mm, H 160 mm Maximum size (open case): 460 x 900 mm Minimum board thickness: 1.5 mm Spine width: Min 6 mm, Max 100 mm Overlap of covering material: Min 6 mm, Max 30 mm Maximum board thickness: 6 mm - Capability to process varying board thicknesses on the same cover Cover material range: 80 to 400 g/m² Cover material thickness: 80 to 400 g/m² Glue tank capacity: 5 kg for hot animal glue (cold glue only for lining works) Net weight: 1,400 kg Gross weight: 1,600 kg Electrical supply: 400V, 3-phase, 50/60 Hz Glue heating timer: Programmable ON/OFF for glue heating Power consumption: 6 kW Compressed air: 6 bar, 100 L/h Central lighting: Always included Condition: Very good Availability: Immediately Additional features of the DARIX EVOLUTION LIGHT compared to the Darix Standard: - Equipped with a second turning-in station arranged at a right angle to the first unit. - After the head and foot sides are turned in, the cover is conveyed to the right to turn in the remaining two sides. - This system allows one product to clear the first unit as the next cover is produced, increasing overall efficiency. - Vacuum belts on the feed table ensure accurate positioning and precise movement of the case, achieving a working speed of up to 4 cases per minute. - Optional: Automatic viscosity control system for the glue. The touchscreen display continuously monitors glue viscosity and automatically adds water to guarantee consistent gluing quality without the need for operator intervention.
