Schenk plate filter

Schenk

Condition: excellent (used), Here, we offer you an inspection system for crystalline silicon solar modules. Reliable quality assurance and process control throughout the entire solar module production. The Dr. Schenk SolarInspect series was developed to meet the specific requirements in the production of crystalline silicon solar modules. These ready-to-use vision systems provide reliable quality control for the entire ongoing production process. Furthermore, continuous monitoring of the production process allows for timely corrective measures to be taken in the event of process deviations. In the production of crystalline silicon solar modules, textured glass substrates are used instead of uncoated glass. Textured glass increases the transmission of sunlight. The optical signals in the vision system, triggered by the surface structure typically used for glass substrates in silicon solar modules, are often similar to or even stronger than those of the actual defect being inspected. Dr. Schenk has developed and manufactured SolarInspect, a system that specializes in the precise differentiation between glass structure and defects on the entire material surface, including the edges. Thanks to an innovative optical design, Dr. Schenk's inspection system can clearly detect glass defects and distinguish them from the glass structure. Reliable inspection of: - Uncoated incoming glass - Uncoated textured glass - Coated glass, e.g., AR (anti-reflective) coated - Layer application - Finished modules Detection of: - Sheet glass defects, e.g., bubbles, inclusions, scratches - Dimensions - Edge defects - Layer defects, homogeneity and thickness of AR-coated glass SolarInspect - Exceptional performance features: - Innovative and modular optical design - Low operating costs - Ready-to-use vision systems optimized for specific process step requirements - Customized solution for all types and sizes of solar modules - Repeatable detection and evaluation - User-friendly quality and analysis tools for production control and process analysis - Easy integration into new and existing lines - Industrially proven design Type: SolarInspect Condition: used Sale is ex works. Scope of delivery: (See image) (Changes and errors in technical data and specifications are subject to change!) Hnsdpjzdtgiefx Ap Hen We will gladly answer any further questions you may have by telephone.

Year of construction: 1987, condition: good (used), functionality: fully functional, machine/vehicle number: RMUW2258, Horizontal balancing machine, manufacturer: SCHENK, type: H30, year of manufacture: 1987, serial number: AHE1070, rotor weight: 3-320 kg, rotor diameter: max. 1,260 mm, journal diameter: 10-160 mm, speed infinitely adjustable. Hnodpfxey S Tyno Ap Hjn Control system: CAB 820, year of manufacture: 2021, serial number: RMUW2258.

Year of construction: 1983, condition: refurbished (used), functionality: fully functional, machine/vehicle number: 1470, KIESELGUHR FILTER SCHENK TYPE ZHF S50 Type: ZHF S 50 Year of construction: 1983 Material: Stainless steel (V4A) 1.4541 Hnodjtqf A Eepfx Ap Hsn Boiler: Capacity: 3100 liters Permissible operating pressure: 6 bar Permissible operating temperature: 20°C Boiler room: 28 segment clamp screws Dimensions: Volume 3100 L Length 4900 mm Width 2400 mm Total height 4100 mm Last use: Food (brewery) Technical documentation: Yes

Year of construction: 1977, condition: refurbished (used), functionality: fully functional, machine/vehicle number: 1124, KIESELGUHR FILTER SCHENK TYPE ZHF S50 Type: ZHF S 70 Year of manufacture: 1977 Material: Stainless steel (V4A) 1.4541 Boiler: Capacity: 4300 liters Permissible operating pressure: 6 bar Permissible operating temperature: 20°C Hedstqf A Repfx Ap Hjnn Boiler room: 28 segment clamp screws 78 strainers Dimensions: Volume 4300 L Length 4200 mm width 2200 mm Total height 4800 mm Last use: Food (brewery) Technical documentation: Yes

Year of construction: 1979, condition: used, Centrifugal high-performance kieselguhr filter with buffer tank, kieselguhr dosing vessel and peristaltic pump. Hnodpjvcqmbsfx Ap Hsn Additional title: Kieselguhr filter Capacity approx.: 110 hl/h Vessel volume: 1550 l Operating pressure: 9 bar Operating temperature: 100 °C Operation / Control: Control cabinet with operating buttons Material: Stainless steel Features: Kieselguhr dosing vessel, 14,26hl; hose pump Periphery: buffer tank, vessel

Year of construction: 1985, condition: used, Sheet filter with square filter elements hanging vertically, arranged row. Hydraulic filter sheet press. Control of the hydraulics from the built-in electrical control panel. Additional title: Sterilisation filter Operating pressure: 8 bar Number of plates: 100 pcs Plate area: 1 m2 Length: 5,5 m Width: 1,5 m Height: 2,3 m Operation / Control: Control cabinet with operating buttons Material: Stainless steel Hnjdpfxow Tmtio Ap Hsn Base construction: Frame Features: Hydraulic press; control panel

Condition: used, Combi filter (kieselgur- and sterilising filter) for beer filtration with hydraulic pressure, 100 x 100 cm filter plates and external risers. Hsdpjvcqlwsfx Ap Henn Additional title: combination filter Capacity: 120 hl/h Plate size: 100 cm edge length Length: 7000 mm Width: 1500 mm Height: 1500 mm Position: horizontal Base construction: mounted on steel frame, standing on feet Features: 31 kieselguhr layers (32 frames), 50 sterilisation layers, 4 pressure manometers (10bar), 6 lanterns, risers, kieselguhr discharge screw (Allweiler), gravity measurement, flow measurement, 3 x turbidity measurement (inlet, outlet Kieselgur filter, outlet 3 x turbidity measurement (inlet, outlet kieselgur filter, outlet sterilisation filter). Spare parts: 295 sealing rings for filter plates, 3 kieselguhr filter support plates

Year of construction: 1975, condition: used, Filter system constructed with horizontally stacked filter elements. Once filtration is completed the kieselguhr is expelled from the vessel by centrifugal force. Capacity: 140 hl/h Vessel volume: 26 hl Length: approx. 4000 mm Width: approx. 2000 mm Height: approx. 3500 mm Material: Stainless steel1.4541 (vessel) Base construction: on feet Features: Kieselguhr dosing vessel with dosing pump; pumps; fittings, measurement technology Hnodsvcqpcopfx Ap Hjn

Condition: used, Year of construction: 1974, Combination Kieselguhr and Sheet filter. Stationary sheet filter with square filter elements in vertical row arrangement. Capacity: 60 hl/h No. of plates - KG Filter: 34 Plates No. of frames - KG Filter: 35 filter frames No. of plates - sheet filter: 150 Plates Length: 6500 mm Width: 1000 mm Height: 1500 mm Formats: Quadratic filter elements - 60 cm x 60 cm Base construction: Frame Features: Manual filter element compression Periphery: Kieselguhr dosing unit with dosing pump Layer patterns: Vertical filter elements in a row Hnjdpfx Aoxbpdlep Hon

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, input voltage: 400 V, compressed air connection: 8 bar, input current: 25 A, input frequency: 50 Hz, power: 8 kW (10.88 HP), SCHENK - CAROUSEL PRINTER VARIPRINT SPIDER V2002 TYPE EX 8/12 ER - electric servo rotary drive - electric servo lift drive for screen relative to the pallet - electric servo squeegee carriage drive 1. Specifications: • production year: 2012 • 12 stations (pallets) • 10 automatic printing mechanisms • print format: 600 x 850 mm (1100 x 850mm with double indexing) Hedpfxoy Iybkj Ap Honn • machine diameter: 5,760 mm • 15 aluminum sandwich pallets: 420 x 700 mm • 12 aluminum sandwich pallets: 550 x 750 mm • 12 squeegees: 400 mm with 40 x 8 mm rubber, 65/800 Shore 2. Power Requirements: • electrical: 400V, 50/60 Hz, 25A • compressed air: 8 bar, approx. 3m³/h per printing mechanism 3. Standard Features: • 13” TOUCHSCREEN display • microprocessor control • 6 basic programs tailored for printing with plastisol inks, water-based inks, and HD printing. Program for pallet heating. • electric lift system – allows electronic adjustment of the distance between the pallet and the screen from the control panel • HD Program – e.g., for high-build printing • function for printing eco-friendly bags • excess ink removal function • pallet rotation functions: 1/2 and double indexing • independent adjustment of screen-to-pallet distance for each printing station • mini controls on each printing arm precision screen alignment system with scale markings • printing accuracy: +/- 0.025 mm • pneumatic adjustment of squeegee pressure (printing/flooding) • SKIP function to skip pallets with improperly placed items • “Replay” program – allows repeated intermediate drying of a base coat using a single dryer • “MIX” program – enables automatic arm selection and setting screen-to-pallet distances programmed over four rotations • accelerated Program 3 for multiple printing: • program for transfer printing (pendulum mode for 3 pallets) • variable pallet rotation direction (right/left) • ability to program each arm with a different printing program • liftable printing arms: so-called open station 4. Additional Features: • side screen loading • pneumatic and manual screen locking • manual adjustment of squeegee angle • printing speed: up to 1,000 cycles/hour Additionally: flashline dryer - 3 pcs.
