SCHIESS FB 225

Year of construction: 1987, condition: ready for operation (used), A CNC travelling column boring and milling machine Schiess is available. Travel X/Y/Z: 10500mm/5000mm/1200mm, quill stroke: 1250mm, quill diameter: 225mm, speed: 750rpm, spindle power: 100kW, spindle torque: 18000Nm, tool holder: SK50/SK60. Machine dimensions: approx. 17000mm/11000mm/8400mm, controls: Siemens 850M. Without platen field. Documentation available. An on-site inspection is possible. Bodpexrf Ibofx Abmoww

Condition: used, Year of construction: 1986, spindle diameter 225 mm x-travel 21900 mm y-travel 6000 mm z-travel 2450 mm table dimension - longitudinal 4500 mm table dimension - cross 4500 mm table load 140 t floor-plate length 6000 mm floor-plate width 2000 mm floor-plate height 400 mm no. of tables 9 V-axis 2450 mm control SIEMENS 840D spindle turning speed range 800 U/min spindle taper ISO 60 / 50 table rotating 360 ° ram head dimension 550 x 460 mm w-axis 1200 mm z-axis 1250 mm total power requirement 100 kW dimensions of the machine ca. 25 x 7 x 11,5 m This SCHIESS FB225 panel boring machine has: - 9 plate fields each with LxWxH: 6000 x 2000 x 400mm - 1 turntable with 4500 x 4500mm and 140ton table load The machine can be inspected under power by arrangement with the seller. X-axis travel: 21900mm Y-axis travel: 6000mm Z-axis, drilling spindle stroke: 1250mm W-axis, headstock stroke: 1200mm (cross section: 550 x 460mm) V-axis, table travel: 2450mm 4 Types of milling heads • Planing head • Angular head with 90° tilting capability • Universal angular head with dual tilting axes Bwodpfx Aowx R Tlsbmsw • Angular head with extension for making grooves in smaller diamet ers

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, travel distance X-axis: 21,900 mm, travel distance Y-axis: 6,000 mm, travel distance Z-axis: 1,250 mm, spindle speed (max.): 800 rpm, spindle diameter: 225 mm, table load: 140,000 kg, swivel angle C-axis (max.): 360 °, TECHNICAL DETAILS Bwodpfx Abswm Dnljmjw Travel paths X-travel: 21,900 mm Y-travel: 6,000 mm Z-travel (drill spindle stroke): 1,250 mm W-travel (headstock stroke): 1,200 mm V-travel (table travel): 2,450 mm Control system: SIEMENS 840D Table Rotary table dimensions, longitudinal: 4,500 mm Rotary table dimensions, transverse: 4,500 mm C-axis: 360° Table load: 140 t Number of workbenches: 9 Dimensions per workbench (L x W x H): 6,000 x 2,000 x 400 mm Spindle Spindle diameter: 225 mm Spindle speed: 800 rpm Spindle mount: ISO 60 / 50 Ram dimensions: 550 x 460 mm MACHINE DETAILS Total power requirement: 100 kW Space required approx.: 25 x 7 x 11.5 m EQUIPMENT - 9 platen bays, each measuring 6,000 x 2,000 x 400 mm - 1 rotary table measuring 4,500 x 4,500 mm with a table load capacity of 140 t - SIEMENS 840D control system
