Flanging dishing Schleiffsten KBmL 3012

Schleiffstein KBmL 3012-300

Condition: used, Year of construction: 2004, Technical details: throat: 510 mm working pressure: 250 bar Punching capacity: 1000 kN t round bar steel: bis Ø 65 x 12 und bis Ø 90 x 8,5 mm electr. connected load: 400V / 50Hz total power requirement: 7,5 kW weight of the machine ca.: ges. 2,6 t dimension machine xH: 1,9 x 1,0 x 2,1 m dimensions L x W x H: Wkz.-Schrank: 0,7 x 0,35 x 0,9 m hydraulic section steel shear Heavy-duty, robust electro-hydraulic hole punch with large throat depth -Punching device: punch holder with punch quick-change device up to Ø 31 mm, stripper size L: 360 x W: 300 mm -Punching table: LxW: 360 x 300 mm, punching support 360 x 300 mm with adjustment device and die holder Ø 50 x 25 mm (equipped with die Ø 16 mm) Number of strokes: -with 10 mm stroke = up to 45 strokes/min. -with 30 mm stroke = up to 22 strokes/min. -with 50 mm stroke = up to 14 strokes/min. Punching stroke: min. 10 mm and max. 50 mm Stroke length and stroke position adjustable Equipped with punch Ø 16 mm Nodpfju Ick Tex Abzsld Foot switch The punching capacities refer to a material strength of 400 N/mm². Accessories: Various punching tools Punches and dies i.D. *

Condition: good (used), overall weight: 13,000 kg, total width: 2,200 mm, total length: 8,000 mm, total height: 3,300 mm, Flanging and dishing machine BOLDRINI - RIBO 20HY/4000 BOLDRINI RIBO 20HY/4000 Hydraulic Flanging & Dishing Machine. Capacity up to Ø 4,000 mm. Suitable for manufacturing dished ends, pressure vessel heads and tank bottoms. Nljdpfx Abozil H Eozsd Length:8000mm Width:2200mm Height:3300mm Weight:13000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: like new (used), functionality: fully functional, COFMO punching press, type KD 2128, capacity 63 tons, table 800x560 mm, ram 450x320 mm, stroke 10/100 mm, variable speed from 60 to 160 strokes per minute, ram adjustment 80 mm. Machine supplied with certificate of conformity and complete documentation. Can be inspected in good working condition. Nljdjxxrvfjpfx Abzjd

Condition: excellent (used), Year of construction: 1979, functionality: fully functional, Description 100 TON C FRAME PRESS WITH BOTTOM FORCE BACK UP 40 TON Machine is great working condition, was overhauled cilinder, sealings. AWAILIBLE 3 MACHINES BOTTOM FORCE 40 TON Specifications Manufacturer MULLER 100T Model CEZ 100 Year 1979 Condition Used Press force 100 TON Travel up doen 0-560mm Travel bottom up 0-200mm Power 15Kw Njdpfxovldxij Abzsld

Year of construction: 1989, condition: used, functionality: fully functional, Lot of used machine tools Nledpfx Aezg E Hyebzsd TRANSPORT TO BE AGREED UPON DURING PURCHASE or QUOTATION: -MT180 TRI-PHASE LATHE -INGERS 175 tri-phase LATHE -LEGOR 300 tri-phase -ANSELMI 180 tri-phase LATHE -Idroming 600 (DRM) - GRINDING MACHINE -BERGONZI FS 870 RADIAL DRILLING MACHINE -FRESA Prvomajska 1 -FRESA Prvomajska 2 -SERRMAC RAG 25/L tri-phase COLUMN DRILLING MACHINE -ITALERI Tri-phase COLUMN DRILLING MACHINE -BIMARK MOD. 30 Tri-phase COLUMN DRILLING MACHINE -Fratelli Rosa Milano tri-phase COLUMN DRILLING MACHINE -Mola Salmoiraghi tri-phase Technical details for each machine are shown in the photos. Transport costs to be determined during the quotation process. For any information, please do not hesitate to contact us. Machines intended for countries outside the EU.

Year of construction: 2013, condition: ready for operation (used), pressing force: 163 t, stroke length: 700 mm, Hydraulic 4-Column Press manufactured in 2013. This Hymag HS 4 160-K features a press force of 1,600 kN and a stroke of 700 mm, making it suitable for metal pressing and forming applications. With a main motor power of 55 kW, this machine is designed for efficiency and reliability. If you are looking to get high-quality metal pressing capabilities, consider the Hymag HS 4 160-K machine we have for sale. Contact us for further details. • Manufacturer: Hymag • Machine Type: Hydraulic 4-Column Press • Application Type: Metal Press / Forming Press • Hydraulic Pressure: 305 bar • Main Motor Power: 55 kW • Voltage: 400 V • Current: 105 A • Secondary Motor Power: 7.5 kW • Voltage: 400 V • Current: 15 A • Cooler Motor Power: 1.5 kW • Voltage: 400 V • Current: 5.1 A • Oil Capacity: 600 L Nsdpfx Ajzd Ezlobzjld

Condition: refurbished (used), Year of construction: 2020, functionality: fully functional, power: 4 kW (5.44 HP), pressing force: 80 t, stroke length: 60 mm, Power: 80 Ton Table size: 680 x 540 mm Strokes per minute: 60/min. Nsdpfszbvvvjx Abzsld Stroke: 60 mm Throat depth: 275 mm Gap in bed: 150 mm Controll: 2- hand controller Country of origin: Netherlands Motor power: 4 kW Machine (L×W×H): 175 x 100 x 235 cm Machine weight: 3700 kg

Year of construction: 2008, condition: ready for operation (used), pressing force: 163 t, stroke length: 700 mm, Hydraulic 4-Column Press manufactured in 2008. This Hymag HS 4 160 features a press force of 1,600 kN and a stroke of 700 mm, making it suitable for metal pressing applications. It is equipped with a PLC-controlled system for enhanced operation. If you are looking to get high-quality metal forming capabilities, consider the Hymag HS 4 160 machine we have for sale. Contact us for further details. • Manufacturer: Hymag • Machine Type: Hydraulic 4-Column Press • Hydraulic Pressure: 280 bar • Main Motor Power: 55 kW • Voltage: 400 V • Current: 96 A • Secondary Motor Power: 7.5 kW Nledpfjzd Ez Eox Abzsd • Voltage: 400 V • Current: 15 A • Oil Capacity: 600 L • Control System: PLC-Controlled Hydraulic Press
