Press punching machine punching press

Schuler PE4s 50/800

Condition: used, Year of construction: 2008, operating hours: 13,000 h, functionality: fully functional, The Bruderer BSTA 500-110B is a 500 kN Swiss-built high-speed stamping press, fitted with a BSV 75T double servo feeder for precision two-track strip feeding. Capable of up to 750 strokes per minute with B2 touch-screen control. Nominal force: 500 kN (50 tons) Year of manufacture: 2008 Stroke rate: 100–750 spm (variable) Adjustable stroke: 19 / 25 / 34 / 43 / 51 / 57 / 64 mm Ram height adjustment: 64 mm Press table area: 1080 x 650 mm Control: B2, IPC-based touch-screen press control, programmable memory for fast retooling BSV 75T DOUBLE SERVO FEEDER Type: tandem dual-feed servo unit, independently controlled tracks Max. strip width: 70 mm per track Max. material thickness: 2 mm Feed length: variable, freely programmable Feed angle: variable Pilot release angle: variable Iiedpfx Ajzh Nnwjqcog No clamping/gripper bars — strip held by driven feed rollers during stamping Designed for parallel advancing of two strips or feeding pre-profiled/pre-stamped strip

Condition: refurbished (used), Year of construction: 1985, functionality: fully functional, Completely overhauled BRUDERER high-speed stamping press BSTA125 incl. new press control system Technical data: Tonnage: 1250 kN Tooling opening: 1170 mm Strokes per minute: 100–850 SPM (depending on selected stroke) Adjustable stroke: 16, 19, 26, 35, 43, 51, 58, 64, 70, 75 mm Ram adjustment range: 89 mm Tool installation height: 268–386.5 mm (depending on selected stroke) Bolster plate: 1150 x 1070 mm Ram area: 1040 x 600 mm Strip pass width: 440 mm Base plate opening: 1120 x 350 mm Iijdpjy D H H Eofx Aqcog Strip entry height: 80–180 mm Strip feed direction: left to right Feeder: servo feed

Condition: used, Year of construction: 2004, functionality: fully functional, machine/vehicle number: 1002570003, total height: 3,450 mm, ram adjustment: 80 mm, installation height: 270 mm, table height: 1,280 mm, total width: 1,700 mm, total length: 3,065 mm, drop-through hole in table: 210 mm, table length: 1,500 mm, table width: 750 mm, pressing force: 63 t, control cabinet height: 2,200 mm, control cabinet length: 1,800 mm, control cabinet width: 600 mm, stroke adjustment: 80 mm, clearance between the columns: 1,540 mm, working width: 1,500 mm, distance between side stands: 360 mm, distance between stands: 2,020 mm, overall weight: 17,000 kg, punching force: 63 t, RASTER punching system RST 630-1500 DH with soundproof enclosure and tool monitoring. The machine is in good condition. Stroke rate: 30 - 700 1/min. Operated in single-shift operation. The machine can be inspected under power. Price on request. Iiedpfx Aqsyyppbjcjg

Condition: used, Year of construction: 1994, operating hours: 28,000 h, functionality: fully functional, The Bruderer BSTA 80H is an 80-ton high-speed stamping press built for heavy-duty progressive-die production, fitted with a BBV 320/200 strip feeder and Unidor tool monitoring. In stock in Pforzheim, ready for inspection. Nominal force: 800 kN (80 tons) Tool monitoring: Unidor Stroke rate: 100–1,000 spm Strip feeder: Bruderer BBV 320/200 Adjustable stroke: 16–63 mm Clamping plate area: 970 mm Main drive: 43 kW Power supply: 380 V / 50 Hz Ram area: 760 x 510 mm Table area: 950 x 910 mm Strip inlet height (adjustable): 80–180 mm Max. strip width: 360 mm Max. material thickness: 3 mm Machine dimensions: 2834 x 1742 x 3460 mm Weight: approx. 15,550 kg Operating hours (main drive): approx. 28,067 h Iiodpszibtbofx Aqcsg More machines from brands Bruderer, Bihler, Soprem, Noxon, Huras, Schaal and Mabu on stock available on request

Condition: used, Year of construction: 1995, operating hours: 42,000 h, functionality: fully functional, machine/vehicle number: 10317, The BSTA 50UL is a Bruderer high-speed precision stamping press rated at 500 kN (50 tons) nominal force, engineered for continuous progressive-die production at variable stroke rates from 100 to 1,120 strokes per minute. The press is equipped with a Bruderer BBV 202/120 strip feeder, delivering strip widths up to 203 mm and handling material thicknesses up to 2 mm. Adjustable stroke is set between 16 and 51 mm, with strip inlet height adjustable across a 50–140 mm range to accommodate varying tooling and material profiles. Nominal force: 500 kN (50 tons) Tool monitoring: Unidor Stroke rate: 100–1120 strokes per minute (variable) Strip feeder: Bruderer BBV 202/120 Adjustable stroke: 16–51 mm Mounting space / clamping plate: 760–940 mm Main drive: 22 kW Power supply: 400 V / 50 Hz Table area: 940 x 580 mm Strip inlet height (adjustable): 50–140 mm Max. strip width: 203 mm Max. material thickness: 2 mm Machine dimensions: 3100 x 2700 x 1800 mm Weight: approx. 8,150 kg Operating hours: 42,416 h Iiedszibrqspfx Aqcjg Sound-insulating cabin available on request More machines from brands Bruderer, Bihler, Soprem, Noxon, Huras, Schaal and Mabu on stock available on reqest

Condition: refurbished (used), Year of construction: 2027, pressing force: 60 t, Machine made to order: High speed press BSTA 60 Retrofit and general overhaul. Conversion to electronic drive und new Unidor PC-control system. Tool area enlargement possible. Iisdpfx Ajzlqlfoqcsg Please contact us for detailed offers.

Condition: refurbished (used), Year of construction: 2027, pressing force: 50 t, Machine available to order (made-to-order): Fully reconditioned B500-950 high-speed automatic stamping press Table length 950 mm (optionally 1150 mm or 1250 mm available), Adjustable stroke 16 to 51 mm, A servo feed can be installed as an alternative to the Bruderer BBV 202/120 roll feed. Iijdozlqk Uopfx Aqcsg Contact us for detailed quotations.

Condition: reconditioned (used), Year of construction: 1996, pressing force: 50 t, stroke length: 51 mm, Bruderer BSTA 50USL - Tool loading area 1100mm L-R Iedezlqgiopfx Aqcjig - Machine under refurbishment, with new controls, - Roll feed BBV or optionally servo feeder available Please contact us for a detailed quotation!

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, punching force: 25 t, Bruderer BSTA 250-75B with BBV 190/85H - B-Control, year of mfg. 2006 - Tool area 750mm Iodpfx Ajzlqhmjqceig - Adjustable stroke 13 to 38mm - complete documentation - Machine checked, in very good condition! contact us!

Condition: used, Year of construction: 1983, Bruderer BSTA 50 HL with BBV 202/120 Available, delivery time on request CE conversion possible. Contact us! Iijdpfx Aqjzlqg Ajceg
