Inclined Spindle Milling Machine

SCM

Condition: ready for operation (used), Year of construction: 2016, machine/vehicle number: AA2/004582, functionality: fully functional, operating hours: 14,500 h, travel distance X-axis: 3,120 mm, travel distance Y-axis: 1,320 mm, number of axes: 5, TECHNICAL DETAILS X-axis travel: 3,120 mm Y-axis travel: 1,320 mm Bdsdpfjy Akr Aox Ad Asb Number of axes: 5 MACHINE DETAILS Operating hours: approx. 14,500 h EQUIPMENT Suction pads Mounted air-blow nozzle Newly installed control unit Note: The machine has already been dismantled by the manufacturer.

Condition: used, Year of construction: 2011, AXES Working Range X-Y-Z Axes * mm 3050-1300-180 Workpiece length for pendulum operation mm 1390 Stroke X-Y-Z Axes mm 3460-1735-250 Max. traverse speed of X-Y axes m/min 60 WORK TABLE Bdedjyymz Uepfx Ad Aob Number of workpiece supports and vacuum cups 6 / 2 standard type Standard end stops / position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles std/quantity/speed 1/min 12 (8X-5Y) / 4000 Horizontal spindles std/quantity/speed 1/min 6 (4X-2Y) / 4000 Integrated grooving / saw unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Motor power std./opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer traveling with unit carrier in X 4 places, pneumatic INSTALLATION Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction connection diameter mm 150+150 (200) Machine weight Kg 3000 * X: distance between stops; Y: milling center as reference point; Z: workpiece passage GENERAL FEATURES CNC-controlled drilling and milling center, C-frame design, and worktable with adjustable workpiece supports and vacuum suction cups, for: - Vertical drilling on the panel surface - Horizontal drilling on all four workpiece sides - Groove milling with disc cutter in the “X” direction - General milling work Self-supporting structure and work table Structure made from welded steel construction with control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV carrier options. Box construction made from cold-rolled steel with internal stiffening ribs and protective devices comprising a drilling head with vertical spindles, horizontal spindles, an integrated grooving and saw unit, and an SCM electrospindle with HSK 63 F quick-change tool system. Movement paths of the portal and unit carrier Movement in the X, Y, and Z axes is via linear prismatic guideways with preloaded ball bearings. The X-axis movement (moving gantry) uses a preloaded, backlash-free rack-and-pinion drive with helical gearing. Movement of the unit carrier in Y and Z directions is also preloaded for precision. Positioning of the working units and machine function control is through "brushless" AC servo motors and digital drives. CNC CONTROL The control unit comprises a numerical control for the milling and drilling machines and a PC with a graphical user interface "XILOG PLUS". PC office operating system Windows XP - 17" LCD color screen - QWERTY keyboard - Swiveling control panel - Machine interface: Xilog Plus software Xilog Plus Features Programming - Parametric, graphical, and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation on three axes, spatially linear, spirally on selected plane - Supported programming with graphical and syntax assistance for drilling and milling operations - Automatic optimization of drilling operations and tool change cycles - Possibility to shift panel zero point for drilling on slanted or curved panel sides - Full compatibility with CAD/CAM Routocam (SCM) – AlphaCam Integrated additional functions - Calculator for direct transfer of computed data - S

Condition: excellent (used), Year of construction: 2000, machine/vehicle number: AB /139622, functionality: fully functional, input frequency: 50 Hz, pivoting range: 56 °, rotational speed (max.): 10,000 rpm, rotational speed (min.): 3,300 rpm, Equipment: CE marking, rotational speed infinitely variable, We are offering this well-maintained SCM T 150 Class spindle moulder, year of manufacture 2000. Description: Spindle moulder with 3-axis control and 999 program memory slots (spindle height, fence, spindle tilt, revolutions) Spindle tilt -10° to +46° Inverter motor, adjustable spindle speed from 3,300 to 10,000 rpm Table extensions at front and rear Swivelling fence Clearance between cutter and table is adjustable Very good condition, minor signs of use Including accessories: • 5 additional SK40 quick-change spindles • Curved fence • Power feeder with stand • Various hand tools Bdodpfxoy Ir Eze Ad Ajb If you have any questions or require further information, please feel free to send us a message or call us.

Condition: used, Year of construction: 2009, functionality: fully functional, overall weight: 452 kg, Surface Planer/Thicknesser, Planer TECNOMAX FS 41 elite – after technical inspection, ready for operation Specification: • Condition – used, after comprehensive technical inspection • Manufacturer – TECNOMAX (SCM Group) • Model – FS 41 elite • Working width – 410 mm • Thicknessing working height – 240 mm Bsdpjy Inuxofx Ad Aodb • Table length – 200 cm • Sound-dampening combs at the cutter block • 3.0 kW motor • 3-knife cutter block for traditional blades • Extraction port diameter 120 mm • 2 feed speeds (6 and 12 m/min) • Original paintwork • Weight – 452 kg • Year of manufacture – 2009 • Overall dimensions – 220 x 90 x 100 cm (L x W x H) Additional information: • The machine is in good technical condition, ready for immediate use • The photos shown represent the actual condition of the item for sale • Possibility to power up and test the machine on site • The auction price does not include VAT or transport costs Financing and transport: • We organize transport via the MDD fleet, courier companies, or external carriers • We provide financial support in the form of leasing or lease loan options

Condition: used, Year of construction: 1995, Used machine Bdedpfx Adoy Ih S Rj Ajb Year of manufacture: 1995 Features and technical data: Versatile copy router with extremely short setup times, both when switching from manual operations to automatic processes and when changing between various automatic machining tasks. The automatic template feed (consisting of a central copying roller and a pressure roller) was developed by SCM to automatically guide workpieces mounted on a template past the milling tool. The automatic copying and pressure rollers can be removed within seconds, freeing the machine for custom and special manual jobs. Distance between tool axis and column: 915 mm Spindle stroke: 105 mm Table stroke: 180 mm Max. clearance between table and spindle: 300 mm Tool holder: MK 2 Spindle speed: 10,000/20,000 rpm Table dimensions with extensions: 1510 x 1170 mm Motor power: 4 kW Template feed motor power: 0.14 kW Template feed speed: 1.5–12 m/min Number of adjustable turret depth stops: 6 Dimensions (approx.): 1690 x 1100 x 1890 mm Weight: 650 kg Availability: short-term Location: 63934 Röllbach

Condition: used, Year of construction: 2002, Used machine Bdedpfx Asy Ih T Ijd Aeb Year of manufacture: 2002 Features and technical data: 1. Unit with rubber-coated calibration roller Hardness 85 Sh, diameter 120 mm 2. Combination unit equipped with a rubber-coated sanding roller Hardness 85 Sh, diameter 120 mm, and with a hard sanding shoe electronic sanding belt oscillation motorized thickness table adjustment digital display for working height rubber-coated pressure rollers at infeed and outfeed of each unit flexible steel pressure shoe at infeed 2 rollers at the infeed and outfeed of the conveyor belt automatic star-delta switching of the main motor Technical data: Working width: 950 mm Min. and max. working height: 4 - 170 mm Sanding belt width: 970 mm Sanding belt length: 1900 mm Motor: 7.5 kW Feed rate: 4.5/9 m/min Extraction connection: 2 x 140 mm Dimensions: 1400 x 1700 x 2000 mm Weight: approx. 1000 kg Availability: by arrangement Location: Baden-Württemberg

Condition: used, Used machine Features and Technical Data: Versatile copy router with extremely short setup times, both when switching from manual to automatic operations and when changing between various automatic processes. The automatic template feed (consisting of a central copying roller and a pressure roller) was developed by SCM to automatically guide workpieces attached to a template past the milling tool. The automatic copying and pressure rollers can be removed within seconds. This allows the machine to be available for single and custom manual fabrication. Distance between tool spindle and frame: 915 mm Spindle stroke: 105 mm Table stroke: 180 mm Bjdjy Ih S Depfx Ad Aedb Max. clearance between table and spindle: 300 mm Tool holder: MK 2 Spindle speed: 10,000/20,000 rpm Table dimensions with extensions: 1510 x 1170 mm Motor power: 4 kW Motor power template feed: 0.14 kW Template feed speed: 1.5–12 m/min Number of adjustable revolver depth stops: 6 Dimensions approx.: 1690 x 1100 x 1890 mm Weight: 650 kg Availability: short-term Location: 63934 Röllbach

Condition: used, Year of construction: 2000, Used machine Year of manufacture: 2000 Bodpfx Adey Ih Tue Asdb The T 110 is the spindle moulder from SCM, optimally combining quality and affordability. The construction is extremely robust. For convenient operation, all controls are arranged within easy reach on the front of the machine. Precise height adjustment of the tool is ensured by a mechanical display. Spindle tilting from -5 to +45 degrees. Table size: 1000 x 750 mm Spindle clamping length: 140 mm Spindle projection above table: 20 mm Spindle speeds: 3000-4500-6000-9000-10000 rpm Maximum diameter of tool retractable under the table: 320 x 40 mm Profiling tool max. diameter: 250 mm Motor: 4 kW Extraction nozzle: 120 mm Comes with 3-roller feed unit Weight: 520 kg Availability: short-term Location: Röllbach

Condition: used, SCM jointer, Italian made 4 traditional knives, wedge-clamped Table combs Bdsdsy Ifglepfx Ad Asb Width: 410 mm Table length: 2600 mm Angled, adjustable fence Brake Well-maintained machine, quiet operation

Condition: used, Year of construction: 2011, Base Machine M800 X5 TV 1 WORKING RANGE X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance Height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made from thick-walled steel. It is reinforced across the entire machine bed with welded components, providing exceptional stability. The table design, with its large base, is the key to ensuring lasting precision and stability. The machine’s layout enables the operator to achieve optimal workflow with minimal space requirements. The mobile gantry is built as a solid monoblock. It is positioned in the X direction on prismatic, ground guides with recirculating ball carriages. The machining unit is mounted on this mobile support carriage, also on prismatic, ground guides and recirculating ball carriages. AXIS MOVEMENT All axes travel on prismatic linear guides with large cross-section and recirculating ball shoes with a wide contact surface, which ensures optimal sliding, even at high speeds and accelerations. The precise and fast positioning of the movable gantry (X-axis) is achieved via helical rack and pinion. Large cross-section recirculating ball screws ensure accurate positioning of the machining unit along the movable gantry (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. Max. axis speeds: · X-axis = 90 m/min · Y-axis = 90 m/min · Z-axis = 30 m/min Safety device with bumper and light barrier 1 Bumpers with sensors are fitted to the movable upright, and a light barrier system is installed at the front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to a lower value of 25 m/min without stopping the machine. This system allows parts to be loaded during pendulum operation without the limitation of access areas, as seen with pressure mat systems. This prevents unwanted interruptions in the machining cycle and offers greater freedom of movement around the worktable. CE certification for the safety system 1 Safety protection fence 1 Side and rear protection fence Automatic central lubrication controlled via CNC 1 The lubrication of the X, Y, and Z axes is controlled by the CNC; intervals are regulated automatically, without manual intervention. Central extraction connector 1 All individual extraction connections of the machining units are collected into a central extraction port. Inside the port, there are various slider valves controlled by the NC. This reduces the required extraction air volume. Chip conveyor 1 Maxi – 5-axis electrospindle 11 kW HSK-63 “Prisma K 1 5-axis electrospindle, 11 kW at 20,000 rpm S1 (100% duty cycle) Speed: max. 20,000 rpm Rotation direction: left/right Liquid cooling Tool interface HSK 63F Inverter 18 kW, stepless, smooth power delivery Max. rotation B-axis = 200° (+-100°) C-axis = 650° Thanks to the non-orthogonal axes, it is possible to perform complex horizontal positioning in a small workspace. This enables the machining of complex geometries without the risk of collision. Bedpfxsxy Tmno Ad Ajdb
