Plate filter

Seitz - Werke GmbH

Condition: excellent (used), functionality: fully functional, REF: MM5465 1 x Seitz-Werke GmbH filling machine for bottles. Fed by counter-pressure tank. Manufacturer - Seitz-Werke GmbH Model - SF 12. Date of manufacture - 1961 (has been refurbished since). Speed - up to 1200 bph (depending on filling volume). Capacity - variable filling range (whatever bottle size fits into holders). Fsdex A A I Hspfx Afusgh Overall dimensions - 1100mm diameter x 2350mm H. Last used in March 2023.

Year of construction: 1988, condition: used, Module filter, free-standing with 4 stainless steel feet with adjusting screws Fgodpfsxwy U Hox Afush Volume: 197 l Operating pressure: 10 bar Max. operating temperature: 121 °C Length: 0,442 m Width: 0,442 m Height: 1,93 m Material: Stainless steel Base construction: standing on feet Features: Closure with 12 clamp screws; tank connections DN 50; with all fittings, pressure gauge Height of the sieve pipe: = 0.99 m; diameter of the sieve pipe 47 mm

Condition: used, Kieselguhr frame filter. Sterilizable universal filter for liquid filtration with kieselguhr. Stationary filter with square elements in a vertical row arrangement. Hydraulic filter sheet pressing with hydraulic control on the built-in electrical control panel. Additional title: kieselguhr filter, years of manufacture 1979 - 2010 Fsdpfx Aoxbn Ntjfuegh Capacity approx.: 850 hl/h Kieselguhr filter - filtration area approx. 174 - 242m2 Operating pressure: 8 bar Power: 6 kW Voltage: 220/380 V Frequency: 50 Hz Length: 10100 mm Width: 1320 mm Height: 1750 mm Formats: Square filter elements Operation / Control: Built-in control panel Material: Stainless steel Position: Horizontal Base construction: Frame Features: Filter plates; filter frames; collection tray with removal screw; hydraulik filter plate compression; hose pump Layer patterns: Vertical row arrangement

Year of construction: 1979, condition: used, Combination Kieselguhr and Sheet filter. Stationary sheet filter with square filter elements in vertical row arrangement. Hydraulic filter layer compression. Control of hydraulics from built-in electrical panel. Additional title: Kieselguhr and sheet filters as a combination design; years of construction 1979 Capacity approx.: 380 hl/h Combination filter - filtration area approx. 76 - 108m2 KG; 18m2 Sheet with beer filtration Fedpfx Afovcqn Ssuogh Operating pressure: 8 bar Power: 6 kW Voltage: 220/380 V Frequency: 50 Hz Length: 10100 mm Width: 1320 mm Height: 1750 mm Formats: Square filter elements Operation / Control: Built-in control panel Material: Stainless steel Position: Horizontal Base construction: Frame Features: Filter plates; Filter frames; collection tray with removal screw; hydraulik filter plate compression; hose pump Layer patterns: Vertical row arrangement

Condition: used, Sterilizable universal filter for sterilization filtration. Stationary sheet filter with square filter elements in a vertical row arrangement, hydraulic filter sheet pressure. Hydraulic control from built-in electrical control panel. Additional title: Sterilisation filter, years of manufacture 1979-2010 Capacity approx.: 750 hl/h Sheet filter - filtration area approx. 356 - 493m2 Operating pressure: 8 bar Power: 6 kW Voltage: 220/380 V Frequency: 50 Hz Length: 10100 mm Width: 1320 mm Fjdpfxsxbn N Ho Afujgh Height: 1750 mm Formats: Square filter elements Operation / Control: Vertical row arrangement Material: Stainless steel Position: Horizontal Base construction: Frame Features: Filter sheets; hydraulik filter plate compression; hose pump Layer patterns: Vertical row arrangement
