Control unit

Siemens

Condition: used, Tube bending machine, mandrel bending machine, bending machine for tubes and profiles Tube bending unit with SIEMENS servo motor and planetary gearbox Year of construction: 2003 Bending capacity: max. Ø 20 x 1 mm Bending radius: max. R 70 mm Bending angle: max. 200° - last used for round tube Ø 15.4 x 0.8 mm, R60 mm - Bending tools and bending jaws interchangeable - Bending tool drive via AC servo motor and Alpha spur gear, planetary gearbox - 2-part bending tool opens and closes via hydraulic stroke movement - MERKLE hydraulic round block cylinder, item 014445 for hydraulic tool opening - Pneumatic height adjustment of the bending jaw via Festo compressed air cylinder - without electrical control - without hydraulic unit Dimensions L/W/H 760 x 400 x 150 mm weight: approx. 60 kg good condition Removed from a functional special machine, tested before removal. Drive: Brushless permanent magnet servo motor SIEMENS Kjdped E A I Iofx Afvsdh Typ:1FK6061-7AF71-1EG0 Nominal torque = MO: 6.4 Nm Rated current = Io: 6.1 A Speed = n. max.: 5500 rpm - Brushless permanent magnet servo motor SIEMENS ----- 5 pieces available in right-hand version. 5 pieces available in left-hand version. The price quoted refers to 1 bending unit with servo motor. If required, we also sell individual assemblies of the bending unit. We also offer the electrical components for controlling the servo motor. We also offer hydraulic units.

Condition: used, Ball screw with SIEMENS servomotor Linear guide with permanent SIEMENS servomotor Type: 1FK6044-7AH71-1EG0 Type: 1FK7044-7AH71-1EG0 ID No. YF RN22 5076 01 001 Year of manufacture: 2003 Axis travel: 540 mm Total length: 900 mm Shaft diameter: 40 mm Lead: 40 mm Ball diameter: approx. 6 mm Kdsdjgi E Hdspfx Afvsh - Compact unit with servomotor and ball nut - Ball screw guided to prevent rotation, driven via nut - Ball screw Ø 40 mm (hollow shaft, inner diameter = approx. 22 mm) - Permanent-magnet SIEMENS servomotor Type: 1FK6044-7AH71-1EG0 (Serial No: ID No. YF RN22 5076 01 001) Total dimensions L x W x H: 900 x 200 x 330 mm Weight: 30 kg Good condition Removed from a fully functional special-purpose machine, tested before removal. 8 units available The stated price refers to 1 unit.

Condition: used, Transistor pulse inverter for three-phase feed drives with analog control, servo controller SIEMENS type Simodrive 610 6SC6101-3A-Z Fab. No.: A 822M103 Z = A30+A20+A18 Year of manufacture: 1989 The Simodrive 610 transistor pulse inverters have been developed to supply the 1FT5/1FS5 three-phase servo motors. The dynamic characteristics of these motors are to be used optimally. The pulse inverters can be used for a wide variety of tasks by equipping the power section accordingly. This flexibility is further increased by expansion modules for the power section. Supply voltage: 3 AC 50/60 Hz 165 Volt or DC 220 Volt Kdjdpjh D Syvofx Afvjh (suitable transformer: 380/165 Volt 5kVA (not included in delivery) Output voltage: 3 UC 200 Volt Efficiency: approx. 95 Number of feed axes: 4 Speed reference: +-10 volts Auxiliary voltage: 24 volts Relay contact for messages fault/ready for operation dimension WxHxD: 339 x 440 x 300 mm Weight: approx. 25 Kg The servo drive is still ready for operation in a Gildemeister GDM42. Further components from the Gildemeister you will find under stock numbers: 60343, 60347, 60348

Condition: used, DC main spindle drive, converter unit with digital control Simoreg V55 Spindle module, drive controller, rectifier, DC controller Manufacturer: SIEMENS Type: SIMODRIVE 6RA2725-6DV55-0 D380/60 Mreq-GdG6V55-3A0 Version: V55 basic unit Input voltage: 3 AC 380 V Input frequency: 50 / 60 Hz Input current: 49 A Output voltage: 380 VDC Output current: 60 A Rated power: 22 kW Dimensions (W x H x D): 270 x 260 x 290 mm Weight: approx. 25 kg The drive controller is still operational in a Gildemeister GDM42. The matching drive motor can be found under stock number 60347. Further components from the Gildemeister can be found under stock numbers: 60346, 60347, 60348 Kdodpfx Aoh D Syrsfvsh

Condition: used, Electric motor, E-motor SIEMENS three-phase motor, power motor Kjdjfifnispfx Afvjdh Type 3LE16012BB233GB4 Type V1 Frame size 225M Motor speed 1475 rpm Current consumption 84 amps Motor power 45 kW Mains connection 400 Volt, 50 Hz. Shaft diameter Ø 60 mm Shaft journal length 140 mm keyway width in the shaft 18 mm flange diameter 450 mm centering diameter 350 mm Bolt circle Ø 400 mm - flange motor with 8 mounting holes Ø 18 mm Overall length of motor housing without motor shaft 715 mm Overall length of motor housing with motor shaft 855 mm Space requirement L x W x H 855 x 450 x 570 mm dead weight: 320 kg very good condition - new, unused from stock clearance

Condition: used, Permanent magnet DC servo motor SIEMENS Type: 1 HU3074-0AC01-Z Kdjdpfx Asuch N Isfvjh NO.B J157 1047 01 008 Voltage = 167 Volt DC = direct voltage Power = 1.8 kW Current consumption = 12.5 amps Speed = n. max.: 2000 rpm Rated torque = Mo 7 Nm Shaft diameter 24 mm Stub shaft length 50 mm Centering diameter 130 mm Bolt circle diameter 165 mm / 4 x 11 mm holes - Shaft with 8 mm keyway Housing dimensions L/W/H 335 x 140 x 145 mm Weight: 23 kg good condition

Condition: new, power capacity / kW volt / V ampere / A Kjdpfxoyl Abye Afvodh SIEMENS SERVO MOTOR SERVO MOTOR 1FT6084-8AF71-4TA0 Condition: generalüberholt Weight: approx. 20kg

Condition: used, SIEMENS SIMODRIVE 6SN1145-1BA02-0CA1 + SIEMENS 6SN1111-0AB00-0AA0 Kdedpfx Afsyl Abtovjh VERSION A

Condition: used, Siemens 6SC6608-4AA00 control panel The parts were removed from production facilities that were in operation until they were decommissioned. Kjdpfeyl Abmox Afvjdh Condition: used (functional)

Condition: used, power capacity / kW volt / V Kjdpfx Ajyl Abajfvedh ampere / A SIEMENS 1PH7131-2NF02-0BC0
