Skoda W 200

Skoda Pilsen W 200

Condition: good (used), Year of construction: 1997, Ref. -No.: 10620 Manufacturer: SKODA Type: W 200 T Year of construction: 1997 Type of control: CNC-Steuerung Control: SIEMENS SINUMERIK 840 Storage location: Halberstadt Country of origin: Germany X-Travel: 16000 mm Y-Travel: 5150 mm Z-Travel: 1600 mm W-Axis: 2100 mm V-axis: 2000 mm Fjdpfx Akeyagidohogf B-Axis: 0 - 360 ° Spindle Diameter: 200 mm Table Load: 80.000 kg Tool Taper: SK 60 / SK 50 Turning Speeds: 1000 RPM Rotary table diameter: 3500 x 3000 mm Further information: Including angle head Machine can be inspected under power.

Condition: excellent (used), Year of construction: 1978, functionality: fully functional, I am selling this machine. It can be connected and tested under power. Very good condition. X 11,500; Y 3,150; Z 2,000; clamping system M 100. Fgedpfoxwl Tbex Akhof Includes support column, 6 plates sized 6,500 x 1,850 x 400 mm. Rotary table E 20. Heads, etc. This is a complete workstation. Weight approx. 200,000 kg.

Condition: ready for operation (used), Year of construction: 1982, Boring spindle diameter: 130mm, tool holder: SK50, centering: 500mm, travel X/Y/Z: 250mm/160mm/380mm, travel W/U: 1000mm/320mm, feed rate: 2m/min, rapid traverse: 5m/min, max. diameter drilling/facing: 800mm/1400mm, torque boring spindle/facing support: 3100Nm/6150Nm, clamping plate dimensions X/Y/Z: 3500mm/1750mm/350mm, weight: approx. 30000kg, controls: Bosch. Including angle head, extension piece, steep taper tool holder for SK50 (without tools), 4x plate fields with the dimensions 1080mm/2000mm and boring apparatus. Documentation available. An inspection on site is possible. Fodeyttw Uepfx Akhogf

Condition: used, Year of construction: 1964, machine/vehicle number: 64 / 39.9037 / 2, functionality: fully functional, pressing force: 1,200 t, stroke length: 600 mm, table width: 4,500 mm, table length: 2,700 mm, distance table to ram: 1,600 mm, clearance between the columns: 5,200 mm, overall weight: 400,000 kg, Equipment: documentation/manual, Press force: 1,200 t Ram stroke: 600 mm Ram adjustment: 600 mm Strokes: approx. 9 strokes/min Shut height: approx. 1,600 mm Drawing device: Blankholder (drawing cushion) force: approx. 225 t Drawing cushion stroke: approx. 200 mm Pneumatic ejector in ram: Force: approx. 95 t Stroke: approx. 150 mm Fgjdpfx Akoy An H Rohjf Heavy-duty mechanical eccentric drawing press in robust double-column design by Schuler, engineered for continuous industrial operation in the automotive sector. The machine features a pressing force of 1,200 t and a fixed ram stroke of 600 mm, with an additional ram adjustment of 600 mm. The stroke rate is approx. 9 strokes per minute. The shut height is around 1,600 mm, enabling the use of large-format dies and components. Particularly noteworthy is the large working area with a table size of approx. 4,500 mm, as well as a retractable/movable press table that significantly facilitates setup and die change, making the machine optimally suited for handling heavy tooling. The integrated drawing device (drawing cushion) provides a holding force of approx. 225 t with a stroke of approx. 200 mm, enabling demanding drawing and forming processes, especially common in bodywork manufacturing. In addition, the press is equipped with a pneumatic ejector in the ram (approx. 95 t / 150 mm), supporting automated parts removal processes. The press has not been operated in continuous production at its current location since the 1990s and has only been used for testing purposes.

Condition: used, Year of construction: 1985, functionality: unexamined, Rotary and sliding table | Brand: SKODA | Type: SEA40P Year of manufacturing: 1985 The table can be inspected by prior arrangement. TECHNICAL SPECIFICATIONS: - Control: variable - Measurement systems: Heidenhain - Axis drives: Siemens - Maximum table load: 40 tons - Table clamping area: 2.400 x 2.400 mm - Total height of the rotary table: 1.210 mm - Table stroke (W-axis): 2.500 mm - Inner circular guide: * Centre diameter: 1.210 mm * Guide width: 250 mm - Outer circular guide: * Centre diameter: 2.200 mm * Guide width: 165 mm - Feed rates, infinitely variable: * Longitudinal feed – range: 0,5 – 2.000 mm/rpm * Rapid traverse: 10,000 mm/rpm * Rotational feed – range: 0,5 – 2.000 mm/rpm * Rapid traverse: 10.000 mm/rpm - Rotational feeds, relative to the diameter: 1.600 mm - Motor torque (speed): 170/300 Nm/rev - Total power requirement: 120 kVA - Table weight approx.: 28 tons - Dimensions L/W/H: 7,3 x 3,5 x 1,21 m Fgodpfx Akezgu Uajhef ACCESSORIES/EQUIPMENT: - Control cabinet for the table positioners, power electronics, positioners (without control) - Documentation No guarantee is given as to the completeness or accuracy of the technical specifications or the equipment. - Subject to prior sale.
