Flexible manufacturing cell

SORALUCE

Condition: ready for operation (used), Year of construction: 2000, spindle speed (max.): 3,000 rpm, travel distance X-axis: 6,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 2,000 mm, controller manufacturer: HEIDENHAIN, controller model: 426, number of slots in tool magazine: 30, number of axes: 3, This 3-axis Soraluce SP 8000 was manufactured in 2000. It features an impressive X-axis travel of 6,500 mm, Y-axis travel of 1,250 mm, and Z-axis travel of 2,000 mm. The machine is equipped with a high-torque spindle motor and a tool magazine capacity of 30 tools. If you are looking to get high-quality machining capabilities, consider the Soraluce SP 8000 universal machining centre we have for sale. Contact us for further details. • Max. feed rate: 15,000 mm/min • Guideways: Heavy-duty linear/roller guideways with linear scales • Milling head: Automatic Huré-type universal head, 2.5° x 2.5° automatic indexing on both bodies • Spindle: taper ISO 50 / SK 50 (DIN 69871); direct/gearbox-driven high-torque motor • Tool changer and magazine: ATC with 30-tool chain-type, column-mounted; supports heavy-duty tooling (weight/length per standard) • CNC control: Heidenhain iTNC 530 / TNC 640 or Siemens Sinumerik Additional equipment • Chip conveyor (longitudinal, between table and column) Ijdpfezumgkox Abyotk • Coolant system (external supply to tool/head) • Enclosure (partial/perimeter protection) Technical Specification Taper Size ISO 50

Year of construction: 1995, condition: ready for operation (used), A CNC rigid board milling and drilling center Bimatec Soraluce is available. Travel X/Y/Z: 2500mm/900mm/1600mm, speed: 2000rpm, spindle mount: ISO40/M16, tool positions: 30, transport dimensions X/Y/Z: approx. 5300mm/3450mm/3500mm, weight: approx. 13500kg, control: Heidenhain CNC 415, operating hours: 31507h. Including fixed table, movable stand, automatically indexing milling head, manual measuring probe, coolant device and filter system. Documentation available. On-site inspection is possible. Iodpfou T Rgwox Abystk

Year of construction: 2011, condition: ready for operation (used), Travel X/Y/Z: 5500mm/1200mm/1800mm, milling head indexing: 2.5°, drive power: 28kW, spindle speed: 4000rpm, feed X/Y/Z: 25m/min, table diameter: 1600mm, table speed: 250rpm, max. workpiece weight: 8000kg, panel field dimensions X/Y/Z: 6000mm/2000mm/300mm, machine weight: approx. 16500kg, control: Heidenhain iTNC 530. Workpiece weight: 8000kg, panel field dimensions X/Y/Z: 6000mm/2000mm/300mm, machine weight: approx. 16500kg, control: Heidenhain iTNC 530. Including internal coolant supply and chip conveyor. Documentation available. On-site inspection is possible. Itedpjvx Twujfx Abyek

Condition: used, Year of construction: 1999, x-travel 12000 mm y-travel 3600 mm z-travel 1500 mm spindle turning speed range 3000 U/min Control: Heidenhain iTNC430 Milling head 2 axes, indexed 2.5° Vertical (Y-axis): 3600 mm Transverse (Z-axis): 1500 mm Longitudinal (X-axis): 12,000 mm Guide rail length: 14,700 mm Guide rail width: 1400 mm Lowest milling position of the spindle nose measured from the floor (head horizontal): 855 mm Low column design 870 x 900 x 2,625 mm: 3,000 kg High stand design 870x900x3,025 mm: 3,500 kg Motor power: 37 kW Mounting: ISO 50/ DIN 69871-A Speeds: 11.7:231:3000 rpm Feed range: 2:2500 mm/min Rapid traverse X-axis: 12000 mm/min Itsdpfx Absxwdygsyok Z-Y axis: 15000 mm/min Feed motor power X-axis: 55 Nm Z-axis: 37 Nm Y-axis: 37 Nm Accuracy Positioning accuracy: 0.025 mm Repeatability: 0.015 mm Weight: approx. 42,000 kg Air supply to the machine: 300 L/min at 4.5 bar NOTE: The clamping plates and chip conveyors are not included in the scope of delivery. However, we can offer you both used and new clamping plates and chip conveyors on request.

Condition: excellent (used), Year of construction: 2009, x-travel 6000 mm y-travel 2100 mm z-travel 1500 mm control HEIDENHAIN iTNC 530 feed 2- 20 m/min spindle turning speed range 20 -4000 U/min table dimension - longitudinal 7000 mm table dimension - cross 2000 mm total power requirement 79 kW weight of the machine ca. 55 t dimensions of the machine ca. 15 x 7 x 4,6 m The SORALUCE FP6000 is in very good condition. accessories as option: # clamping angle: 5'000.-€ # Clamping cube: 2'000.-€ # Div. tools & workbench: 2'000.-€ Description: - CNC control: HEIDENHAIN ITNC 530 Ijdpfxovwgl Aj Abyjtk Orthogonal milling head: - Tool holder: ISO 50, DIN69871 AD - Automatic tool clamping: Clamping force 20,000 N - Indexing accuracy / repeatability: ± 3 sec. == ± 0.002 mm - Tightening bolt: DIN 69872 form A - Number of swivel positions: 1 x 1 ° milling head ( 360 positions rear plane, 270 positions front plane) 270 positions front plane) - Diameter spindle bearing: 90 - Sealing air: 0,7 bar Main drive: - Drive type: three-phase motor - Drive power: 100 % ED 32 kW spindle: - Spindle speed: 20 - 4000 rpm - Full power from: 340 rpm - Torque at 32 kW/S1: 910 Nm - Speed control: 2 ranges infinitely variable via star/delta connection Rapid traverse: max. 35000 mm/min

Condition: good (used), Year of construction: 2000, x-travel 3500 mm y-travel 1600 mm z-travel 1200 mm spindle turning speed range 250 - 3000 U/min tool taper ISO SK-50 tool change unit 40 rapid traverse: 15000 mm/min. Itjdpjykvaysfx Abysk feed 5000 mm/min table dimension - longitudinal 3860 mm table dimension - cross 1000 mm control HEIDENHAIN TNCi530 weight of the machine ca. 24 t dimensions of the machine ca. 8000 x 5000 x 4000 m

Year of construction: 1999, condition: ready for operation (used), travel distance X-axis: 6,250 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, spindle motor power: 30,000 W, spindle speed (max.): 3,000 rpm, number of axes: 3, This 3-axis Soraluce SM 8000 Bed Type Milling Machine was manufactured in 1999. It features an impressive X-axis travel of 6,250 mm, Y-axis travel of 1,200 mm, and Z-axis travel of 1,500 mm. The machine includes a spacious table dimension of 8,000 x 1,100 mm and a powerful 30 kW spindle. If you are looking to get high-quality milling capabilities, consider the Soraluce SM 8000 machine we have for sale. Contact us for further details. • Table dimensions: 8,000 x 1,100 mm • Bed height: 870 mm • Working feeds: 5,000 mm/min • Rapid traverse (X/Y/Z): 15,000 mm/min • Feed motor torque (X/Y/Z): 45 / 27 / 27 Nm • Coolant system pressure: 3 bar • Coolant tank capacity: 500 L • Max coolant flow rate: 50 L/min • Air supply: 300 L/min at 4.5 bar • Milling head: Manual Additional equipment • Oil chiller / cooler • Chip conveyor Technical Specification Iedpfx Aezna Nrjbyotk Taper Size ISO 50

Condition: excellent (used), Year of construction: 2003, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,400 mm, spindle speed (max.): 4,000 rpm, table width: 1,200 mm, table load: 4,000 kg, table length: 3,860 mm, mount diameter: 50 mm, total height: 3,640 mm, total width: 4,500 mm, total length: 8,900 mm, rotational speed (max.): 4,000 rpm, workpiece weight (max.): 4,000 kg, overall weight: 24,000 kg, FIBRO indexing rotary table, 800 mm Enclosed, covered machine with doors for easy access Itodpfxezl Afdj Abyek Indexing head: 2.5 x 2.5 degrees Automatic lubrication Double chain chip conveyor Machine owned by one previous user, in working condition X-axis: 3500 mm Y-axis: 1200 mm Z-axis: 1400 mm Table length: 3860 mm Table width: 1200 mm Table load capacity: 4000 Table diameter: 800 mm Feed rate, X-axis: 20,000 mm/min Feed rate, Y-axis: 20,000 mm/min Feed rate, Z-axis: 20,000 mm/min Tool interface: 50 ISO/BT/MK Spindle power: 30 kW Spindle speed: 4000 rpm Tool changer: 30 Number of controlled axes: 3 + 1 Chip conveyor: Yes Coolant system: Yes Length: 8900 mm Width: 4500 mm Height: 3640 mm Weight: 24,000 kg

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,250 mm, table load: 2,500 kg, rotational speed (max.): 3,000 rpm, overall weight: 10,000 kg, CNC Heidenhain TNC 530 Maximum spindle speed: 3000 rpm Automatic tool changer SA 50 Iedpoy Nnunefx Abystk Power: 22 kW Tool changer Travel: 2000 x 1000 x 1250 mm Chip conveyor Machine weight: 12,500 kg

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,600 mm, Travel ranges: Longitudinal (X): 4000 mm Vertical (Z): 1600 mm Lateral (Y): 1300 mm Rotary table: Diameter: 1600 mm Maximum speed: 250 min⁻¹ Drive power (100% duty cycle): 53 kW Maximum transport load (positioning): 8000 kg Maximum transport load (rotation): 3000 - 8000 kg Work table: Length: 4000 mm Width: 1240 mm Height of work table: 760 mm Automatically indexing milling head: Tool interface: ISO 50, DIN 69871 AD Automatic tool clamping: Clamping force 20000 N Spindle speed range: Spindle speed: 20 - 5000 min⁻¹ Full power from 340 min⁻¹ Torque at 32 kW/S1: 900 Nm Main drive: Drive power: 43 kW Maximum rapid traverse rate: X-axis 45000 mm/min Y- and Z-axis 35000 mm/min Maximum feed force: X, Y and Z-axis 16000 N Automatic tool changer Magazine positions in M version: Maximum tool positions: SK 50 40 positions Maximum tool positions: Capto C8 20 positions Machine weight: approx. 32,100 kg Equipment: - Work table 4000 x 1240 x 760 mm with integrated rotary table Ø 1600 mm - Swiveling control panel with telescopic arm with HEIDENHAIN TNC 640 HSCI (6 axes + spindle) control, including 19" flat screen, metallic keyboard with integrated mouse and USB interface on the control panel. Processor speed 0.5 ms including HEIDENHAIN smarT.NC. - Interpolative turning with HEIDENHAIN TNC 640 HSCI consisting of CAM system, HEIDENHAIN postprocessor, software adaptation for C-axis (spindle). - Portable electronic hand-held unit HEIDENHAIN HR 520 with 5 m cable. - Automatically indexing milling head / 2 levels with 2.5° x 2.5° division and a tool clamping force of 20,000 N (H200), 32 kW / 900 Nm, tool interface ISO 50 - DIN 69871 AD. Mounting flange with Hirth gearing for adapting turning tool holders, grinding spindles or additional milling heads and a protective ring to cover the Hirth gearing; not required if H205 is selected. - Spindle drive 43 kW at 100% duty cycle via water-cooled HEIDENHAIN inline motor with direct power transmission. The motor is integrated into the milling slide. Itjdpfjzi S E Uox Abyok - Turning tool holder with Capto C8 interface (manual tool clamping) for turning operations incl. Hirth gearing and SK 50 interface according to DIN 69871 AD for adaptation to SORALUCE milling heads. (Semi-automatic changing with additional manual fastening by 8 x M8 screws); not required with fully automatic changing of the turning tool holder. - Pneumatically adjustable pick-up station (travel 500 mm) in the tool changer area for the turning tool holder and protective ring for semi-automatic changing. - Work table with integrated NC rotary table Ø 1,600 mm, for turning operations and for positioning operations with hydraulic clamping. - Rack and pinion drive in the X-axis via two servomotors controlled in a master-slave process.
