Universal 5-axis machining center

Spinner U5-1520

Condition: used, Year of construction: 2016, Used 2016 SPINNER U-1520 Machining Centre Supplied with Siemens SINUMERIK 840 control, 12,000 RPM spindle, 32-station tool changer, 80 bar high-pressure coolant, air through spindle, Renishaw probe, touch probe, and additional Ø650 mm rotary table. Isdpfxozx Ehns Akwotl ----- SPECIFICATION: TRAVELS: - X Axis: 1,500 mm - Y Axis: 500 mm - Z Axis: 600 mm - 4 Continuous Axes + 1 Positioned Axis TABLE: - Rotary Table Diameter: 650 mm - Fixed table: 920x540mm SPINDLE: - Max Speed: 12,000 rpm - Taper: SK40 - Air Through Spindle TOOL CHANGER: - Capacity: 32 Tools COOLANT EQUIPMENT: - High Pressure Coolant: 80 bar GENERAL: - Control: Siemens SINUMERIK - Renishaw Probe - Touch Probe - Year of Construction: 2016 Control: Siemens 840D Spec: Travel X 1500 Y500 Z600 | Spindle Speed 12000RPM | SK40 Accessories: 5 axis Table, Fixed Table, 32 Tool Changer

Condition: reconditioned (used), functionality: fully functional, machine/vehicle number: F39033, KEKEISEN Universal Bed Milling Machine UBF 2000/13, machine no. F39033; well maintained, very good condition, mechanically partly overhauled in 2025 2-axis universal head automatically swivelling, with locking in Hirth coupling Intermediate positions adjustable in 1° steps by jog mode SK50 tool holder according to DIN 69871/872 Longitudinal travel of the table (X-axis) 2000 mm Transverse travel of the headstock (Y-axis) 1000 mm Vertical travel of the headstock (Z-axis) 1300 mm Machine table size 2200 x 960 mm, with T-slots 22 mm, spacing 140 mm Rotary table rotation 360° (stepless, with clamping) Rotary table load 5000 kg Spindle power 30 kW (100%ED), max. torque 1180 Nm Spindle speed 20 - 3800 rpm (infinitely variable in 2 ranges), with oil cooling Axis speeds 4 m/min or 10 m/min rapid traverse CNC control Heidenhain TNC 426 CA with electric handwheel HR 330 Itedpeykuxhefx Akwjl Drive system make Baumüller Coolant system with inner cooling up to 16 bar. Air/water changeover Purolator double-switching filter with 200 litre collecting tank Tool changer for 30 tools Work area panelling all round, open at the top, with longitudinal chip conveyor Connection data 400 V; 50 Hz; approx. 55 kVA without installation elements (fixators),

Condition: excellent (used), Year of construction: 2012, Equipment: chip conveyor, Spinner U5-1520 5-axis machining center Control system: Heidenhain 620 Year of manufacture: 2012 Table dimensions: 2-part – fixed 920x540 mm / rotary round table 650x500 mm (with enlarging ring) Travel in X-axis: 1,520 mm Travel in Y-axis: 520 mm Travel in Z-axis: 420 mm Spindle mount: ISO 40 Spindle speed: 12,000 rpm Automatic tool changer: 32 positions Spindle motor power: 15 kW Net weight approx.: 10,000 kg Accessories: Internal cooling system with paper band filter Chip conveyor Handwheel Isdpfxeztv Ihe Akwstl

Condition: excellent (used), Year of construction: 2003, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,400 mm, spindle speed (max.): 4,000 rpm, table width: 1,200 mm, table load: 4,000 kg, table length: 3,860 mm, mount diameter: 50 mm, total height: 3,640 mm, total width: 4,500 mm, total length: 8,900 mm, rotational speed (max.): 4,000 rpm, workpiece weight (max.): 4,000 kg, overall weight: 24,000 kg, FIBRO indexing rotary table 800 mm Closed covered machine with doors for easy acces Indexing head 2.5 x 2.5 Degrees Automatic lubrication Double chain chip conveyor Under power 1e owner machine X - Travel: 3500mm Y - Travel: 1200mm Z - Travel: 1400mm Table Length: 3860mm Table Width: 1200mm Table load: 4000 Table Ø: 800mm Feed rate X-Axis: 20000mm/min. Feed rate Y-Axis: 20000mm/min. Feed rate Z-Axis: 20000mm/min. Isdjzl Afdepfx Akwstl Spindle Taper: 50ISO/Bt/Mk Power on spindle: 30kW Speeds / ranges: 4000Rpm ATC / revolver: 30 Number of controlled axis:3 + 1 Chip conveyor: Yes Coolantsystem: Yes Length: 8900mm Width: 4500mm Height: 3640mm Weight: 24000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,250 mm, table load: 2,500 kg, rotational speed (max.): 3,000 rpm, overall weight: 10,000 kg, CNC Heidenhain TNC 530 Maximum spindle speed: 3000 RPM SA 50 tool holder Power: 22 kW Tool changer Travel: 2000 x 1000 x 1250 mm Chip conveyor Itedpfx Ajy Nnunskwjl Machine weight: 12500 kg

Condition: used, Year of construction: 2022, x-travel 5.230 mm y-travel 2.750 mm z-travel 1.100 mm control Heidenhain TNC 640 Tool bore DIN69871 A50 BIG PLUS main drive 32/43 kW torque S1/S6-60% 752/1.011 Nm speeds Spindel stufenlos 6.000 U/min ca. 70 kw weight of the machine ca. ca. 43 t Installation dimensions (length x width x height) ca. 12,2 x 5,7 x 5,1 m Isdpfx Ajzgxgmskwetl In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical features & accessories: - Heidenhain TNC640 control system with HR510 handwheel and digital drives - 60-station tool changer - Internal coolant supply (ICS) for vertical spindle with 1000L tank and automatic water/air switching - Direct axis measurement via Heidenhain linear scales - Coolant system with paper belt filter and magnetic separator - Automatic central lubrication - Rigid tapping (threading without compensating holder) - Oil-cooled ball screw (internal) in the X-axis - Spindle oil cooler - Automatic machine shut-off - Screw-type chip conveyors on both sides of the table - Hinged-belt cross chip conveyor Accessories, pictured tools, and workholding devices are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data/specifications, and prior sale.

Condition: used, Year of construction: 2013, operating hours: 40,000 h, functionality: fully functional, machine/vehicle number: 62130810, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,050 mm, travel distance Z-axis: 1,300 mm, feed length X-axis: 1,000 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 1,000 mm, rapid traverse X-axis: 16,000 m/min, rapid traverse Y-axis: 16,000 m/min, rapid traverse Z-axis: 16,000 m/min, CNC bed-type milling machine Kiheung KNC U1050 - Control: HEIDENHAIN iTNC 530 - Tool holder SK50 - Coolant tank 600 l Iedjxp N H Njpfx Akwotl - Universal automatic milling head A 4 Plus - High-performance cooling system with 2 high-pressure pumps, CTS 16 bar, paper filter - 2 coolant water tanks - Coolant spray gun - Hinged chip conveyor

Condition: used, Year of construction: 1977, functionality: fully functional, machine/vehicle number: 1000U, KELLENBERGER Round Grinding Machine 1000 U Manufacturer: KELLENBERGER Model: 1000 U Machine number: 457/1893 Year of manufacture: 1977 Technical data Center height: 125 mm Center distance: 1,000 mm / max. 1,200 mm Largest possible swing diameter: 250 mm Max. length for surface grinding (with B=200 mm): 1,300 mm Work surface of the table: 1590 x 140 mm Grinding wheel dimensions for round grinding: 350 / 400 x 50 x 127 mm Iedoylbicepfx Akwetl Grinding wheel dimensions for surface grinding: 250 x 13 x 76 mm Table speed: 6 m/min Speeds of the grinding spindle: 1500 / 1700 / 2200 / 3600 rpm Workpiece speeds, continuously adjustable: 20 - 400 rpm Grinding wheel head, swiveling: 270° Locking: every 90° Swiveling range of the workpiece spindle stock: 360° Max. inclination of the table: 9° Transverse movement of the grinding slide: 285 mm Feed per table revolution, continuously adjustable: 0.001 - 0.03 mm/revolution Feed amount during plunge grinding: 0 - 0.9 mm/revolution Micro-stop of the feed per graduation: 0.001 mm/revolution Spindle taper: MK 5 Tailstock: MK 3 Dimensions & Weight Length x Width x Height: 4210 x 1750 x 1500 mm Weight: 3,100 kg

Condition: used, Year of construction: 2012, operating hours: 40,000 h, functionality: fully functional, machine/vehicle number: 66120101, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,600 mm, Model X 4000 - HEIDENHAIN iTNC 530 path control - Feed in all 3 axes Itodpfoxp Nutjx Akwjl - Rapid traverse X: 16,000 mm/min, Rapid traverse Y: 12,000 mm/min, Rapid traverse Z: 10,000 mm/min - Coolant tank with option for through-spindle cooling, 2 pumps, 1,700 l - Vertical tool changer for 24 tools - Universal automatic milling head A 4 Plus - CTS 16 bar through-spindle cooling - Air through the spindle (max. 10 bar) - Hinged belt chip conveyor X 4000, rear, raised discharge - Hinged belt chip conveyor, front, raised discharge, narrow version

Condition: used, Year of construction: 2016, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,500 mm, RepairFIT by Dornhöfer The difference. Includes installation & commissioning! KEY TECHNICAL DATA Machine year of manufacture: 2016 Capacities / Travel: Longitudinal (X): mm 3,000 Vertical (Y): mm 2,000 Lateral (Z): mm 1,500 Clamping surface, NC rotary table: Swivel table: mm 1600 x 1400 Transport load: kg 15,000 Positioning accuracy: arc/sec ±2.5 Paint finish: graphite gray RAL 7024 / agate gray RAL 7038 Tool holder: ISO 50, DIN 69871 AD Iedpfx Aezux Awekwotl Pull stud: DIN 69872 Form A Main drive: Drive power (from 376 rpm): kW 40 Spindle speed range: Spindle speed: min-1 0 - 3,000 Torque: Nm 1,360 Speed control: 3-stage (oil-cooled) with automatic switching Connection power: kVA approx. 53 Feeds: Working feed max.: X, Y and Z axis mm/min 15,000 Max. Rapid traverse speed: X, Y and Z axis mm/min 25,000 Space requirement Length approx. mm 8,500 Height approx. (without tool changer) mm 4,200 Width approx. mm 5,600 Weight: kg approx. 29,200 HEIDENHAIN iTNC 530 HSCI Automatic MTE milling head Diagonal Automatic tool changer Chip conveyor Coolant system with 50 bar & (IKZ) Full enclosure for working area (closed at the top) Extraction system for the aforementioned full enclosure Special operating mode RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are procured after a strict selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, the identified obvious defects and faults were professionally repaired by our skilled service team.
