Stäubli RX160 (2009) 6 axes robot

Stäubli RX160

Condition: like new (used), Year of construction: 2017, operating hours: 4,500 h, functionality: fully functional, machine/vehicle number: F17/5EWVB1, overall weight: 350 kg, load capacity: 30 kg, arm reach: 1,700 mm, I offer the Stäubli RX160 robot, the option to add a uniVal Drive The robot is in almost new condition, used only 4500 hours motor see. photo. Hsdpfx Afor Dvd Ispsfn Maximum load 30kg Nominal load 20Kg Reach (between axis 1 and 6) 1710 mm Number of degrees of freedom 6 Repeatability - ISO 9283 ±0.05 mm Stäubli series controller CS8C Weight 248 Kg

Condition: ready for operation (used), Year of construction: 2017, Two Stäubli robots including controller and stand are available. 1) 2x Stäubli RX160L robots, year of manufacture: 2017, axes: 6, payload nominal/maximum: 14kg/28kg, reach: 2010mm, repeat accuracy: +/-0.05mm, max. speed: 12.3m/s, weight: approx. 250kg, operating hours: approx. 52000h. 2) 2x Stäubli CS8C-RX160 controllers, year of manufacture: 2017. 3) 2x robot stands for Stäubli RX160L. Documentation available. On-site inspection is possible. Hsdewt Tltopfx Afpjfn

Condition: excellent (used), Stäubli Measuring Robot Here we offer a very well maintained Stäubli measuring robot. Measuring robotics to measure, analyse and evaluate quality features Hfsdpofz Dhtsfx Afpsn RobFlow (measuring robotics software) full version and dongle on integrated Siemens industrial PC 6AG4114-1NC22-4EX0 Laser Distance Sensor Model ILR 1181-30 Technical data: Measuring range 0.1 ... 50 m on natural, diffuse reflecting surfaces, 50 m to a maximum of 150 m on reflector panel Linearity ±2 mm (+15°C ... +30°C), ±5 mm (-10°C ... +50°C) Resolution 0,1 mm Repeat accuracy ≤ 0.5 mm Response time 100 ms ... 6 s (ILR 1181-30) 20 ms ... 6 s (ILR 1182-30) Laser according to IEC 825-1 / EN 60825 Red 650 nm, laser protection class 2, power ≤ 1 mW Beam diameter < 11 mm at 10 m distance Beam diameter < 35 mm at 50 m distance Beam diameter < 65 mm at 100 m distance Laser divergence 0.6 mrad Operating temperature -10°C ... +50°C Storage temperature -20°C ... +70°C applications: RobFlow is a modular system, the range of functions of the standard package can be extended by additional Plugins for special tasks as well as customer-specific extensions can be added. With the help of the available functions, the following applications can be implemented, for example: Infotainment tests: Optical and haptic tests Single actuations and path movements straight, meandering, curve segments Analysis and evaluation functions Steering column tests: Haptic tests along complex paths Wide measuring range due to multiple calibrated Force/torque sensor Easy to [...]

Condition: used, Year of construction: 2007, operating hours: 30,000 h, The Stäubli RX160 robot consumed 30,000 engine hours. Made in 2008. Necessary accessories (communication card, digital input and output card...) can be added to the robot as needed. The robot has had an oil change and is in good overall condition. All serviced in original Stäubli service. Maximum load capacity 34 kg. Nominal load capacity 20 kg Reach (between axis 1 and 6) 1710 mm Repeatability - ISO 9283 ± 0.05 mm Maximum speed at the center of gravity of the load 10.3 m/s Weight 248 kg Brakes - All axles Pneumatic: 2 solenoid valves 5/2-way (compressed air) monostable 1 straight line between base and forearm Electrical: 1 socket with 19 contacts (7 twisted pairs including 2 shielded, 3 power contacts) Standard for clean rooms - ISO 14644-1 5 Protection class (*wrist) according to NF EN 60529 IP65 (*67) Stäubli controller series CS8 CS8C. Hjdsnrhgmjpfx Afpofn
