Swiss-type cnc lathe

STAR SV-32

Condition: good (used), Year of construction: 2001, functionality: fully functional, Fanuc control, turret with Y-axis and AGW, FMB bar feeder, chip conveyor, tool holders, including driven ones. Dsdpfxjxl Tkkj Aghoku

Condition: ready for operation (used), Year of construction: 2002, operating hours: 18,000 h, functionality: fully functional, spindle diameter: 32 mm, Equipment: bar feeder, chip conveyor, CNC Swiss-type lathe with comprehensive equipment! Dedpfxsxc I Ape Agheku Main spindle diameter: 32 mm MACHINE DETAILS Operating hours: 18,000 EQUIPMENT Synchronously driven guide bushing C-axis on main and sub-spindle Workpiece conveyor belt Collet sleeve main spindle: F37 (673-53) Collet sleeve sub-spindle: F37 (673-73) 3-spindle cross drilling unit 4-position tool holder 16x16 mm Sub-spindle (32 mm sub-spindle capacity) Parts blower to the front Parts ejector Parts ejection safety device Cut-off tool breakage safety device Separate coolant tank with level and flow monitoring Automatic central lubrication unit with oil level monitoring Leveling bolts and plates Toolbox FMB Turbo 3-26 bar feeder, year of manufacture: RS232C interface for bar feeder Fire extinguishing system Kraft & Bauer / GUT Feuerschutz Mayfran chip conveyor

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 32 [mm] Dkjdpfxsuha N Dj Aghju - Travel : 310 [mm] - Spindle speeds : 280 - 7.000 [rpm] - Spindle power : 7,5 [kW] - C axis indexing precision : 0,01 [°] COUNTER-SPINDLE - Max. bar diameter : 32 [mm] - Z stroke : 150 [mm] - Spindle speeds : 280 - 7.000 [rpm] - Spindle power : 3,7 [kW] - C axis indexing precision : 0,01 [°] - Number of turrets : 1 UPPER TURRET - Number of positions : 10 - Number of motorized positions : 10 - Live tools speed : 5.700 [rpm] - Live tools power : 2,8 [kW] GUIDE BUSH HOLDER 1 - Number of positions : 4 - Number of motorized positions : 3 - Live tools speed : 6.000 [rpm] POWER SUPPLY - Supply voltage : 200 [V] - Total installed power : 8 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.645 x 1.403 [mm] - Machine height : 1.680 [mm] - Machine weight : 3.880 [kg] MACHINE HOURS - Number of working hours : 6140 [h] EQUIPMENT - CNC : Fanuc 16 iTB - 3 colors status lamp - Parts catcher - Parts conveying strip - Coolant tank * with high-pressure pump - Bar loader : FMB TURBO 3/36 - Electric transformer

Condition: good (used), STAR SV-32 CNC sliding headstock automatic lathe TECHNICAL DATA Main spindle, bar capacity: 32 mm Travel: 310 mm Spindle speed: 7000 rpm Spindle drive power: 7.5 kW Minimum resolution, C-axis: 0.01 ° Counter spindle, bar capacity: 32 mm Spindle speed: 7000 rpm Spindle drive power: 7.5 kW Resolution, C-axis: 0.01 ° Turret: Number of tools: 10 of which driven: 10 Speed of the driven tools: 5`700 rpm Driven tools, power: 2.8 kW Dkodpfx Asu Uicysghsu Tool carrier: Number of tools: 4 Of which driven: 3 Speed of the driven tools: 6'000 rpm Weight and dimensions: Weight: 3800 kg Dimensions: 2700 x 1400 x 2400 mm SCOPE OF OFFER U.A: (list not exhaustive) Control system: Fanuc Fire extinguishing system: Siemens Oil mist separator: Donaldson transformer High pressure pump Parts conveyor Chip conveyor Exact scope of supply according to photo gallery We assume no liability for the correctness, completeness and up-to-dateness of the information.

Condition: good (used), Year of construction: 2013, Manufacturer: STAR Type: SV-32 Year of manufacture: 2013 with FANUC 16i-TB control, turret, synchronized spindle, driven tools, C-axis, parts conveyor, fire extinguishing system, chip conveyor, bar feeder magazine FMB TURBO 3-36. Dkjdpevffccjfx Aghsu
