T slotted bed plate STOLLE

Stolle

Condition: used, plate width 5500 mm plate depth 2000 mm plate height 300 mm weight 10000 kg 2 identical plate fields available (A2018) LxWxH: 5000 x 2000 x 300mm Area for 2 slab fields: 22m² Dimension of the T-slots; 36 x 64 mm - height: 45 mm Hodpfxsgrm T Do Am Sjnr

Condition: used, plate width 2870 mm plate depth 2000 mm plate height 300 mm weight 5200 kg 3 identical plate fields available (A2017) LxWxH: 2870 x 2000 x 300mm Area for 3 slab fields: 17.22m² Hnjdpfsgrm U Eox Am Sor Dimension of the T-slots; 36 x 64 mm - height: 45 mm Weight: KG

Condition: used, plate width 2870 mm plate depth 2000 mm plate height 300 mm weight 5200 kg flute distance 250 mm 3 identical plate fields available (A2017) LxWxH: 2870 x 2000 x 300mm Area for 3 slab fields: 17.22m² Dimension of the T-slots; 36 x 64 mm - height: 45 mm Hsdpoy S Dziofx Am Sjnr Weight: KG

Condition: used, Year of construction: 1980, length 3500 mm width 1750 mm Hnedpfx Ajw U Eilem Sjr thickness of bolster 260 mm number 2 St no. of flutes 6 weight 5 t 2 pieces T slotted floor plates with 6 slots, each 36 mm width. All dimensions and price is only for one plate !

Condition: used, Technical details: floor-plate length: 5500 mm plate width: 2150 mm plate height: 340 mm Hnodpfxeval Nfs Am Ser Plate thickness: 340 mm weight of the machine ca.: 9,0 t transport dimensions LxWxH: ca. 5,5 x 2,2 x 0,35 m Material cast steel Milled, finished surface T-slots according to DIN 650: a=28; h=46; b=48; c=21mm Center distance 150 / 230 mm *

Condition: excellent (used), overall weight: 5,700 kg, total height: 300 mm, total length: 4,000 mm, total width: 2,000 mm, T slotted bed plate STOLLE - DT MACH-ID 9776 Make: STOLLE Type: DT Floorplate Length: 4000mm Floorplate Width: 2000mm Height: 300mm Hsdpfxjzrl Eto Am Sonr No. Of T-slots: 8 Distance from T to T-slot / Jump:250mm T -slot size: 27mm Weight a plate approx.: 5700kg Number of matching pieces: 2 Length: 4000mm Width: 2000mm Height: 300mm Weight: 5700kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), overall weight: 10,000 kg, total height: 400 mm, total length: 6,280 mm, total width: 2,100 mm, T slotted bed plate STOLLE - SDT MACH-ID 9775 Make: STOLLE Type: SDT Hsdpfx Ajzrl A Sem Sonr Floorplate Length: 6280mm Floorplate Width: 2100mm Height: 400mm No. Of T-slots: 7 Distance from T to T-slot / Jump:300mm T -slot size: 35mm Weight a plate approx.: 10000kg Number of matching pieces: 1 Length: 6280mm Width: 2100mm Height: 400mm Weight: 10000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), Cast iron marble plate Length: 3500 mm Width: 2500 mm Hnsdpfxszmw Hre Am Ssr Thickness: 300 mm Height on feet: 900 mm Delivered with 12 leveling feet Weight : 6,3 T

Condition: used, plate width 4000 mm plate depth 2500 mm plate height 300 mm weight 6,2 kg STOLLE Clamping Plate / Clamping Bed 4000x2500x300 mm L x W x H: 4000 x 2500 x 300 mm Total area (for 2 plate sections): 20 m² T-slot dimensions: 28 x 48 mm (slot width x depth) Plate thickness: 110 mm Number of slots: 10 Edge distance: 124 mm Hnjdpfx Amjzl Hcgj Sjr T-slot spacing: 250 mm Note: I am offering one clamping plate for sale. A second, identical clamping plate with the same dimensions is also available. Both plates are exact matches and can be joined together if required to create a larger clamping surface. The second clamping plate is also available upon request. Please feel free to contact me if you are interested in both plates or have questions regarding their combined installation.

Condition: used, plate width 4000 mm plate depth 2500 mm Hodjzl Hcaepfx Am Ssnr plate height 300 mm weight 6,2 kg STOLLE Clamping Plate / Clamping Bed 4000x2500x300 mm L x W x H: 4000 x 2500 x 300 mm Total area (for 2 plate sections): 20 m² T-slot dimensions: 28 x 48 mm (slot width x depth) Plate thickness: 110 mm Number of slots: 10 Edge distance: 124 mm T-slot spacing: 250 mm Note: I am offering one clamping plate for sale. A second, identical clamping plate with the same dimensions is also available. Both plates are exact matches and can be joined together if required to create a larger clamping surface. The second clamping plate is also available upon request. Please feel free to contact me if you are interested in both plates or have questions regarding their combined installation.
