Cylindrical grinding machine

TITAN RU 350 x 1-1500

Condition: excellent (used), Grinding length 1000 mm grinding diameter fi 350 mm Nledok Abxxepfx Afqsi In very good condition.

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 027.0400/067, CNC CYLINDRICAL GRINDER STUDER S-33 CNC Year: 2007 - Fanuc 21i-TB 1 External Grinding Spindle Country of Origin: Switzerland Voltage: 380/50/3 Net machine weight: 4,000 kg TECHNICAL SPECIFICATIONS Distance between centers: 600 mm Center height: 175 mm Maximum workpiece weight: 80 kg Longitudinal Slide Z Max. travel: 800 – 1,150 mm Travel speed: 0.001 to 10,000 mm/min (early 2000’s model: 0.001-5,000 mm/min) Resolution: 0.0001 mm Cross Slide X Max. travel: 285 mm Nljdpfsw T Sh Eex Afqei Travel speed: 0.001 to 20,000 mm/min (early 2000’s model: 0.001-10,000 mm/min) Resolution: 0.0001 mm Wheelhead (universal version) Swiveling range: -15° to 225° (early 2000’s model: -15° to 195°) Swivel axis: 2.5 / 1 ° Hirth Drive power: 7.5 or 9 kW or 11 kW Grinding wheel: 500x63 (80/110F5) x203 mm Workhead Rotational speed: 1 – 1,500 min-1 Mount taper: MT4 or MT5 / ISO 50 Drive power: 1.6 or 3.0 or 4.0 kW Tailstock Mount taper: MT3 or MT4 Quill stroke: 35 / 50 mm (early 2000’s model: 35 mm) Quill diameter: Ø 50 mm Fine adjustment: +/- 40 µm Control system: Fanuc 21i-TB All technical details are provided in good faith but subject to errors or omissions.

Condition: used, Year of construction: 2012, grinding diameter max. 320 mm grinding length 1.500 mm centre height 160 mm Control Touch Jones & Shipman between centers max. 100 kg table: Traverse Z-Axis 1.645 mm traversing speed 0,0001 - 12 m/min swivable +5 / -5 ° x-axis: Traverse X-Axis 260 mm traversing speed 0,0001 - 6 m/min grinding head: grinding wheel motor 7,5 kW cutting speed 45 m/s Grinding wheel Ø x width x bore 450 x 50 x 203,2 mm Tailstock: Swivel range -15 / +90 ° turning speed range 0 - 660 U/min Torque 27 Nm tool adaptor MK 3 total power requirement kW weight of the machine ca. 8,5 t dimensions of the machine ca. 5,5 x 2,5 x 2,0 m Cylindrical Grinding Machine JONES & SHIPMAN - Suprema Easy 1500 E - Replacement grinding wheel flange - Multi-grain diamond (for circumferential and lateral dressing, 10mm, 1 carat) - Tailstock with micro adjustment (max. adjustment range +-0.05mm) - Pneumatic quill retraction - Two-jaw bezel (range 8-75 mm) Nledpfstqmrpox Afqoi

Condition: reconditioned (used), Year of construction: 2006, functionality: fully functional, center height: 175 mm, type of input current: three-phase, feed length X-axis: 285 mm, feed length Z-axis: 1,150 mm, overall weight: 5,700 kg, year of last overhaul: 2025, input voltage: 400 V, workpiece spindle speed (max.): 1,500 rpm, CNC Cylindrical grinder STUDER S33 TECHNICAL CHARACTERISTICS: Year of manufacturing: 2006 CNC control: FANUC 21i-TB Software installed: StuderGrind Centre distance: 1000 [mm] Height of centers: 175 Stroke X axis: 285 [mm] Min. Stroke speed X axis: 0.001 [mm/min] Max. Stroke speed X axis: 5000 [mm/min] Resolution X axis: 0.0001 [mm] Stroke Z axis: 1150 [mm] Min. Stroke speed Z axis: 0.001 [mm/min] Max. Stroke speed Z axis: 10000 [mm/min] Resolution Z axis: 0.0001 [mm] B axis swivelling stroke: -15 [°] / +195 [°] B axis indexing precision: Hirth 1 [°] Automatic B axis: Yes Workpiece spindle nose: MT5 Workpiece spindle min. speed: 1 [rpm] Workpiece spindle max. speed: 1500 [rpm] Max. part weight in part holder headstock between centres: 120 [Kg] Type of attachment tailstock: MT3 Tailstock quill stroke: 35 [mm] Tailstock quill diameter: 50 [mm] Tailstock fine adjustment: +/- 40 [mm] Supply voltage: 400 [V] Total power required: 20 [kVA] Weight: 5700 [Kg] INCLUDED EQUIPMENT: x1 internal grinding spindle type 102540B – speed: 40,000 [rpm] x1 swiveling dressing attachment x1 rotating dressing device DR.KAISER type C42 DC 058 – speed: 25,000 [rpm] – 0.17 [kW] x1 frequency converter MAAS type SPS-9250 x1 pneumatic tailstock lift x1 pneumatic upper-table lift x1 longitudinal slide with rotary table - swiveling up to 8.5 [°] x1 automatic B-axis turret wheelhead – Hirth gearing 1 [°] x1 C-axis for thread and form grinding x1 workpiece probe MOVOMATIC C25 x1 contact control device DITTEL SENSITRON 2 x1 semi-automatic wheel balancing device MPM type 3.BMT100M x1 paper filtration unit STREULI AG x1 mist extraction unit AFS Air Filter Systeme x1 electrical cabinet air conditioner x3 external grinding wheel flanges x2 lifting blocks x1 axis bracket (for transportation of the machine) x1 set of operating manuals (French, English, and German) Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Similar machine to the brands Okamoto, ELB, GER, Tacchella, Karstens, Jones & Shipman, Jung, Favretto, Blohm, Studer. Also see surface grinder, lathe, machining center, milling machine. Nodpjxg Ixxofx Afqoli

Condition: used, Year of construction: 2017, grinding length 1500 mm centre height 180 mm weight of the machine ca. 3,9 t Nlsdpfx Aswm Rqgefqei dimensions of the machine ca. L: 4900 x 1650x 1800 m

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, External Cylindrical Grinding Machine Manufacturer: NAXOS-UNION (Germany) Model: W500 500 x 2500 mm Year of Overhaul: 2017 Technical Specifications: • Max. distance between centres: 2500 mm (full length can be ground) • Centre height: 250 mm • Grinding wheel diameter: 600 mm • Grinding support travel: 320 mm • Max. workpiece weight between centres: 1500 kg • Grinding spindle speed, stepless: 900 – 1600 RPM • Workpiece spindle speed: 50 – 450 RPM • Workpiece spindle taper: MK5 / Morse 5 • Motor power: 2.2 kW • Approx. machine dimensions (L x W x H): 7800 x 3300 x 1750 mm • Approx. weight: 13 tonnes Accessories included: • 1x full machine enclosure incl. front sliding door with safety switch • 2x glass scales for X and Z axes incl. digital display Z300 from RSF-Elektrik, measuring system MSA • 1x new belt filter unit by SEITZ, type PFA 100, incl. 100 l/min pump and control system • 1x electromechanical balancing system by MPM, balancing head mounted on spindle, sensor at grinding spindle bearing • 1x live centre, manufacturer RÖHM MK5 • 6x grinding wheel flanges • 7x steady rests • 14x leveling feet Condition: Completely overhauled in 2017, very little use since. Negotiation basis: Price: ex works, loaded free on truck Collection after payment received and by prior appointment. Nljdpfxsxcvr Ss Afqsi Disclaimer: The seller shall not be liable for typographical or data transmission errors. Machine condition in terms of appearance, technology and wear corresponds to its age; used equipment is sold without any warranty. All prices are net.
