Horizontal lathes TOS Celakovice SU-100 1979

TOS

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Horizontal boring machine TOS WHN 13.8 CNC Control system: Heidenhain 530 Spindle diameter: 130 mm Working table: 1800 x 2500 mm Working spindle taper: ISO 50 Spindle speed: 10-3000 rpm Kdjdez Dizyspfx Akwet Working spindle extension: W-800 mm Vertical spindle adjustment: Y-2500 mm Transverse table adjustment: X-4000 mm Longitudinal stand adjustment: Z-1600 mm Feed range X, Y, Z, W: 4-3000 mm/min Table load: 20 t Power consumption: 82 kW

Condition: good (used), Working area Kdedoy Ug U Djpfx Akwet Maximum turning diameter 400 mm Maximum turning length 5000 mm Swinging diameter over bed 840 mm Swinging diameter over carriage 530 mm Spindle speed 14.6 – 1250 rpm Drive power 18.5 kW Dimensions 8.0 × 1.9 × 1.7 m Weight approx. 6.3 – 8.2 t

Year of construction: 1998, condition: used, Speed: 12.5-2000/min, with documentation. An on-site inspection is possible. Kdsdpfsz Da I Rjx Akwst

Condition: used, total height: 1,700 mm, total length: 6,000 mm, total width: 1,700 mm, Empty weight: 6.500 kg Price: On request Lathe metal lathe Model: Conventional Manufacturer: TOS Type: SUI 63 Serial number: 407620860 Center distance: 4000mm Center height: 325mm Turning diameter: 630mm Spindle passage: 80mm Spindle speed: 11,2-1800 rpm Machine-afmeting: 6000x1700x1700mm Machine weight: 6500kg - Documentation available: No - CE certificate present: No - Drive system: Conventional - Centre height [mm]: 325 - Swing over bed [mm]: 630 - Distance between centres [mm]: 4000 - Spindle bore [mm]: 80 Kodpfx Akswnhy Iewodt - Min. spindle speed [rpm]: 11.2 - Max. spindle speed [rpm]: 1800 - Transport dimensions: 6000mm x 1700mm x 1700mm (l x w x h) - Transport weight [kg]: 6500kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 01.01.0555, turning diameter over cross slide: 850 mm, spindle bore: 102 mm, turning diameter: 1,200 mm, turning diameter over bed slide: 850 mm, turning diameter over top slide: 1,600 mm, center height: 600 mm, center width: 800 mm, spindle speed (max.): 400 rpm, type of input current: three-phase, overall weight: 15,000 kg, Gurutzpe Super BT 600 x 3000mm lathe, with dimension display and probe-based copying function, swing over bed 1180mm, swing over cross slide 850mm, swing over carriage 1570mm, distance between faceplate and carriage 620mm, spindle bore 102mm, speeds 2.8-400 rpm, 30 hp motor, four-jaw chuck with a diameter of 1000mm, bed width 800mm, tailstock spindle diameter 140mm, maximum weight on lathes between centers 10 tons with a steady rest of 12 tons, estimated weight of the lathe and accessories 15000kg, in very good condition. Kdodeztz Hcopfx Akwjt

Condition: excellent (used), CATALOGUE NUMBER 7663 TECHNICAL DATA - max planing width 510mm - max planing height 200mm – from above: - feed rollers - toothed infeed roller - pressure rollers, 2 rows - toothed infeed roller - pressure roller - planing roller 510mm, 4-knife, 7.5kW motor - pressure rollers - smooth, outfeed roller - outfeed pressure roller, 2 pcs - smooth feed roller – from below: - pressure roller - adjustable infeed table + slip roller - planing roller 510mm, 4-knife, 5.5kW motor - 2 slip rollers, smooth - side pressure roller – from the rear: - side spindles 1) vertical right 140mm, 4kW 2) vertical left 140mm, 4kW - spindle diameter 40mm - 4-knife cutter heads fitted, height 120mm - spindles adjustable up/down, right/left - stepless feed rate adjustment - electric table lifting - dust extraction port diameters 3x150mm, 1x110mm - dimensions L/W/H 2300x1700x1700mm - weight 2200kg ADVANTAGES - ideal for processing flooring - electric table lifting - Czech production - used planer, very good condition Net price: 36900 PLN Kdsdpfxoztpmqe Akwst Net price: 8786 EUR, depending on the exchange rate of 4.20 EUR (Prices may vary due to larger fluctuations)

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,250 mm, spindle diameter: 130 mm, spindle speed (min.): 10 rpm, spindle speed (max.): 2,500 rpm, table length: 2,200 mm, table width: 1,800 mm, TOS Varnsdorf WHQ 13.8 CNC table type horizontal boring mill, year of construction 2000, made in the Czech Republic. The machine is controlled by an original Heidenhain TNC 430 CNC with the Heidenhain operating panel and runs programs produced with CAM software. The control cabinet air conditioning unit was replaced one year ago. The machine is well maintained and in full working order. Technical data: - Control: Heidenhain TNC 430 - Spindle diameter: 130 mm - Spindle speed: 10 - 2,500 rpm - Tool taper: ISO SK 50 - X travel: 3,500 mm - Y travel (vertical axis): 2,500 mm - Z travel: 1,250 mm Kjdpoz Ap Awjfx Akwjdt - Table size: 2,200 x 1,800 mm - Operator platform with 250 kg load capacity - Air conditioning unit fitted one year ago - Programmable via CAM software The machine can be inspected under power in our workshop.

Condition: ready for operation (used), Year of construction: 1987, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 1,100 mm, spindle diameter: 100 mm, table length: 1,100 mm, table width: 1,000 mm, TOS Varnsdorf WH 10 NC table type horizontal boring mill (borer), year of construction 1987. The machine has been converted to an HSP control and its electrical/electronic system has been overhauled. Well maintained and in working condition. Technical data: - Table size: 1,100 x 1,000 mm - X travel: 1,200 mm Kodpfx Aoz Apa Njkwodt - Y travel: 1,100 mm - Spindle diameter: 100 mm - Control: HSP (retrofit), electrics overhauled Available for inspection in our workshop and ready for immediate delivery.

Condition: ready for operation (used), Year of construction: 1982, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,000 mm, spindle diameter: 130 mm, spindle speed (max.): 1,500 rpm, table length: 1,800 mm, table width: 1,600 mm, feed length W-axis: 600 mm, TOS Varnsdorf WHN 13 A table type horizontal boring mill (borer), year of construction 1982. The machine has been retrofitted with a FANUC CNC control; maximum spindle speed 1,500 rpm. Well maintained and in working condition. Technical data: - Table size: 1,600 x 1,800 mm - X travel: 3,500 mm - Y travel: 2,000 mm - Z travel: 1,000 mm - W travel (boring spindle / quill): 600 mm - Spindle diameter: 130 mm - Max. spindle speed: 1,500 rpm - Control: FANUC (retrofit) Available for inspection in our workshop and ready for immediate delivery. Kjdpfx Akez An Ufswjdt

Year of construction: 1998, condition: new, New trapezoidal screw and nut for the X-axis, for FN20, FN32, FN40. Kodpjk Nk Iwsfx Akwjdt

Year of construction: 1992, condition: new, New ISO40 collet for FN 20/32/40 milling machines. Kjdpfxjk Nk I Nj Akwodt

Condition: new, New 160 mm handwheel for tool milling machines, manufactured by TOS/INTOS Žebrák. Available with or without a hand crank. Kdedodx Rzvjpfx Akwst
