CNC Turning- and Milling Center

TRAUB TNA 480 L

Condition: new, functionality: fully functional, Year of construction: 2025, laser power: 6,000 W, travel distance X-axis: 3,030 mm, travel distance Y-axis: 1,520 mm, travel distance Z-axis: 310 mm, total length: 9,500 mm, total width: 4,500 mm, total height: 2,050 mm, Equipment: CE marking, centralized greasing system, cooling unit, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, VS-3015CE 6KW FIber Laser Sheet Cutting Machine Working area (mm) : 3000×1500 X axis travel distance (mm): 1520 Y axis travel distance (mm): 3030 Z axis travel distance (mm)： 310 X/Y axis positioning accuracy ： ≤0.03mm\m X/Y axis repeat positioning accuracy： ≤±0.02mm Max. synthetic positioning speed: 150m\min Max. acceleration: 2G Double-sided control panel, adaptive multi-angle placement, simple disassembly, and can fit into a standard 40HQ container. Industrial-grade special air conditioner, constant temperature and humidity for stable performance. Iasdpfxsv Ngraj Apcor Automatic grease and oil injection system, intelligent air pressure monitoring device, and anti-collision detection device provide intelligent protection.

Condition: new, functionality: fully functional, Year of construction: 2026, laser type: fiber laser, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Section Steel Laser Cutting Machine Bevel cutting highly enhances competitiveness Smart cutting head equipped with professional Acu3D rotary axis Achieves multi-directional, multi-angle 3D cutting Iodpow I Iliofx Apcear (Web beveling, R-corner cutting, V bevel, Y bevel) Versatile cutting Sheet, tube, and section steel cutting in one One-stop processing workflow, seamlessly integrated with TEKLA Easily complete drawing import - nesting & programming - process setup - material alignment - cutting

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Hello, I am offering for sale a renowned brand CNC lathe: DMG GILDEMEISTER CTX 420 Linear V4 with C-axis, Y-axis, and driven tools. The machine is in excellent technical and visual condition. _ Type: CNC Lathe Manufacturer: DMG GILDEMEISTER Model: CTX 420 V4 Linear Control: HEIDENHAIN 4290 + DIN PLUS interface for program generation Country of manufacture: Germany Year of manufacture: 2004 _ Machine specifications: - Turret: 12 tools with VDI 40 holders (all stations are driven) - Max spindle speed: 5,000 rpm - C-axis - Y-axis - Driven tools - Max turning length on Z-axis: 635 mm - Max turning diameter on X-axis: 325 mm - Spindle chuck BERG, diameter 200 mm - Max bar diameter: 66 mm Iasdsxcupcspfx Apcjr - Coolant system - Hydraulic tailstock, programmable - Chip conveyor - Spindle drive power: 21 kW - LNS bar feeder - Documentation (DTR) - Machine weight: 6 tons _ WHY IS IT WORTH BUYING MACHINES FROM PPM? - We offer our own stationary and mobile service support - We have sold over 700 DMG machines - We can commission the machine at the customer's site - Operator training and delivery included in the price - All our machines undergo a professional technical inspection and are ready for operation - The machine can be purchased via installment plan or leasing.

Condition: excellent (used), Year of construction: 2014, operating hours: 3,000 h, functionality: fully functional, Year of manufacture: 2014, commissioning: 2017 OSP P300S control system Travel ranges: X1/X2-axis: 695/235 mm Y-axis: 300 mm Z1/Z2-axis: 1,600/1,461 mm B-axis: -30° to +210° Maximum turning diameter: 650 mm Big Bore main spindle 32/22 kW, spindle nose A2-11, max. speed: 3,000 rpm, max. torque: 955 Nm, bore diameter: 112 mm SMW VNK320-127 hollow clamping cylinder, through bore 127 mm 3-jaw chuck Forkardt 3QLK 315-88 Z11 Pressure reducing valve 8-70 bar Iedpfx Apsxy I T Ascoar Milling spindle 22 kW, max. speed: 12,000 rpm Tool magazine with 40 stations, HSK-A63 Lower turret with 12 tool stations Self-centering steady rest on lower turret Hydraulic steady rest SMW SLU-X-3.2-ZS, clamping range: 50-200 mm Programmable tailstock Renishaw RMP probe Drum chip conveyor TMF300 with 980 L tank 8 bar circulation pump 70 bar high-pressure pump Hinged belt chip conveyor Tool monitoring system for tool life and breakage Tool measuring device (with standard chuck) for safe setup MacMan machine management with integrated PDA (production data acquisition) Part program storage: 2 GB Max. length of individual part program: 2 MB 2x USB 2.0 ports Ethernet interface with browser and DNC-T1 for program transfer Harmonic speed oscillation via periodic speed variation Tool height offset in Y-axis for turning tools Circular thread milling X/Z/Y/B (helical interpolation) Including eccentric milling X/Y/C Hi-Cut Pro high-speed control for rotating tools 10 workpiece zero points (coordinate system selection function) Coordinate transformation
