Traub TNL26K

Traub TNL26K

Condition: like new (used), Year of construction: 2026, functionality: fully functional, We offer you: CNC turning and milling center with robotic automation Manufacturer: DMG MORI Type: CLX 450 TC Year of construction: 2026 Control system: Celos X with Siemens Sinumerik One Technical data: Max. turning diameter: 400 mm Turning length: 1100 mm Bar capacity: max. 65 mm Travel paths: X-axis travel: 276 mm Z1-axis travel: 755 mm Z3-axis travel: 775 mm Y-axis travel: +/- 100 mm B-axis travel: +/- 120° Main spindle: Speed: 5,000 rpm Drive power: 14/17 kW Max. torque: 275/345 Nm Counter spindle: Speed: 5,000 rpm Drive power: 14/17 kW Max. torque: 275/345 Nm Milling spindle: Speed: 0 – 12,000 rpm Drive power: 8.8/10.5 kW Tool interface: HSK-T 63 Tool changer: 60 positions Max. torque: 73/90 Nm Internal clamping device: Ø 67 mm Operating hours: approx. 1,130 h Spindle hours: approx. 280 h Technical features & accessories: - Absolute, direct linear scales in the X and Y axes - Double-circuit filter - Counter spindle ISM 65, A2-8, C-axis and hydraulic spindle brake - Hinged belt chip conveyor, incl. coolant tank - Chuck flushing device on the outside for the main and counter spindle Pjdpfx Aiez A Ay Tsrjgt - Coolant supply through the counter spindle - Coolant spray gun - Screen cleaning for the safety shield - Electronic handwheel (if available) - Alternating speed - Signal light, 4-color - Automatic work area door, electric - Electrical interface Robo2Go - Workpiece measuring probe, manufacturer Renishaw RMP40 (if available) - Tool measuring device, manufacturer Renishaw RP1 (if available) - Function for drill breakage detection for Renishaw RP1 - Linear scale for Z1-axis - Differential pressure monitoring 2.0 on the main and counter spindle - Tailstock function for the counter spindle, incl. foot switch - Coolant system 8/40 bar, consisting of: - Coolant tank 600 l - Pump pressure variable 8 – 40 bar - Belt filter system - Lifting pump with level monitoring - Mechanical oil mist separator - Protection Package - Technology cycle with dialogue-guided programming - Technology cycle for parting off the workpiece - 2x 3-jaw chuck, manufacturer Schunk ROTA THW3 265-81 - Loading and unloading system Robo2Go, consisting of: - Module 35 kg - Drawer storage incl. additional drawer - Accessories on request Accessories, tools and clamping devices shown in the pictures are only included in the scope of delivery if this is stated in the additional information. Changes and errors in the technical data and specifications, as well as prior sale, are reserved!

Condition: good (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 1,050 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 42 m/min, rapid traverse Y-axis: 42 m/min, rapid traverse Z-axis: 42 m/min, nominal power (apparent): 41 kVA, total height: 2,808 mm, total length: 2,880 mm, total width: 2,929 mm, table width: 550 mm, table length: 1,300 mm, table load: 1,200 kg, rotational speed (max.): 12,000 rpm, overall weight: 6,800 kg, operating hours of spindle: 9,271 h, spindle nose: 150-660, tool length: 350 mm, tool diameter: 80 mm, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, Mazak Vertical Machining Center VCS 530C – Well-maintained, inspected & ready for immediate use For sale is a Mazak VCS 530C vertical machining center in excellent, well-maintained technical condition. The machine has undergone regular servicing and is in outstanding optical and mechanical shape. It is fully functional, thoroughly checked, and immediately ready for operation. Pgodpfxsy E Hhfj Airjt The Mazak 530C stands out with its high-quality features, including a 4th axis, allowing complex workpieces to be machined precisely and efficiently, providing enhanced flexibility. Additionally, the automatic door offers increased user comfort, resulting in reduced setup times and increased safety during operation. The integrated coolant system (KSS unit) ensures optimum chip evacuation, which in turn leads to longer tool life and excellent surface finishes. Combined, these features deliver a powerful package focused on productivity, precision, and reliability. With our all-inclusive service package, we can personally handle the complete process upon request—from delivery to commissioning of your new machine. This includes unloading, placement, and precise alignment of the machining center. Thereafter, our experienced service technicians will carry out professional commissioning, perform all necessary function checks, and ensure that your Mazak VCS 530C operates reliably and accurately. We also offer tailored training programs for your staff so you can make optimal use of the machine from day one. Even after installation, we remain your competent point of contact—whether for maintenance, technical questions, or future upgrades. With our all-inclusive package, you have nothing to worry about—we ensure everything runs smoothly so you can focus completely on your production. Additionally, you can acquire extraction systems, attachments, and accessories from us, including high-quality Donaldson extraction units to make your production even more efficient and cleaner. Our service commitment: Quality, expertise, and customer satisfaction are our top priorities. Our team consists of qualified and experienced technicians specialized in Mazak machinery and other equipment. We place great emphasis on personal support and are happy to assist you any time, even after your purchase. You are also welcome to inspect and test the machine under power at our facility at any time. You are cordially invited to visit us and see for yourself the condition and functionality of the machine. With us, you are in the best hands—professional, reliable, and passionate about machinery! PS CNC Service Germany GmbH & Co. KG All specifications are subject to change without notice.

Condition: used, TECHNICAL DETAILS - Number of spindles : 2 - Number of axes : 9 - Number of turrets : 2 MAIN SPINDLE - Spindle power : 6.7 / 10.7 [kW] - Spindle speeds : 8000 [rpm] - Max. bar diameter : 32 [mm] - Z stroke : 305 [mm] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Spindle power : 3.7 / 5.5 [kW] - Spindle speeds : 6400 [rpm] - Max. bar diameter : 30 [mm] - C axis indexing precision : 0.001 [°] - X stroke : 140 [mm] - Z stroke : 300 [mm] TURRET 1 - Number of positions : 10 - Number of motorized positions : 10 - Live tools speed : 12 000 [rpm] - Live tools power : 3.4 [kW] - X/Z stroke : 140/300 [mm] Psdpfeypxqrsx Airsgt - Y stroke : -40/+25 [mm] TURRET 2 - Number of positions : 10 - Number of motorized positions : 10 - Live tools speed : 12 000 [rpm] - Live tools power : 3.4 [kW] - X/Z stroke : 140/320 [mm] - Y stroke : -25/+40 [mm] POWER SUPPLY - Total installed power : 28 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3870 x 1670 [mm] - Machine height : 2500 [mm] - Machine weight : 6000 [kg] MACHINE HOURS - Number of hours under power : 23240 [h] - Number of working hours : 19500 [h] EQUIPMENT - CNC : Traub TX 8i-p - 3 colors status lamp - Coolant tank : 500 [l] * with high-pressure pump : 3,8,20 [bars] * with paper filtering unit - Chips conveyor - Parts catcher - Parts conveying strip - Predisposition for barfeeder

Condition: ready for operation (used), Year of construction: 2011, controller manufacturer: MAZATROL, controller model: Matrix, This 5-axis Mazak Integrex 100 IV ST was manufactured in 2011. It features a main spindle with a 6" hydraulic chuck, 4,000 rpm max speed, and 30 kW power. The second spindle matches these capabilities. Its milling spindle can reach up to 20,000 rpm. Includes a high-speed ATC with a 20-tool capacity, expandable to 120. Ideal for single-setup machining with its heavy-duty construction and MAZATROL MATRIX CNC control. Contact us for more information about this machine. Machine Benefits Qualitative Machine Benefits • There are 2 units available Technical Machine Benefits • Chuck type: 6" hydraulic chuck with bar capacity max /spindle speed: 4000 rpm max /power: 30 kw / 22 kw continuous/ max torque: 500 nm /spindle nose: a2-8/ acceleration time: 5. 1 seconds • Type: 6" hydraulic chuck max speed: 4000 rpm max power: 26 kw / 22 kw continuous /max torque: 724 nm /spindle nose: a2-8 /acceleration time: 2. 7 seconds • Max speed: up to 20000 rpm (optional) /max power: 18. 5 kw/ max torque: 119 nm/ taper type: km63, capto c6, bt40 • X-axis: 410 mm/ y-axis: ±70 mm (total 140 mm) /z-axis: 805 mm/ b-axis (milling head): 210° rotation/ c-axis (spindle): 0. 0001° resolution (full contouring) • Max turning diameter: approx. ø545 mm/ max turning length: approx. 600 mm Pgjdpfx Ajyalpioirst • Tool capacity: 20 tools standard, expandable to 120 /changer type: high-speed cam-driven system • Heavy-duty construction with linear guides “done in one” multi-tasking concept for single-setup machining/ cnc control: mazatrol matrix with 3d simulation/ intelligent thermal shield for automatic thermal compensation

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 42 [mm] - Max. machining length : 110 [mm] - Spindle speeds : 6000 [rpm] - Spindle power : 5.5 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 42 [mm] - Spindle speeds : 6000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.001 [°] GUIDE BUSH HOLDER 1 - Number of positions : 5 END ATTACHMENT - Number of positions : 5 SECONDARY OPERATION - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] - Live tools power : 1.4 [kW] POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 25 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.880 x 1.375 [mm] - Machine height : 1.940 [mm] - Machine weight : 3300 [kg] MACHINE HOURS - Number of working hours : 18939 [h] Pgjdpfx Ajx S R Ntoirot EQUIPMENT - CNC : Fanuc 0i-TD - Interface : RS232 - Rotating guide bush - Ejection of workpiece - Parts catcher - Parts conveying strip - Chips conveyor - Coolant tank - Bar loader : LNS SPRINT 565 - Oil mist extractor

Condition: used, Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 5,000 rpm, HEIDENHAIN iTNC 530 CNC X-AXIS TRAVEL: 3000 MM Y-AXIS TRAVEL: 1400 MM Z-AXIS TRAVEL (Vertical): 1500 mm SPINDLE SPEED: 5000 RPM SPINDLE NOSE ATTACHMENT: SK 50 TABLE MEASURES: 3200 X 1100 MM TABLE LOAD CAPACITY: 10,000 KG Pgsdpfx Asxvrrhjirot 24-Place Tool Changer No. 02 Chip Conveyors Automatic Indexed Head a axis 2,5 ° b axis 3 ° YOM 2008

Condition: excellent (used), Year of construction: 2024, functionality: fully functional, CNC Turning- and Milling Center - Universal | Brand: DMG MORI | Type: CLX 450 TC Year of manufacture: 2024 B-axis factor – added value compared to any turret lathe: * Shortest set-up times thanks to automatic tool change with 60 tools * Eliminates the need for angle tools: B-axis with a swivel angle of +/-120° and 0.001° resolution Complete 6-side machining via main and counter spindles: * Maximum positioning accuracy and performance thanks to integrated spindle drives up to 5,000 rpm and 345 Nm, as well as an integrated C-axis (0.001°) * No driven toolholders required, thanks to the compactMASTER with 12.000 rpm and 90 Nm * Generous working area for components up to Ø 400 mm x 1.100 mm Operating hours (September 2026): - Operating hours: 4.351 h - Spindle hours: 1.967 h The machine can be inspected under power by prior appointment. Condition: As good as new / ready for operation. TECHNICAL SPECIFICATIONS: Working area Max. travel on X-axis: 750 mm Psdpez E A Uijfx Airsgt Max. travel on Y-axis: 200 mm Max. travel on Z-axis: 1.100 mm Workpiece Max. workpiece diameter: 400 mm Max. workpiece length: 1.100 mm Max. bar passage: 77 mm Main spindle as an integrated spindle motor Dynamic dual-pressure clamping Tailstock function for the sub-spindle Multi-thread cycle 2.0 EQUIPMENT: - Control system: SINUMERIK 840D sl Operate - 60-position chain magazine - Chip conveyor - Documentation - CE marking - A wide range of additional features ... Robo2Go loading and unloading system, offering flexibility with a 6-axis industrial robot. No guarantee is given as to the completeness or accuracy of the technical specifications or the equipment. - Subject to prior sale - Detailed technical data sheet and information on features are available upon request.

Condition: excellent (used), Year of construction: 2021, Great opportunity to buy an outstanding universal turning center (milling and turning) including automation with the Robo2Go: a flexible workpiece loading and unloading system with a six-axis-industrial-robot. The CLX 450 TC was built in 2021 and first used for actual production in 2022. About 9300 operating hours and only 3800 spindle hours. The Robo2Go was built in 2018, but is actually 'like new', because it was barely used. CNC control Celos X with SIEMENS Sinumerik One Max. turning diameter 400 mm Turning length 1100 mm Bar capacity max. 65 mm X-axis travel 276 mm Z1-axis travel 755 mm Z3-axis travel 775 mm Y-axis travel +/- 100 mm B-axis travel +/- 120° Pgedpfx Aijz Eg H Asret Tool holder HSK-T 63 Tool changer 60 positions Additional 1,000L coolant tank with programmable pressure 80-bar through-spindle cooling 60-tool tool changer Safety fence around robot Please check the full technical specifications and options in the attached documents. Optional: Large set of HSK-63 toolholders (without the inserted tools) The machine can be viewed in operation upon appointment. More pictures and videos available on request.

Condition: ready for operation (used), Year of construction: 2015, spindle speed (max.): 4,500 rpm, travel distance X-axis: 230 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 575 mm, spindle motor power: 26,000 W, overall weight: 5,700 kg, number of axes: 4, This 4-axis Mazak QTN 250 II MSY was manufactured in 2015. It features a maximum swing diameter of 640 mm and a maximum machining diameter of 380 mm. The machine includes a main spindle with a chuck diameter of 250 mm and a counter spindle with a chuck diameter of 210 mm. If you are looking to get high-quality turning capabilities, consider the Mazak QTN 250 II MSY horizontal turning machine we have for sale. Contact us for further details. -Information • • CNC control: MAZATROL MATRIX NEXUS 2 / MATRIX II • Working capacity: • Maximum swing diameter: 640 mm • Maximum machining diameter: 380 mm • Maximum machining length: 500 mm • Bar capacity: 77 mm • Axis travel: • C-axis rapid movement: 550 (as stated) • Tailstock travel: 500 mm (as stated) • Main spindle: • Chuck diameter: 250 mm • Nose: ASA 8 • Counter spindle: • Chuck diameter: 210 mm • Maximum speed: 5,000 rpm • Nose: ASA 5 • Driven tools: • Maximum speed: 5,000 rpm • Feed rates: • X-axis rapid traverse: 36,000 mm/min • Z-axis rapid traverse: 36,000 mm/min • Coolant tank capacity: 300 litres Additional equipment • Automatic loading and unloading system by MECCANO • FANUC ARC Mate 100iC/12 robot (per photos) • Tooling package as shown in the photographs and video • Assorted tool holders as shown in the photographs Technical Specification Podpfszpypujx Airegt Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 1999, operating hours: 110,000 h, functionality: fully functional, spindle bore: 42 mm, Description follows Psdpfx Asx A Ha Hjirogt
