CNC Laser Cutting Machine

Trumpf TruLaser 3030

Condition: used, functionality: fully functional, Year of construction: 2011, control type: CNC control, degree of automation: automatic, actuation type: electric, laser type: CO₂ laser, laser power: 5,000 W, FOR SALE: TRUMPF TruLaser 3030 L20 (5000 W) – High-Performance Laser Cutting Solution We are offering a high-quality, German-engineered TRUMPF TruLaser 3030 L20 laser cutting machine. Known for its reliability and precision, this 5000 W power-house is exceptionally well-suited for processing a wide range of material thicknesses with high efficiency. features custom configurations designed for high-volume series production. Technical Specifications: Model: TruLaser 3030 L20 Power: 5000 W Kdsdpfxjyluu Se Afdok Year of Manufacture: 2011 Max. Sheet Size: 3000 x 1500 mm Positioning Accuracy: 0.03 mm/m Max. Axis Speed: 140 m/min Cutting Speed: 0.8 – 26 m/min Maximum Cutting Capacities: Mild Steel (Baustahl): 25 mm Stainless Steel (Edelstahl): 20 mm Aluminum: 12 mm

Year of construction: 2026, condition: new, functionality: fully functional, The universal laser marking system LAS 28 from Systemtechnik Hölzer GmbH can be used for a very wide range of marking applications. With the integrated fiber laser you can mark almost all materials such as steel, carbide, aluminum and plastics. Depending on the requirements, the system can be equipped with a 20, 30 or 50 watt fiber laser. For permanent marking, the use of the laser is necessary in many industries. With the powerful laser software, texts, numbers, 2D codes, QR codes and logos can be realized with just a few clicks without extensive programming knowledge. Serial and article numbers are automatically incremented by the software after prior setting. In addition, the software can read data (variable information such as drawing numbers, project designations, etc.) from existing tables and automatically transfer them to predefined areas. The use of a hand scanner is also possible. The standard equipment includes a laptop incl. holder with Windows operating system. Optionally, the laser model LAS 28 can be equipped with a rotary axis (3-jaw chuck) for marking cylindrical parts. Further options, such as lateral extensions for marking long parts, can be realized. Made in Germany - Fiber laser 20W (Optional: 30W, 50W) - Wavelength 1064nm - marking field size 150x150mm (optional: 200x200) Kdsdpfev Sybyjx Afdok - optional: rotary axis (3-jaw chuck) - optional: digital height measuring system - optional: exhaust system (incl. activated carbon filter) - optional: Autofocus system - signal light for indication of operating status - marking software EZCAD (optional additional laser software) - Pilot laser (simple preview, contour preview) - focus finder (simple focus adjustment) - max. part height approx. 270mm - electrically adjustable Z-axis (adjustment of working plane) - frame made of aluminum profile - connection 230V - air cooled - Laptop with Windows operating system - dimensions: 800x 600 x 1660mm (LxWxH) - weight: approx. 80 Kg

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2011, control type: CNC control, laser type: CO₂ laser, laser power: 4,000 W, CNC Laser Cutting System Trulaser 3030 4000 Watt, with RotoLas X-axis working area max.: 3000 mm Y-axis working area max.: 1500 mm Z-axis working area max.: 115 mm Control: Siemens Sinumerik 840D Laser power: 4000 Watt Operating hours: 38,860 h Laser on-time: 13,767 h Sheet thickness max. for mild steel: 20 mm Sheet thickness max. for stainless steel: 15 mm Sheet thickness max. for aluminum: 10 mm Standard features: - Enclosed machine frame with integrated laser unit - Motion system for high-precision machining Kodpfxjy Ec Uue Afdsdk - Torque drive combined with linear direct drives - Sealed beam guidance - Single cutting head strategy - Cooling unit - Automatic longitudinal pallet changer - Wide longitudinal conveyor belt - 17" color touchscreen display - Work area lighting - Positioning laser diode - Spray device - PierceLine - FocusLine - NitroLine - PlasmaLine Cutting head: - LensLine with condition monitoring - Lens cutting head with 250 mm focal length - Universal quick-change cutting head device (UTI) - ControlLine: height control and sheet edge detection Control system: - Simple / advanced shop-floor programming - Fast reproduction - Integrated technology data - Automatic shut-off - ContourLine - FastLine - FlyLine - Microweld - Production schedule - AdjustLine - Teleservice Data transfer: - USB interface - RJ-45 network connection Safety: - CE marking - Light barriers - Multi-chamber extraction system - Compact dust extraction unit - Machine enclosure with polycarbonate windows + TruFlow 4000 + High-speed cutting head + RotoLas tube cutting device + Prepared for LoadMaster + Option for compressed air cutting

Condition: used, functionality: fully functional, Year of construction: 2006, Make: TRUMPF Model: TruLaser L 3030 – 4 kW Kdsdpfoyyyplex Afdek Year of manufacture: 2006 Working area: 3,000 x 1,500 x 115 mm Control: Siemens Sinumerik 840 D Laser power: 4,000 Watt Operating hours: Laser On 54,137h, Beam On 18,589h

Condition: good (used), Year of construction: 1998, machine/vehicle number: 98095307, Offer 24271 Technical data: - max. working width 3050 mm - max. cutting capacity St 40 6 mm - Cutting angle adjustable mot. 0.5 - 3 ° - Cutting gap adjustment by hand - Number of hydraulic hold-down devices 18 pcs. - mot. Rear fence with positioning control 10 - 1000 mm - Front angle fence - Stroke rate depending on cutting angle and cutting length 9 - 17 per/min - Pneumatic connection 6 bar - Hydraulic drive 400 V / 15 kW - Table height 770 mm Kdedpfet Tw Uiox Afdek - Space requirement incl. back gauge, - approx. W 4050 x H 1600 x D 2450 mm - Weight approx. 5500 kg - with: - E-foot switch - Cutting line lighting - Sheet support - Rear guard with protective grille

Condition: used, functionality: fully functional, 1. BALL RECIRCULATING UNIT KUVE20-B-1947 PART NO.: 386954 1 PC. Machine: T3030 L20 COUNTRY OF ORIGIN: FR 2. WATER MANIFOLD COMPLETE PART NO.: 1996899 1 SET Machine: T3030 L20 3. WELDING HEAD WS OPTICS 1 SET Machine: T3030 L20 4. CUTTING HEAD LENS 250 D40 – 17616 PART NO.: 1497234 1 PC. Machine: T3030 L20 COUNTRY OF ORIGIN: DE 5. (R)GRID VOLTAGE UNIT PART NO.: 0983675 1 PC. Machine: T3030 L20 Ksdpfox Uzblsx Afdjdk 6. BELLOWS Y-AXIS 93614-102-40 PART NO.: 0141394 1 PC. Machine: T3030 L20 7. EXPANSION VALVE TGEN 25TR MOP70 R134a PART NO.: 1627195 1 PC. Machine: 3030 6kW 8. BELLOWS X-AXIS 1854032 PART NO.: 606083 1 PC. Machine: T3030 L20 COUNTRY OF ORIGIN: IT 9. TRIODE UP TO 4KW RS3021CJ PART NO.: 903994 1 PC. Machine: T3030 BRAND: THALES 10. FILTERS 8 PCS. Machine: T3030 11. BELLOWS Y-AXIS PART NO.: 1226193 1 PC. Machine: T3030 5kW 12. DISK BELLOWS Y-AXIS PART NO.: 1353514 1 PC. Machine: T3030 5kW 13. BOX BELLOWS PART NO.: 0978079 1 PC. Machine: T3030 5kW

Condition: excellent (used), functionality: fully functional, Year of construction: 2009, Beam on: 17,540 h Laser on: 45,508 h Kedsyyyilopfx Afdjdk

Condition: excellent (used), functionality: fully functional, Year of construction: 2014, Operating hours: approx. 22,800 h Laser on: approx. 40,100 h Voltage: 400 V Frequency: 50 Hz Power: 3,200 W Kodpfx Afsyyygkodedk

Condition: excellent (used), functionality: fully functional, Year of construction: 2007, operating hours: 30,000 h, laser power: 3,200 W, sheet thickness steel (max.): 20 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 115 mm, AVAILABLE FOR A SHORT TERM: TRUMPF TruLaser 3030 – 3.2 kW – Year 2007 with RotoLas! TECHNICAL DATA: Make: TRUMPF Type: TruLaser L 3030 – 3.2 kW Year of manufacture: 2007 Working area: 3,000 x 1,500 x 115 mm Control system: Siemens Sinumerik 840 D Laser power: 4,000 watts Max. sheet thickness mild steel: 20 mm Max. sheet thickness stainless steel: 12 mm Max. sheet thickness aluminum: 8 mm Operating hours: NC on 30,000 h (Oct. 2024) Machine regularly serviced by TRUMPF! Transmitter tube: new 2024 TASC laser control: new 2022 Driver stage: replaced 2018 Magnetic bearing electronics: new 2016 STANDARD EQUIPMENT: - Enclosed machine frame with integrated laser unit Laser unit: TLF 2000 CO2 laser with high-frequency excitation, maintenance-free turbo radial blower, Reflector telescope, cooling unit, logbook function - Automatic pallet changer - Longitudinal conveyor belt for small parts/waste - Drives: Maintenance-free three-phase servo motors - Cutting head quick-change device - Laser cutting head with 5" lens and laser cutting head with 7.5" lens - Programmable cutting gas pressure setting - APC capacitive height control and process control - Automatic focus position adjustment AutoLas Plus - Laser power control - Positioning laser diode - HI-LAS High-pressure cutting Kdedpfx Afsu Afcbsdsk - Fast processing with SprintLas - ContourLas for producing small holes - PMS plasma sensors - Automatic sheet metal edge detection - Programmable power cycles - Microweld - Automatic shutdown - Workspace lighting - Sinumerik 840D control system: open PC-based control, easy operation, online help, integrated e-shop, diagnostic functions, maintenance logbook, technology data, teleservice - ToPs 100 lite workshop programming - Safety: multi-beam light barriers, fully encapsulated and ventilated beam guidance, monitoring system, multi-chamber extraction and compact dust collector, protective cabin - 3.5" floppy disk drive - TFT color screen - Electrical equipment: Voltage 400 V / 50 Hz - Paint finish: Standard RAL 9002/5010 EXTENDED EQUIPMENT: - TruFlow 3200 laser including lens monitoring sensors - PCS Process Control System - Preparation for LiftMaster - RotoLas pipe cutting system for cutting pipes and profiles

Condition: used, functionality: fully functional, Year of construction: 2018, With Slat Conveyor, Riedel Chiller Unit, Trumpf Dust Extraction Unit, Sick Safety Light Curtains, Signal Tower & Manuals. Overall Machine Dimensions L9,300 x W5,100 x H2,400mm. Kdsdpfxsyx Hm Ie Afdjk Working Range 'X'=3,000mm, 'Y'=1,500mm, 'Z'=116mm. Maximum Table Load 1,100kg. Maximum Simultaneous Table Feed 140m/min. Maximum Laser Power 6,000W. Wavelength 1,080nm. Mean Bidirectional Positioning Accuracy ±0.05mm, Bidirectional Positioning Error A (ISO 230–2:2014) ±0.06mm. Maximum Sheet Thickness Mild Steel 20mm. Maximum Sheet Thickness Structural Steel 25mm, Maximum Sheet Thickness Stainless Steel 25mm, Maximum Sheet Thickness Aluminium 25mm, Maximum Sheet Thickness Titanium 4mm. Maximum Sheet Thickness Copper 10mm, Maximum Sheet Thickness Brass 10mm. S/No. A0221E1080 (2018)

Condition: excellent (used), functionality: fully functional, Year of construction: 2019, TruLaser 3030 L81 – FIBER 4000W Kjdpfx Ajyxc D Asfdodk Laser on: approx. 13,300 h Machine on: approx. 26,300 h

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2011, machine/vehicle number: 908, laser power: 3,200 W, travel distance X-axis: 1,500 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 600 mm, No minimum price – guaranteed sale to the highest bidder! Bids are binding and require collection within the period from 08/04/26 to 16/04/26! TECHNICAL DETAILS X-axis travel: approx. 1500 mm Y-axis travel: approx. 4500 mm Z-axis travel: approx. 600 mm Laser power: 3.2 kW Table dimensions: 3500 x 2000 mm MACHINE DETAILS Lifting device model: TRUMPF LOADMASTER Kdjdeylalvopfx Afdjk Number of suction units (lifting device): 12 Lifting device features: Light barrier system Dimensions & Weight Dimensions (L x W x H): 12000 x 7000 x 2400 mm Machine weight: 15 t EQUIPMENT Shuttle table Additional laser head Accessories Note: The laser cutting system can be transported on trucks up to 3000 mm wide and therefore does not require a special permit. External reference: 18
