Vertical turret lathe

UMARO SC 14 CNC FANUC Oi TC

Condition: excellent (used), Year of construction: 1983, Faceplate diameter: 1250 mm Max. swing diameter: 1400 mm Max. swing height: 1160 mm Max. ram stroke, vertical / horizontal: 755 / 840 mm Table load capacity: unlimited Faceplate speed range: 5.6 - 300 rpm Vertical slide angular adjustment: 45° Feed rate range: 0.044-8 mm/rev Rapid traverse rate: 2 m/min Drive power: 55 kW Footprint L x W x H: 2660 x 2710 x 3360 mm Total weight: 16,500 kg Pjdsy Ex Epopfx Anyorb Accessories / Special features: • 2-axis digital display, manufacturer: ACU-Rite • Faceplate, Ø 1250 mm, with 4 chuck jaws • 5-position turret • Taper turning • Profile turning Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: good (used), Year of construction: 1999, functionality: fully functional, turning length: 3,000 mm, turning diameter: 1,000 mm, spindle bore: 197 mm, Upon request, videos of the machine in operation can also be provided. Maximum turning length: 6000 mm Turning diameter: over cross slide: 1000 mm over bed: 1250 mm Podpfxjyr N N Rj Anyerb Spindle bore: 197 mm Spindle speeds: 0 – 665 rpm Faceplate diameter: 1200 mm Workpiece weight: 15000 kg between centers Motor power: 55 kW / 74 hp 3 gear stages: 1.5-55 / 50-180 / 180-665 rpm Accessories: Sauter 4-position tool turret (rotation defective) Tailstock (hydraulics partially defective, pressure loss) Chip conveyor 2 chip guard doors (incl. safety device) 4-way bed machine (flat bed) LED lighting

Condition: used, Year of construction: 2007, functionality: fully functional, Technical data of the VTC-100R: - Swing diameter 1,250 mm - Turning diameter 1,000 mm - Turning height 850 mm - Drive power 45/55 kW - Max. torque 582 kg/m - Rapid traverse rates (X/Z) 20 m/min - Max. workpiece weight 1,500 kg - Machine weight 23 t - Footprint 2,800 x 5,200 mm - Control system Fanuc 32i-TA (10.4" color LCD) - C-axis - 12-position Baruffaldi turret VDI60 - 6 positions for driven tools - Hydraulic chuck (32") with hard and soft jaws - Clamping cylinder - Hydraulic unit with draw tube - Coolant system - Work area protection - Telescopic guard X/Z - Foot switch for hydraulic chuck - Work area lighting - 3-color indicator light - Mounting elements - Chip air blow-out system - Tool holder VDI 60 - Complete documentation Options (included): - Chip conveyor - Automatic door - Customer macro B - Automatic workpiece measurement - Oil mist extraction - Tool setter - Coolant high-pressure system - POLO filter system, 20 bar Podpszmd Ucjfx Anyjrb - Chip conveyor incl. hoses

Condition: used, Year of construction: 2013, Year 1978 Retrofit 2013 max. turning diameter 1300 mm table diameter 1000 mm workpiece height max. 1500 mm working lenght 1050 mm 280 U/min. T-slots 48 x 28 speeds 4,75 - 250 U/min rapid traverse 6000 mm/min In our opinion, the machine is in good used condition and can be inspected condition and can be inspected under power by appointment. Prsdpfx Anoxmk E Uoyeb Retrofit 2013 Precision class: IT7 Technical features - 4-fold swivel head Accessories, illustrated tools and clamping devices are only included in the scope of delivery if this is noted in the additional information Changes and errors in the technical data and information as well as prior sale reserved.

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, Vertical turning lathe with a 2,200 mm table diameter and an approx. 2,500 mm swing diameter. The base machine is from the Chinese manufacturer QQHR (well-known manufacturer). The entire electrical system, including the main motor, servo drives, control cabinet, and PLC, was completely renewed and professionally overhauled by Paulmann (Germany) in 2017. Predpfeycgxkex Anyjb

Condition: good (used), Year of construction: 2006, control Rexroth Prodswzmriepfx Anysb
