Planer-Type Milling M/C - Double Column

WALDRICH COBURG Valutec

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 3.6002, travel distance X-axis: 4,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, table load: 12,000 kg, TECHNICAL DETAILS X axis: 4,000 mm Y axis: 3,000 mm Z axis: 1,500 mm Passage height: 1,550 mm Passage width: 2,500 mm Table width: 2,000 mm Table length: 3,000 mm max. table load: 12,000 kg Tool holder: HSK-A100 max. tool weight: 30 kg max. tool diameter: 250 mm max. tool length: 500 mm Drilling spindle speed range: 5–6,000 rpm max. permissible torque at milling spindle: 800 Nm MACHINE DETAILS Dsdpfx Ajxvrb Nokmewc Total power requirement: 30 kW Space requirement approx.: 9.5 x 6.7 x 6.2 m EQUIPMENT Demmeler pallet changer

Condition: used, Year of construction: 2016, x-axis 6.800 mm y-axis 4.000 mm z-axis 1.500 mm Control iTNC 530 HSCI Heidenhain distance between columns max. 5.090 mm distance spindle center to table 1.825 mm type 175149A-0007 Dsdpszf Nn Ssfx Akmswc turning speed range - main spindle max. 19.800 min/-1 power capacity - main spindel 20 kW tool taper HSK-A63 swivellable B: +115° / -115 ° rotatable C: +/- 200 ° type 178099-0005 turning speed range - main spindle max. 10.020 min/-1 power capacity - main spindel 20 kW tool taper HSK-A100 swivellable B: +115° / -115 ° rotatable C: +/- 200 ° table surface area 6.000 x 3.000 mm max. table load 50,0 t height over floor 100 mm number of T-slots 12 T-slot - width 28H12 mm T-slot - distance 250 mm number of toolpositions 62 (38+24) pos. number of toolpositions HSK A63: 37+1 pos. number of toolpositions HSK A100: 23+1 pos. max. tool diameter HSK A63: 52 mm max. tool length HSK A63: 250 mm max. tool weight HSK A63: - kg max. tool diameter HSK A100: 80 mm max. tool length HSK A100: 450 mm max. tool weight HSK A100: - kg rapid traverse ( X / Y / Z ) 40.000 mm/min rapid traverse B/C: 4.320 °/min feed speeds X/Y/Z: 30.000 mm/min Working speed B/C: 2.160 °/min Accelaration max. 3,2 m/s² x-axis 6.800 mm y-axis 4.000 mm z-axis 1.500 mm b-axis +115° / -115 ° c-axis +/- 200 ° total power requirement 180 kVA dimensions of the machine ca. 12,5 x 15,0 x 7,0 m 5-Axis-High-Speed-Gantry-Big-Machining-Center DROOP & REIN - FOGS 40 60 C - Fork head

Condition: like new (used), Year of construction: 1987, Used Giddings and Lewis Model MC 50 Twin Pallet Horizontal Machining Centre with Live Spindle, 60 ATC and G&L 8000A Control System. Serial # 445-1052.Year of Manufacture: 1987 Machine Formerly Installed at Rolls Royce Plc In Derby UK. Immediately for Sale and now Located in Belgium where it can be Inspected. Spindle Diameter - 130 MM Spindle Taper - 50 ISO Spindle Travel (Z Axis) - 915 MM Dwsdpfx Asu Dahnjkmjc Spindle Speeds (4 Ranges) - 5 to 1500 RPM Main Motor - 30 HP Pallet Size - 1219 x 1245 MM Pallet Rotation Increments - 0.001 DEG (360,000 POSITIONS) Pallet Changer Max Load - 5000KGS Pallet Max Load Without APC - 9000 KGS Longitudinal Travel (W) - 1700 MM Vertical Travel Of Head (Y) - 1500 MM Cross Travel (X) - 1800 MM Feed Rates Per Minute - 1.00MM/MIN TO RAPID RATE Rapid Traverse Rate Per Minute (X And Y) - 4500 MM / MIN Rapid Traverse Rate Per Minute (Z And W) - 3000 MM / MIN Auto Tool Changer - 60 POSITIONS Electrical Supply - 415V, 3PH, 50HZ FEATURES AND EQUIPMENT High Pressure (25 Bar) Through Spindle Coolant, High Tolerance Machine. Accurate Machine which was well Maintained and Regularly Calibrated by Manufacturer. Renishaw Probing. Length - 11679 MM Width - 6502 MM Height - 4423 MM Weight - 40329 KGS

Condition: used, Year of construction: 1974, x-travel 9700 mm y-travel 3500 mm z-travel 640 mm w-axis 3000 mm Control Siemens type 840D PL spindle diameter 200 mm Spindle capacity 85 Kw surface area 9000x2800 mm Table load 40000 kg column daylight 3400 mm high speed spindle taper ISO 50 weight of the machine ca. 193,8 t dimensions of the machine ca. 22,4x10,2x8,2 m Retrofit 2009 Steep taper ISO 60 DIN 2079 Speed ??12-450 rpm Milling heads: 1x WF 680/450 1x WFU 180/350 1x WFU 70/300 1x 550 mm extension for WFKs The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Dwedpfoyq Sxlex Akmjc About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1996, functionality: limited functionality, CNC-Planer-Type Milling M/C - Double Column (Milling and Turning Center) | Brand: DÖRRIES SCHARMANN | Type: 4FZT | Year of construction: 1996 A high-performance gantry milling machine designed for machining large workpieces. Its primary applications include the milling and turning of large, complex workpieces. The machine can be inspected under power by appointment. Condition: Consistent with the year of manufacture; some parts require refurbishment. - A high-quality machine, and therefore well worth modernization / a complete overhaul / highly recommended. TECHNICAL SPECIFICATIONS: Main Dimensions: - Machine width: 13.230 mm - Machine height over the floor: 8.450 mm - Machine length: 31.100 mm - Working length: 11.000 mm - Clearance width: 4.400 mm - Clearance height from the table surface to the spindle nose of the standard milling head: 3.000 mm Table: - Table width: 3.450 mm - Total table length: 13.400 mm - Length of individual table: 6.200 mm - Total clamping area: 3.450 x 11.000 mm - Clamping area of single table: 3.450 x 5.000 mm - Maximum total workpiece weight: 112 tons - Maximum workpiece weight per table: 80 tons Crossbeam: - Travel: 2.000 mm Milling and boring support: - Drive power for milling and boring (spindle): 80 kW - Max. speed of the drive shaft (spindle): 2.500 rpm EQUIPMENT / ACCESSORIES: - 2 tables - 8 machining heads - Control: SINUMERIK 880 - 2 x chip conveyors - Documentation - CE marking No guarantee for completeness and accuracy of technical data and equipment. - Subject to prior sale - Detailed technical data sheet and information on equipment available on request. Dwsdpfx Akoyuptzomoc

Condition: like new (used), Year of construction: 2010, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 8500 x 2500 mmNumber of T slots: 17T slots dimensions: 22 mm Traverses of axis X axis traverse: 8000 mmY axis traverse: 3800 mmZ axis traverse: 1500 mmVertical capacity (VC): 168 / 1668 mmDistance between columns: 3100 mm Milling head Auto-indexing differential head (UAD - 0,02º)Tool clamping system: HydraulicTaper nose: ISO50 (DIN69871) / Pull stud: DIN69872Speed range: 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 35000 kgMachine weight approximate: 79000 KgMachine dimensions approximate: 22700 x 7660 x 6800 mm Accessories Guarding: 2 sliding doors with a new perimetral wire-mesh fenceAutomatic tool changer: ATC-60Chip conveyor: 2longitudinal hinge typeElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sale conditions Warranty: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features Dwodpez Alwqsfx Akmsc
