Vertical turning lathe

Webster & Bennett EVOLUTION R48R

Condition: used, WEBSTER & BENNETT EV 36” HIGH SPEED VERTICAL BORER Ijdpfxsxp Na Ne Anwsic MAKE WEBSTER & BENNETT, MADE IN ENGLAND MODEL EV 36” TABLE DIA 915 mm SWING 1168 mm HEIGHT UNDER RAIL 533 - 1016 mm SPEED 13.5 - 300 rpm FEED RATE 0.005-0.250 inch/min MAIN SPEED 40 HP PLUS HIGH SPEED TAABLE EV SERIES MACHINE ELEVATING RAIL SAFETY GAURDING SET OF JAWS FULLY FUNCTIONAL GOOD SLIDES

Condition: used, faceplate diameter 3100 mm swing diameter 3600 mm Iiodsyqt Hdepfx Anwec turning height 3600 mm control Fagor 8035 table load 35 t turning speeds 0,32 - 40 U/min max. ram stroke 3000 mm table load 35 t turning speeds 0,32-40 U/min total power requirement 70 kW 2x Ram head 250 x 250 mm Chip conveyor Mist extraction unit Coolant system The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 1997, Ref. -No.: 10620 Manufacturer: SKODA Type: W 200 T Year of construction: 1997 Type of control: CNC-Steuerung Control: SIEMENS SINUMERIK 840 Storage location: Halberstadt Country of origin: Germany X-Travel: 16000 mm Y-Travel: 5150 mm Z-Travel: 1600 mm W-Axis: 2100 mm V-axis: 2000 mm B-Axis: 0 - 360 ° Spindle Diameter: 200 mm Table Load: 80.000 kg Tool Taper: SK 60 / SK 50 Turning Speeds: 1000 RPM Rotary table diameter: 3500 x 3000 mm Iijdoyagidspfx Anwsc Further information: Including angle head Machine can be inspected under power.

Condition: used, Year of construction: 1987, faceplate diameter 3600 mm swing diameter 4500 mm Iiedpfx Aneyz Db Uewsc turning height 1850 mm turning speed range 0,6- 50 U/min weight of the machine ca. 72 t verticale turning machine double coloumn - digital scale - double coloumn - 2x ram - movable cross slide - extra toolholder (four station) on the side of facing plate

Condition: refurbished (used), Year of construction: 1987, functionality: fully functional, turning diameter: 4,300 mm, faceplate diameter: 4,000 mm, Vertical Turning Lathe SC43 CNC, retrofitted and upgraded with CNC Fanuc 0𝑖-TF Plus Made in Romania by TITAN Year of manufacture: 1987 The machine was completely retrofitted in 2026 Main technical data: FACE PLATE DIA. MM 4000 MAX. SWING MM 4300 MAX HEIGHT UNDER THE CROSSRAIL MM 2000 MAX. LOADING ADMITTED KG 18,000 FACEPLATE SPEED RANGE 1-92 RPM FEEDS RANGE MM/ROT 0.05-5 CARRIAGE RAPID FEEDS MM/MIN 2500 MAIN D.C. MOTOR POWER KW 55 SIEMENS WITH SIEMENS DRIVER MACHINE WEIGHT APPROX. 63 TONS The machine has the following brand new components: - New electrical equipment with parts made by Schneider, Shrack, Siemens, with a new cabinet - New control panel - New micro switches Iiodpfjy A Iifex Anwoc - New hydraulic pump and components - New pump for guideway lubrication, and the entire installation was redone - New CNC Fanuc 0𝑖-TF Plus 55KW Main motor, Siemens, refurbished in 2018 with Siemens driver The main gearbox was checked and refurbished with new bearings. The machine was repainted. We grant a 6-month guarantee for parts. We can send more photos and a video showing the machine’s precision measurements. Do not hesitate to contact us.

Condition: used, Technical details: Iijdpfxjx Ngzyj Anwsc turning diameter over bed: 3800 mm turning diameter over slide rest: 3200 mm turning length: 12000 mm faceplate turning speed range -stepless-: 2 - 200 U/min max. workpiece weight: 90.000 kg bed width: 4000 mm 2 steadies *

Condition: good (used), Year of construction: 1982, VERTICAL TURNING LATHE SC22 Year of manufacture: 1982 Manufacturer: I.M. ROMAN (Romania) Main technical data: - Table diameter: 2000 mm - Max. swing: 2200 mm - Max. workpiece height: 1500 mm - Max. workpiece weight: 12000 kg - Table speed range: 2–92 rpm - Vertical travel (Z axis) of rail head: 1200 mm - Main motor, DC type: 55 kW - Machine weight approx. 31000 kg Accessories: Isdpfx Ajyzxafsnwsic 4 jaws for faceplate The machine is under power. For more details please contact us.

Condition: new, Year of construction: 2025, functionality: fully functional, turning height: 1,600 mm, turning diameter: 2,000 mm, CNC Vertical Turning Center Model: VTC-16/20R with Fanuc 31i-B Table Diameter: Ø1,600 mm Max. Swing Diameter: Ø2,000 mm Max. Turning Height: 1,600 mm Table Speed: Max. 250 rpm Table Load Capacity: 8,000 kg Table Indexing Speed: 720°/min Table Indexing Accuracy: 0.001° X-Axis (Ram horizontal): -100 mm to 1,170 mm Z-Axis (Ram vertical): 900 mm Drive Spindle Speed: Max. 2,000 rpm Ram Size: 240 mm x 240 mm Milling Spindle Taper: ISO 50 Tool Shank Size: 40 mm x 40 mm Crossrail (vertical travel): 250 mm x 3 stages (hydraulic) Table Drive Motor: AC 37/45 kW (continuous/30 min. duty) Milling Spindle Drive Power ISO 50: 15/18.5 kW (continuous/30 min. duty) Iodpfexp Nb Tjx Anwsic Control System: Fanuc 31i-B Display Unit: 15-inch TFT-LCD Memory Capacity: 1 MB Automatic Tool Changer: 24 positions (for 7 turning tools + 1 cover + 16 milling tools) Standard Tool Holders: New 240 TCR-01 (2 pcs) Splash Guard: Table version (R-Type standard design) External Coolant System: 3 bar (80 l/min) Chip Conveyor: Hinged belt type Table Bearing Cooling Device 4-Jaw Independent Manual Chuck Foundation Anchor Bolts / Base Plates Maintenance Tools and Toolbox Hydraulic Power Unit Work Area Lighting Signal Lamp: 3 colors (green, red, yellow) Operating Manuals (English): 1 CD with Fanuc manuals and 3 books with mechanical/electrical manuals Power Supply: 220 V, 60 Hz, 3-phase Machine Color: Manufacturer standard OPTIONAL ACCESSORIES (#1) Turning Tool Holder: Type 240TCR, 4x included Rigid Tapping: 1x included OPTIONAL ACCESSORIES (#2) Automatic power-off for N.C. - on request Turning tool holder type 240TCR - on request Through-spindle coolant supply: 30 bar (pump pressure) - on request Transformer 415 V, 50 Hz, 3-phase - on request Linear scales X-, Z-axis (Fagor, Spain) - on request Workpiece measuring device - on request Tool measurement TS27R, Renishaw - on request Other information: INSTALLATION, COMMISSIONING, TEST OPERATION, AND TRAINING - not included in the price INSURANCE AND FREIGHT - not included in the price Image shows machine with pallet changer. The offered machine DOES NOT INCLUDE A PALLET CHANGER! Errors in technical data excepted. The scope of accessories is as described in the text of this article only. There is no entitlement to any other accessories, such as those shown for illustration purposes. The general terms and conditions of JS-Werkzeugmaschinen GmbH apply.

Condition: good (used), travel distance X-axis: 12,000 mm, travel distance Y-axis: 7,300 mm, travel distance Z-axis: 3,000 mm, total length: 30,000 mm, table length: 12,000 mm, table width: 4,730 mm, total width: 12,000 mm, total height: 10,475 mm, table load: 250,000 kg, overall weight: 400,000 kg, Make : Waldrich - Siegen - Typ : PF-F-150(1)-530/400 - No. : 11.093/0 - Age : Overhault 2004 ( Euro 2.2 Mil) X Travel : 12.000 - Y Travel : 7.300 - Z Travel : 3.000 - W Travel : 4.000 - Between column : 5.000 - Table width : 4.730 - Table length : 12.000 - Table load : 19 t / mtr. Ca. 250 ton - Table feed : 10.000 mm/min. - W axis : 3.000 mm/min. - T axis : 6.000 mm/min. - Cross adj. milling head : - Vert. adj. cross rail : Iedpfx Anjytrxkowjic - Horizontal hydrostatic spindle ram - Milling spindle Ø : 560 - Milling tool taper : iso 60 - C axis feed : 5.000 mm/min. - Milling motor : 90 kW - Spindle speed : 2.500 R/pm - Z axis stroke : 3.000 - Z axis feed : 2.000 mm/min. - Milling Küma Angle head WF2 90 kw- 450 - Milling Küma Uni. UB1D 60 kw - 2400 - Milling Küma Fixed GB1D 90 kw- 2400 - Milling Küma Angle head WF1? - Electric requirement : 3 x 400 V / 50 Hz - Power requirement : 600 kVA / 630 Amp - Capacity 4.000 L coolant true spindle 20/40 Bar Machine is rebuild in 2004 by Schiess Bed – Table assembly group: * Renewal of sliding lining * Grinding of guideway * Renewal of table drive * Direct linear measuring syst. * Hydrostatic Portal and cross rail: * Modification of adjusting spindle trape Zoidal spindle was recplaced with ball screw * Direct linear measuring syst. * New drive motors for relization of higer speed on feed axes of milling support. * New milling support with hydrostatic guideways Electric system: * Complet elctric cabinet switchgear * Complet new wire * Siemens Sinumrik 840 D in 6 axis !! Equipment / parts : * Complet new raumag janich covers * Complet new double chip conveyor * Complet with big tooling packet * Complet with big mounting equipment - Under power in Europe - Free directly - Controlled axis X / Y / Z / W / C / B axis - Over all height : 10.475 mm - Over all width : 11.934 mm - Over all length : 30.000 mm - Total weight : ca. 400.000 Kg Rebuild in 2004 for EUR 2.200.000 !This CNC Waldrich Portal milling machines was used in the Energie Field for steam turbien case machining. Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 1974, x-travel 9700 mm y-travel 3500 mm z-travel 640 mm w-axis 3000 mm Control Siemens type 840D PL spindle diameter 200 mm Spindle capacity 85 Kw surface area 9000x2800 mm Table load 40000 kg column daylight 3400 mm high speed spindle taper ISO 50 weight of the machine ca. 193,8 t dimensions of the machine ca. 22,4x10,2x8,2 m Retrofit 2009 Steep taper ISO 60 DIN 2079 Speed ??12-450 rpm Milling heads: 1x WF 680/450 1x WFU 180/350 1x WFU 70/300 1x 550 mm extension for WFKs The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Iedpfx Anoyq Sxlewoic Your Markus Hirsch Team
