Lead/traction spindle lathe

WEILER LZ 280

Condition: excellent (used), Henri Hauser M5 DR jig boring machine spindle diameter 90 mm x-travel 700 mm y-travel 500 mm Drilling capacity in steel 40 mm spindle mounting MK 4 drilling spindle stroke 170 mm number of spindle revolutions 2 Fodpfx Aeg Ibuxjg Tspd infinitely variable 10-2000 rpm Boring diameter max. 230 mm Table dimension - longitudinal 900 mm Table dimension - crosswise 770 mm Vertical travel of cross beam 630 mm Drilling spindle 6 pieces from/to 0.02-0..20 rpm Clearance between uprights 900 mm Passage between spindle and table 815 Spindle motor 4.0 HP Total power requirement 380 V Machine weight approx. 3.9 t Complete factory closure, large selection of storage platforms, pallet racks, shelf racks, paternosters. High-quality industrial machines, lathes, grinding machines, hand machines Financing through our bank is also possible. komplett-konzept.leasingo.de Further articles - new and used - you will find in our shop! International shipping costs on request!

Condition: used, Technical details: bore capacity in steel (diameter): 16 mm throat: 190 mm bore stroke: 60 mm Distance spindle/table max.: 250 mm range of revolution per miute: 410 / 725 / 1100 / 1700 bei 4step U/min spindle taper MT: MK 2 table surface area: 155 x 155 mm vertical adjustment: Tisch/table = 180 mm Fpjdpeu Id Dzefx Ag Tjd table rotating: 360 ° base plate surface area: 175 x 175 mm distance spindle center to floor plate:: max. 360 mm column diameter: 70 mm machine weight ab.: 65 kg dimensions L x W x H: 0,6 x 0,3 x 0,85 m Drill sleeve equipped with drill chuck 1 - 16 mm table rotatable *

Condition: used, Technical details: grinding wheel diameter: 200 mm voltage: 220 380 V / Hz revolution per minute: 3000 U/min total power requirement: 900 Watt weight: 22 kg dimensions L x W x H: 0,23 x 0,46 x 0,25 m Double sanding block; table-top unit Fodpfxou Ngu Se Ag Tepd with sanding supports left/right, horizontally adjustable 30mm max. sanding discs Ø 200mm max. grinding wheel thickness 32mm currently clamped sanding discs on the sanding block: left = Ø 190mm x 30mm type H50 and right = Ø 180mm x 32mm type M20 *

Condition: used, Year of construction: 2003, Technical details: bore capacity in steel (diameter): 25 mm throat: 255 mm bore stroke: 140 mm spindle taper MT: MK 3 spindle speed:: 105 - 2980 / 8step U/min Distance spindle/table max.: min.: 350 / max.: 950 mm table clamping surface:: 420 x 270 mm table rotating: 360 ° table swivable approx.: 30° links / rechts drill table adjustment: 600 manuell mm column diameter: 100 mm Fpedpfju Idhysx Ag Tod current- max.: 400 V / 50 Hz A total power requirement: 0,9 kW weight of the machine ca.: 180 kg dimension machine xH: 0,6 x 0,5 x 1,8 m Equipment: Röhm quick-action chuck 3 - 16mm Switchover for clockwise/anticlockwise rotation for thread cutting *

Condition: used, Year of construction: 1985, machine/vehicle number: 113785, 4 - station tool grinding machine pre-grinding - disc 200 x 50 x 51 mm - table size 400 x 200 mm re-grinding - disc 200 x 50 x 51 mm - table size 400 x 200 mm lap grinding - disc / diamant 125 - 12.5 x 51 mm - table size 400 x 200 mm chip groove - disc - 150 x 8 x 51 mm coolant device  Fpedpog H Ng Djfx Ag Ted workplace lamp motor speed 1,400 x / 2,800 rpm electrical data 380 V / 0.37 / 0.6 KW space requirements width - 1,100 x depth - 1,000 x height - 1,400 mm weight approx. 340 kg

Condition: used, operating hours: 338 h, power: 38 kW (51.67 HP), gearing type: mechanical, fuel type: diesel, first registration: 12/2021, overall weight: 3,000 kg, mileage: 336 km, empty load weight: 1,925 kg, axle configuration: 2 axles, tire size: 250/80R18, tire condition: 85 %, number of seats: 2, wheelbase: 1,460 mm, Equipment: additional headlights, air conditioning, cabin, cruise control, fog lights, front power take-off, SRX 5800 TORA with REDCAB cabin | Equipment: with adjustable rims | comfortable RED-CAB cabin with wide-opening doors | RevGuide reversible seat system | ACTIO chassis for optimal ground adaptation | 4-cylinder 16V YANMAR turbo diesel engine with CommonRail direct injection | Synchronized 32-speed shuttle gearbox with 16 forward and 16 reverse gears | PTO 540 and 540e | Radio | Air conditioning | Operating hours: 336h | Subject to errors, input mistakes, and prior sale. Fpedpfsxnbfnox Ag Tsd

Condition: reconditioned (used), Steel grinding machine Make REMA Model DS 07/ST version with pole-changing motor 0,22/0,37 kW 1450/2900 rpm year of manufacture unknown Ma.-No. 022857 Equipment: - Reversing switch right/left rotation - column design with chip tray - Wet grinding device - 2 pcs. support table ATS (left) inclinable from -5° to +15 and with spring rockers - 2 pcs. angular stops - adjustable support table ATK (right) for grinding chip grooves - steel holder for support table ATK 360° rotatable, swiveling, with height adjustment and knurled screw for adjustment of chip depth - enlarged protective hood (left) Fpsdpfx Agjhvu Tmo Ted with silicon carbide cup wheel Ø 175 mm with mounting flange - protective hood (right) for grinding wheels Ø 125 mm with mounting flange - Operating instructions used as seen, without warranty

Condition: good (used), Year of construction: 1965, Model maker milling machine with swivel head, MK 4, rotary table, d. Accessories Fpodpfx Aeq Ixz Reg Tod Year of construction: 1965 X (mm): 1000 Y (mm): 600 Mounting (iso/mk): 4 Power (kw): 2

Condition: excellent (used), jaw width: 103 mm jaw height: 37 mm span length: 175 mm place requirement: 600 x 180 x 150 mm weight: 27 kg Fodpfxefgx R Ue Ag Tepd

Condition: excellent (used), Deckel FP1 AKTIV (3-Axis Active) Machine no.: 2102-3240 Year of manufacture: approx. 1988 Travel paths: X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 – S20x2 Spindle speed: 40–2,000 rpm Motor power: 1.6 and 2 kW Power supply: 380 V, 50 Hz Equipment/Accessories: - Active digital readout, 3 axes, HEIDENHAIN type TNC 113 - Infinitely variable feed in X, Y, and Z axes - Vertical milling head quill travel: 60 mm Fpodpfx Aoyll A Teg Tsd - Vertical milling head swivels and extends 100 mm horizontally - Coolant system (coolant tank in machine base) - Documentation - Central lubrication system - Machine vice - Various toolholders/collets/tools Space required (L x W x H): 1,350 x 1,100 x 1,700 mm Weight: 850 kg The machine has been visually reconditioned and technically inspected. Geometry inspection videos can be provided upon request. Backlash Y axis: 0.1 mm Backlash X axis: 0.2 mm Backlash Z axis: 0.15 mm Runout horizontal spindle: 0.001 mm Runout vertical spindle: 0.001 mm Parallelism deviation Y axis: 0.002 mm (measurement path: 150 mm) Parallelism deviation X axis: 0.01 mm (measurement path: 300 mm) Geometry inspection videos can be provided upon request. The following parts have been renewed: - Gears in horizontal head replaced and gear shaft newly mounted - New guide cover for Z axis + various attached parts - Machine refurbished - New LEDs installed - Y-axis chain tensioner overhauled - Reference point programming checked - Function test carried out
