Other

Weinig

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 1.490,14, saw blade diameter: 500 mm, cutting height (max.): 140 mm, cutting width (max.): 350 mm, power: 8 kW (10.88 HP), overall weight: 2,000 kg, TECHNICAL DETAILS Max. saw blade length: 6,100 mm Max. saw blade diameter: 500 mm Saw blade arbor diameter: 35 mm Max. cutting height: 140 mm Max. cutting width: 350 mm Infeed table length: 7,850 mm Outfeed table length: 2,400 mm MACHINE DETAILS Main motor power: 5.5 kW Total power: 8.0 kW Voltage: 400 V Fuse: 25 A Dimensions & Weight Dimensions (L x W x H): 11,250 x 800 x 1,600 mm Djdpey Nyd Iofx Ad Necg Weight: 2,000 kg EQUIPMENT Automatic feed system

Condition: ready for operation (used), Year of construction: 2004, machine/vehicle number: 102848, functionality: fully functional, operating hours: 3,142 h, empty load weight: 5,000 kg, feed rate X-axis: 33 m/min, number of spindles: 7, TECHNICAL DETAILS Number of spindles: 7 Spindle 1 - Spindle type: Bottom - Motor power: 15 kW - Tooling: Yes Spindle 2 - Spindle type: Right - Motor power: 11 kW - Tooling: Yes Dcedpfxjy Nyb He Ad Nsg Spindle 3 - Spindle type: Left - Motor power: 11 kW - Tooling: Yes Spindle 4 - Spindle type: Top - Motor power: 22 kW - Tooling: Yes Spindle 5 - Spindle type: Bottom - Motor power: 15 kW - Tooling: Yes Spindle 6 - Spindle type: Top - Motor power: 30 kW - Tooling: Yes Spindle 7 - Spindle type: Bottom - Motor power: 15 kW Minimum planing width: 20 mm Maximum planing width: 300 mm Minimum planing height: 3 mm Maximum planing height: 160 mm Infeed table length: 1,000 mm Feed roller diameter: 140 mm Extraction nozzle diameter: 160 mm Feed speed: Manual Minimum feed speed: 5 m/min Maximum feed speed: 33 m/min Feed speed regulation: Infinitely variable MACHINE DETAILS Voltage: 400 V Current consumption: 278 A Circuit breaker: 400 A Power: 128 kW Dimensions & weight Dimensions (L x W x H): 5,500 x 2,400 x 2,100 mm Net weight: 5,000 kg Operating hours: 3,142 h EQUIPMENT Driven rollers in the table Powerlock Cutterhead drive: Cardan shaft drive Lubrication system: Automatic

Condition: used, Year of construction: 1997, Beam planer 260 x 160 mm, trailing chamfer unit on the upper spindle, air cushion table with two-axis control for left and upper spindle, factory-new control system (latest Weinig version) Max. working width: 260 mm Max. working height: 160 mm Number of spindles: 6 1st spindle: bottom, spindle diameter 40 mm, clamping length 270 mm, speed 6000 rpm, motor power 11.0 kW 2nd spindle: right, spindle diameter 40 mm, clamping length 170 mm, speed 6000 rpm, motor power 11.0 kW (shared motor with left spindle) 3rd spindle: left, spindle diameter 40 mm, clamping length 170 mm, speed 6000 rpm 4th spindle: top, spindle diameter 40 mm, clamping length 270 mm, speed 6000 rpm, motor power 11.0 kW 5th spindle: bottom, spindle diameter 40 mm, motor power 11.0 kW, speed 6000 rpm, clamping length 270 mm 6th spindle: top, chamfering unit Motor brakes: mechanical Height adjustment of upper spindle: electric Optionally with/without feed Feed brake system: Yes Feed speed infinitely variable up to: 3 – 23 m/min Feed roller pressure: pneumatic Feed power: 4.0 kW Feed drive: cardan Lubricant pump: manual Max. planing depth: 10 mm Jointing cutter on jointer: Yes Powered rollers in table: 1 Control type: PLC control Spindle position display: mechanical numerical display Infeed rollers before jointer: Yes Air cushion table: triple track Central lubrication point: Yes Description: short infeed table 1050 mm with internal lighting Location: Nattheim Dcjdpfxewwwkho Ad Nsg

Condition: ready for operation (used), Year of construction: 1983, Brand: Weinig Model: U 17 A Machine no: 1387-2940 Year of manufacture: 1983 Working height: 1700 mm Working width: 1200 mm 7 spindles in order: Below (4 kW, 5.5 hp), Right (4 kW, 5.5 hp), Left (5.5 kW, 7 hp), Right (4 kW, 5.5 hp), Above (5.5 kW, 7 hp), Under (4 kW, 5.5 hp), Universal (5.5 kW, 7 hp) 40 mm spindles Tiltable feeding-unit Variable feed speed: 6-36 m/min Switch for the security fence Infeed path for planer Brand: Sacot Length: 4000 mm Width: 200 mm Output table Length: 3500 mm Width: 200 mm Dedpfovydwzjx Ad Nscg Lifting table Length: 2350 mm Width: 1200 mm Stock no: 2002037BXM

Condition: excellent (used), functionality: fully functional, Working width: 220 mm Working height: 120 mm Number of spindles: 5 Spindle arrangement: bottom / right / left / top / bottom Motors: 7.5 KW, 11 KW, 11 KW, 11 KW, 7.5 KW Table lubrication Feed drive: 2.2 KW Electrically adjustable pressure beam Electrically adjustable left spindle Feed speed: 6/22 m/min Year of production: 1993 Dedpfsy N Rbkox Ad Necg Machine dimensions: - Length: 4400 mm - Width: 1700 mm - Height: 1250 mm

Condition: ready for operation (used), functionality: fully functional, Working width: 220 mm Working height: 120 mm 5 spindles Spindle arrangement: bottom / right / left / top / right Motors: 5.5 kW, 7.5 kW, 5.5 kW, 5.5 kW Dsdpfjy N Ra Tsx Ad Njcg Table lubrication Feed speed: 6/22 m/min Year of manufacture: 1990 Machine length: 4400 mm Width: 1700 mm Height: 1250 mm

Condition: excellent (used), Year of construction: 1990, functionality: fully functional, working width 300mm working height 140mm feeding rate 200m/min spindles speed 6000 RPM spindles diameter 50mm spindles set: 1. bottom - 22kW 2. top - 22kW 3. right - 18,5kW 4. left - 18,5kW Dodjy N N U Njpfx Ad Nscg 5. right - 18,5kW 6. left - 22kW 7. top - 22kW 8. bottom - 22kW 9. top - 22kW 10. bottom - 22kW 11. bottom - 22kW Possibility to purchase the machine with feeder + EUR 17,900 net.

Condition: excellent (used), functionality: fully functional, Device description Working width: 230 mm Working height: 130 mm 5 heads + chamfering unit Dsdpfxoy N N Uce Ad Necg Head arrangement: bottom/right/left/top/bottom Head speed: 6000 rpm Memory system Stepless feed speed adjustment up to 30 m/min Feed on cardan shafts Table lubrication Pneumatic pressure on drive rollers

Condition: excellent (used), functionality: fully functional, working width 230mm working height 160mm 5 spindles spindles set: bottom/right/left/top/bottom spindles diameter 40mm (last one 50mm) Dsdpfx Aoy N N T Sod Necg manual jointer on last head rolls in the table electric regulation of top head variable regulated feeder to 36m/min chrome table pneumatic pressure of feeding rolls

Condition: excellent (used), functionality: fully functional, working width 230mm working height 120mm Dcedpfjy N N Txsx Ad Njg 4 spindles spindles set: dolna/prawa/lewa/górna spindles diameter 40mm pneumatic pressure of feeding rolls table lubrication
