Formier

WEINIG Unimat 1000 Star

Condition: used, No. 3176 Automatic planer and moulder WEINIG Hydromat 1000 Used, year of construction 2007 6 spindles: bottom-right-left-top-top-bottom Electronic feed 6 - 60 m/min Working width 80 - 150 mm Working height 23 - 65 mm Finished slat widths 4 - 15 mm Max. Max. number of slats 16 pieces Slat lengths 400 - 4000 mm 1st spindle horizontal at the bottom Brake motor 11 kW, 6000 rpm Spindle diameter 45 mm Tool flight circle 125 - 180 mm 2nd spindle vertical right Brake motor 7.5 kW, 6000 rpm Diameter 45 mm Tool flight circle 112 - 250 mm Max. Moulding depth 35 mm Axial adjustment travel 80 mm 3. spindle vertical left 7.5 kW, 6000 rpm Diameter 45 mm Tool flight circle 112 - 250 mm Max. Moulding depth 35 mm Axial adjustment travel 80 mm Pressure shoe in front of the spindle, swiveling away, pneumatic roller contact pressure 4. spindle horizontal top 15 kW, 6000 rpm, diameter 45 mm Tool flight circle 112 - 250 mm Max. Moulding depth 35 mm Axial adjustment path 45 mm Split pressure shoe in front of upper spindle, adjustable and swiveling away, pneumatic 5. horizontal top spindle as saw spindle Brake motor 37 kW, 5000 rpm Diameter 45 mm Axial adjustment travel reduced to 25 mm Tool flight circle 112 - 250 mm Max. Sawing depth 35 mm Axial adjustment path 45 mm Split pressure shoe in front of upper spindle, adjustable and swiveling away, pneumatic 6. horizontal spindle at the bottom as saw spindle Brake motor 30 kW, 5000 rpm Axial adjustment travel reduced to 25 mm Diameter 45 mm Tool flight circle 112 - 250 mm Max. Sawing depth 35 mm Axial adjustment path 45 mm All moulder spindles with high-performance bearings Electronic feed 7.5 kW Adjustment travel of the feed rollers compared to the left-hand spindle, axial 35 mm Shorter roller distance compared to the right-hand spindles Running meter counter, electric, with 2 counters Short infeed table (1.2 m) with 2 driven rollers above the table 1 driven, toothed roller in the table, lateral pressure roller Automatic waxilite pump / lubricant pump Machine with 4-roller extension, pendulum shafts extended to 200 mm 2 driven, toothed rollers in the outfeed table 2 driven, toothed rollers in the machine table Pressure beam before and after upper spindle with mechanical digital display DigiSet (digital double display) for left and top spindles Electrical height adjustment of the upper spindles and the feed Machine already dismantled and stored Sale on behalf of customer, ex location near South Tyrol, without transportation and assembly Nkedpfxju Agh Ss Ab Ijt Subject to errors in the description and price Transportation and loading by us optionally possible To avoid possible misunderstandings, an on-site inspection by appointment is possible and recommended Sold as is Technical details, condition description, year of construction and scope of delivery according to manufacturer's brochure or previous owner, without guarantee Subject to prior sale For used machines, any warranty is excluded, the following applies: “purchased as seen” Images and videos serve as examples and do not represent the actual scope of delivery Terms of payment: Prices plus VAT, payment before collection or dispatch Terms of delivery: ex location

Year of construction: 2000, condition: good (used), Leadermac LMC 523 Smartmac four side planer - year of production 2000 - DTR - electronic height and width adjustment - possibility to save permanent parameters TECHNICAL PARAMETERS: - planing width 230 mm - planing height 140 mm - diameter of the spindles 40 mm 1 lower spindle 7.5 kW 2 right spindle 5.5 kW 3 left spindle, 5.5 kW 4 upper spindle 7.5 kW 5 lower spindle 7.5 kW smoothly adjustable feed 3 kW feed motor power electronic height adjustment electronic adjustment of the left head feed on cardan shafts five top steel pull rollers two upper rubber pulling rollers one role in the table top pulling pneumatic material pressure minimum material length 400 mm Nedpfxoifftxe Ab Ijkt length of the preliminary table 2000 mm chrome tables stub diameter 5 x 125 mm Machine dimensions 370 x 200 x 190 cm weight ~ 3000 kg
