Werk II Fillmaster R18 Isobaric Filler Capper (2023)

Werk II Isobaric Filler Capper

Overview

Bedpeziuazsfx Acfoli
This Braumanufaktur Werk II Fillmaster R18 is a compact isobaric rinsing, filling and crown-capping monoblock for glass bottles, built in 2023 by Braumanufaktur Werk II (Großalmerode, Germany). It is sold as a complete craft-scale bottling set for carbonated beverages together with a 750 L fermentation and carbonation tank (SM Inox, 2021) and a 330 L pressure loading tank (SM Inox, 2023).

The monoblock combines 6 rinsing stations, 6 isobaric filling valves and 6 crown-capping heads in a single compact unit. CO₂ pre-saturation of the bottles before filling reduces oxygen pickup and product oxidation. Mechanical movements are driven by a pneumatic system (6 - 8 bar); filling parameters, production data and bottle counters are managed via the Siemens SIMATIC HMI touch panel. The line is still installed and under power, and basic functionality can be demonstrated on site.

Technical data

- Manufacturer: Braumanufaktur Werk II GmbH (Großalmerode, Germany)
- Model: Fillmaster R18
- Year of manufacture: 2023
- Machine type: isobaric rinser - filler - crown capper monoblock, glass bottles
- Rinsing stations: 6 / filling valves: 6 / capping heads: 6
- Capacity: approx. 500 - 650 bph (semi-automatic, operator-dependent)
- Filling system: isobaric, with CO₂ cylinder connection for bottle pre-saturation
- Bottle formats: currently set up for 0.375 L glass; adaptable to other crown-cap formats
- Crown caps: 26 or 29 mm, all sizes configurable
- Control: Siemens SIMATIC HMI touch panel (filling parameters, production data, bottle counter)
- Compressed air: 6 - 8 bar
- Power: 230 V, 5 A
- Dimensions: approx. 870 x 930 x H 1,910 mm

Equipment

- SM Inox FBTB 750 L PED fermentation and carbonation tank (2021): domed bottom, pressure lid, double insulated jacket with glycol circuit fed by an external heat pump, dedicated control panel for temperature, agitator and CO₂ injection (automatic / manual), carbonation stone fed via solenoid valve; PED Cat. III, approx. Ø 955 mm
- SM Inox FCTC 330 L loading tank (2023): pressure lid with CO₂ inlet for pump-free liquid transfer between tanks, approx. Ø 640 mm
- Mobile transfer / washing pump on stainless trolley
- OEM technical documentation (operating manual, PLC instructions, quick guide) and declarations of conformity

Condition

Used - very good condition with light use: the PLC production counter reads approx. 58,600 bottles / 12,000 litres in total. Still installed and under power; the sale takes place because the owner has discontinued production.

Availability

Immediately. Location: Italy. Preparation, dismantling and truck loading by the seller (EXW loaded). The machine can be visited and demonstrated on request.
