Coordinate measuring machine

Werth Scope-Check 300x200x200 3D

Condition: ready for operation (used), Year of construction: 2020, clamping force: 2,200 kN, screw diameter: 70 mm, injection weight: 172 g, This Arburg 570 S 2200-800/290 was manufactured in 2020. It features a hydraulic drive system and the Selogica control system for precise operations. With a clamping force of 2,200 kN and a screw diameter of 40 mm, it is ideal for detailed injection moulding tasks. Consider the opportunity to buy this Arburg 570 S 2200-800/290 hydraulic injection moulding machine. Contact us for more information. Clamping unit • Distance between tie bars: 570 × 570 mm • Opening stroke: 650 mm • Ejector force: 70 kN • Ejector stroke: 200 mmInjection unit • Injection unit size: 290 • Injection pressure: 2,500 bar • Shot volume: 188 cm³Drive & control • Drive system: Hydraulic • Control system: ARBURG Selogica Hnjdpfx Akox Nkp Isrju

Condition: like new (used), Year of construction: 2019, operating hours: 399 h, functionality: fully functional, clamping force: 2,200 kN, screw diameter: 48 mm, clearance between the columns: 650 mm, displacement volume: 318 cm³, injection pressure: 1,900 bar, mold height (min.): 250 mm, ejector force: 35,000 N, ejector stroke: 150 mm, opening stroke: 550 mm, plate length: 900 mm, plate width: 900 mm, total height: 2,800 mm, overall weight: 10,700 kg, Equipment: documentation/manual, FANUC ROBOSHOT Alpha S-220iA – fully electric injection moulding machine, year 2019 Very lightly used precision injection moulding machine with only 399 operating hours. The FANUC ROBOSHOT Alpha S-220iA combines high repeatability, dynamic movements and energy-efficient production. Suitable for demanding technical plastic parts and reliable series production. Technical data: - Clamping force: 2,200 kN (220 t) - Double-toggle clamping mechanism - Tie-bar spacing: 650 × 650 mm - Platen size: 900 × 900 mm - Mould height: 250–750 mm, extended version - Clamping stroke: 550 mm - Ejector stroke: 150 mm - Maximum ejector force: 35 kN - Screw diameter: 48 mm - Shot volume: 318 cm³ - Maximum injection speed: 200 mm/s - Maximum injection pressure: 1,900 bar - Locating ring: Ø 160 mm - Fully electric drive Control and equipment: - FANUC 31i-B CNC control - 15-inch LCD touchscreen - AI mould and ejector protection Hnedeznd Dyopfx Akrju - Precision metering and pressure-profile functions - Automatic mould-height adjustment - Energy-consumption measurement - Euromap 67 robot interface - Three independent air valves - Cascade control for up to eight valves - USB and memory-card output - Four-circuit flow meter The machine is in like-new condition and fully operational. Inspection is available by appointment. Price, delivery time and further information are available on request.

Condition: good (used), Year of construction: 2010, 3D Coordinate Measuring Machine Werth Video-Check-IP 400×200 3D CNC Hnedpexfluusfx Akrou TECHNICAL DATA Manufacturer: Werth Model: Video-Check-IP 400×200 3D CNC Function: 3D Coordinate Measuring Machine Year of manufacture: 2010 Measuring range X-axis: 400 mm Measuring range Y-axis: 200 mm Measuring range Z-axis: 250 mm Max. workpiece weight: 30 kg Drives: Ball screw drives with servo motors Measuring systems: Incremental scales with 0.1 µm resolution Guides: Precision ball guides on all axes Illumination: Transmitted light, bright field and dark field reflected light with LED Optics: Zoom optics with zoom factor 0.2x–100x Camera: High-resolution CCD black-and-white camera Electrical connection: 230 V AC, 50 Hz Current consumption: max. 10 A Power: max. 1.5 kVA Noise level: < 70 dB(A) SCOPE OF DELIVERY Including (not limited to): 3D Coordinate Measuring Machine Werth Video-Check-IP 400×200 3D CNC Control panel Probes Fiber optic and reference standard sets Exact scope of delivery according to photo documentation The Werth Video-Check-IP 400×200 3D CNC is a high-precision coordinate measuring machine for optical and tactile metrology. With a measuring range of 400 x 200 x 250 mm, it offers versatile application options for quality assurance of a wide variety of components. The combination of high-resolution CCD black-and-white camera, powerful zoom optics and LED lighting ensures precise image capture and reliable results. Precision ball guides and servo drives guarantee high repeatability. The device comes with extensive accessories and is ideally suited for precise 3D measuring tasks in industrial and manufacturing environments. No guarantee is given for the correctness, completeness or currentness of the information provided.

Condition: ready for operation (used), Year of construction: 2013, operating hours: 60,672 h, clamping force: 4,000 kN, screw diameter: 80 mm, total height: 2,360 mm, overall weight: 11,000 kg, product length (max.): 7,420 mm, This Engel DUO 3550/400 pico was manufactured in 2013. It features a clamping force of 4,000 kN, a screw diameter of 80 mm, and a maximum injection volume of 1,960 cm³. The machine dimensions are 7,420 × 2,360 × 2,360 mm, and it weighs 11,000 kg. It is equipped with a robot interface Euromap 67. Contact us for more information about this machine. • Operating hours: 60,672 h • Condition: Excellent • Status: In production • Maximum injection volume: 1,960 cm³ • Minimum mould height: 350 mm • Maximum mould height: 850 mm • Platen opening stroke: 1,050 mm • Platen dimensions (W × L): 1,100 × 1,190 mm • Tie-bar distance: 800 × 800 mm • Motor power: 70 kW • Heater power: 52.95 kW • Number of electrical connection pins: 32 • Injection nozzle radius (tip): R35 • Centering ring diameter: 200 mm • Number of Hydraulic Cores (FS/MS): 1 fixed side and 2 moving side • Number of Hydraulic Cascades: 0 • Number of Hot Runner Control Points: 8 • Number of heating zones: 0 Additional equipment Hjdpfxjx Nr Ryo Akronu • Robot equipped: Yes • Robot interface: Euromap 67

Condition: ready for operation (used), Year of construction: 2002, operating hours: 14,500 h, functionality: fully functional, clamping force: 2,500 kN, screw diameter: 60 mm, displacement volume: 735 cm³, injection pressure: 1,481 bar, injection weight: 662 g, mold height (min.): 250 mm, ejector stroke: 250 mm, plate length: 650 mm, plate width: 1,050 mm, installation height: 850 mm, Machine in operational condition. Includes handling robot from ENGEL. Hnsdoyuayropfx Akrsu

Condition: like new (used), Year of construction: 2019, clamping force: 2,200 kN, Equipment: documentation/manual, Fanuc FANUC ROBOSHOT Alpha S220iA (2019) _FANUC Roboshot α-S220iA – Equipment List_ _Basic Technical Specifications_ 1. Clamping force: 2200 kN 2. Injection speed: 200 mm/s 3. Max. injection pressure: 1900 bar 4. Min./Max. mold height: 250–750 mm (extended) 5. Clamping stroke: 550 mm 6. Tie bar spacing (H×V): 650 × 650 mm 7. Locating ring: Ø 160 mm 8. Ejector stroke: 150 mm 9. Screw diameter: 48 mm (318 cm³) 10. Screw/barrel: W/C (hardened, high wear & corrosion resistance, up to 350 °C, 30% GF) 11. Nozzle: Standard open R19D4 _Control & Software (FANUC 31i-B CNC)_ 1. 15" LCD touchscreen 2. SI unit (kN, MPa...) 3. Password-protected screen lock 4. AI pressure profile trace function 5. AI metering control function 6. AI mold protection function 7. AI ejector protection function 8. Backflow monitor function 9. Precise metering 2, 3 10. Auto purge function 11. Extruder delay timer function 12. High precision V-P switch function 13. Injection unit temperature control and display 14. Automatic mold height adjustment 15. 2-stage ejection Hnjdpfjzkttcjx Akrou 16. Ejector delay function 17. Pre-ejection function 18. Optimal energy consumption function _Standard Machine Equipment_ 1. Extended mold height 2. 4-circuit rotameter 3. Automatic mold height adjustment 4. Hopper slider 5. 3-color LED signal lamp 6. Automatic purge and material cleaning function 7. Plasticizing speed control 8. Decompression control additional function 9. Backflow monitoring function 10. AI mold and ejector protection 11. Mold protection output on moving platen 12. Energy consumption measurement function 13. Robot interface (Euromap 67) 14. Auto stop/shutdown mode 15. 3 independent air valves 16. 8 digital outputs, 11 digital inputs 17. Pre-injection / injection compression function 18. Cascade injection valve control (up to 8 valves) 19. USB and memory card output 20. Tool kit (standard tools + grease gun) 21. User manual (Hungarian) 22. Warning labels (Hungarian) _Clamping Unit Specifications_ 1. Mechanism: Double toggle 2. Clamping force: 2200 kN / 220 tonf 3. Die height (single platen): 250–650 mm _(opt. 250–750 mm)_ 4. Clamping stroke: 550 mm 5. Locating ring: Ø 160 mm 6. Tie bar spacing (H×V): 650 × 650 mm 7. Platen size (H×V): 900 × 900 mm 8. Min. mould size (H×V): 375 × 375 mm 9. Ejector stroke: 150 mm 10. Max. ejector force: 35 kN / 3.5 tonf

Condition: used, Year of construction: 2007, clamping force: 50 kN, displacement volume: 27 cm³, injection pressure: 2,760 bar, overall weight: 2,300 kg, screw conveyor diameter: 20 mm, terms of delivery: FCA Pegnitz Hodezmi A Sjpfx Akrenu delivery time: on request terms of payment: 100% prior to delivery

Condition: used, functionality: fully functional, measuring range X-axis: 400 mm, measuring range Y-axis: 200 mm, measuring range Z-axis: 250 mm, workpiece weight (max.): 40 kg, VideoCheck S 400x200 3D CNC Year of manufacture: 2014 Measuring range: X = up to 400 mm Y = up to 200 mm Z = up to 250 mm Installation area: Depth: 770 mm Width: 778 mm + 400 mm travel Hsdpfoxbifpjx Akrenu Height: 1673 mm + 200 mm travel Measuring device weight: up to 480 kg Max. workpiece weight: mmax = 40 kg

Condition: excellent (used), Year of construction: 2007, operating hours: 102,000 h, clamping force: 6,500 kN, DUO 5550/650 Advanced Year 2007 Clamping force: 6500 kN Screw: D90, S6, tempered, with flight armouring and ionitriding, abrasion resistant Control unit: CC200 A01 Languages: Slovenian (SL), German (DE) Operating hours: 102,000 1x core mowing platen 1x core pull, additional, on movable platen Mold height increase of 200 mm Variant C, according to the technical sales manual (Min. mold height remains standard, max. mold height increases, platen stroke remains standard, max. platen distance remains standard) Connections for external filter station 8x mold heating control Expansion module for 8 temperature measuring or control points Standard 8-way cooling water flow regulator (0-10 l/min) Cooling water flow regulator, 10-way Magnetic mold clamping platen system TECNOMAGNETE, temperature resistant up to 120 degrees C, incl. interface Euromap 70.1, nozzle adaptation and assembly ENGEL ROBOTER TYPE ERC 63-F X-Max. travel distance: 100 mm Total Y-axis length: 900 + 900 mm (tandem) Z-total: 2360 mm Hjdpfjy Ug Ahox Akrenu C-axis (125 Nm) 2 switchable vacuum/compressed air circuits RC 200 integrated with C30 E handheld control unit

Condition: good (used), Year of construction: 2010, functionality: fully functional, measuring range X-axis: 250 mm, measuring range Y-axis: 200 mm, measuring range Z-axis: 200 mm, Software: QVPAK V10.005 Hsdpfx Aju Sqmdekrjnu
