TP-Plus-2:90

Wittmann

Condition: excellent (used), Year of construction: 2019, Wittmann Battenfeld EcoPower 110/350 / All-Electric Machine / Operating hours: approx. 15,000 in automatic mode Year of manufacture: 2019 Injection Unit: Screw diameter: 35 mm Shot weight: 153.8 g Injection pressure: 2083 bar Dosage volume: 168 cc Clamping Unit: Clamping force: 110 t Tie bar spacing: 470 x 420 mm Platen size: 682 x 682 mm Ejector: electric Clamping unit: toggle lever Control system: UNILOG B8 - Touchscreen Additional features: Machine in excellent technical condition All-electric machine: energy-efficient and very quiet Operating hours: approx. 15,000 in automatic mode Total operating hours: 21,800 Euromap 67 Robot interface Air valve x 1 Nodpfxsy Dqhas Ag Dowf Hydraulic core pull x 1 Hot runner control system Injection unit is wear-resistant and corrosion-resistant Central lubrication Dimensions: Weight: 4,800 kg Length/Width/Height: 4.91 x 1.42 x 2.10 m All machines offered are started up by our service technicians prior to sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2014, Wittmann Battenfeld HM 150/750 Servo Power / Hybrid Machine / Operating hours: approx. 29,000 in automatic mode Year of manufacture: 2014 Injection unit: Screw diameter: 50 mm Injection weight: 402.2 g Injection pressure: 1,714 bar Shot volume: 442 ccm Clamping unit: Clamping force: 150 t Tie bar distance: 520x470 mm Dimensions of platens: 760x755 mm Ejector: hydraulic Clamping unit: hydraulic Control system: UNILOG B6P - touchscreen Additional equipment: Machine in very good technical condition Electric machine: energy-saving and very quiet Operating hours: approx. 29,000 in automatic mode Total operating hours: 36,714 Euromap 67 Robot interface Air valve x 1 Hydraulic core pull x 1 Injection unit is wear-resistant and corrosion-resistant Main drive motor - servo motor driven by inverter - energy saving Dimensions: Weight: 6,600 kg Length/Width/Height: 4.82x1.42x2.20 m Nsdpey Dqf Sefx Ag Dowf All machines offered are started up by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or to participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2017, Wittmann Battenfeld EcoPower 110/350 with the Wittmann W818 robot / Electric machine / Operating hours: approx. 16,000 in automatic mode Year of manufacture: 2017 Injection unit: Screw diameter: 35 mm Injection weight: 153.8 g Injection pressure: 2083 bar Dosing volume: 169 cc Clamping unit: Clamping force: 110 t Bar spacing: 470x420 mm Size of the clamping plates: 680x660 mm Ejector: electric Clamping unit: toggle lever Control: UNILOG B8 - touchscreen Additional equipment: Perfect technical condition Electric machine: high-speed, energy-saving and very quiet Operating hours: approx. 16,000 in automatic mode Euromap 67 Robot interface Control with Air valve Hydraulic core pull x 1 Control with hot runners Nwodoy Dqg Aepfx Ag Dof Injection unit is wear-resistant and resistant to corrosion Central lubrication Automatic tool height adjustment Parallel movements The machine was serviced in Germany Robot Wittmann W818 Year of manufacture: 2015 4-axis robot: 3 axes are driven by servo motors (electric); axis C - pneumatic Travel paths in axes: X-420, Y-1200, Z-2000 Touch control panel The safety package for robots Robot with adapter, conveyor belt and protective housing Purchase of the robot and the conveyor belt for an additional charge Dimensions: Weight: 4800 kg Length/width/height: 4.91x1.42x2.10 m All machines offered are started by our service technicians before sale. It is possible to receive a video of the technical tests of the selected machine or to take part in live technical tests in our company in Łódź. Price: On request

Condition: good (used), Year of construction: 2010, sprue picker Wittmann W702 x=100mm Y vert. 700mm Nwodpfx Ajy Av Eueg Dsf year: 2010 price: 1.850 € contact: Mr. Rainer Eckerle

Condition: like new (used), Year of construction: 2019, operating hours: 3,825 h, functionality: fully functional, The Wittmann plus D140 temperature control unit is for sale. The device was used in a technical center, which explains the low operating hours. Original price: €5,260 - Max. water temperature: 140°C in the mold supply line - Max. system pressure: 10 bar in the mold return line - Pump: 0.5 kW (1.4A) / 50Hz, max. 40 l/min, max. 4.5 bar, seal-less and magnetically coupled - Heating capacity: 7.5 - 9 kW (11.5 - 12.5A) at 380 - 415V - Cooling capacity: 20 kW at ΔT = 75°C (indirect cooling) - Operating voltage: 3x 380 – 415 V, 50 Hz - Control voltage: 24V AC - Power consumption: 14.5A / 9.5kW (the total connected load increases if options such as reinforced pump or additional heating capacity are added) - Main connection: 4m cable incl. 16A CEKON plug - WITTMANN 4.0 interface including license, with shielded RJ45 socket - USB port: socket for software updates and data logging Nwsdpjy Atnyofx Ag Dof - Mold supply and return: G3/4'' female thread - Mold circuit with angle-seat strainer, mesh size 0.25mm - Water inlet and outlet: G3/8'' female thread - Strainer in water inlet: G3/8'' female thread, mesh size 0.3mm - Color: RAL7047 (Telegrey 4), front RAL3004 (Purple red) - Weight: Net: 65 kg, Gross: 82 kg (incl. pallet and packaging) - Dimensions (L x W x H): 840 x 265 x 650 mm - Dimensions incl. pallet & packaging (L x W x H): 920 x 630 x 830 mm - Fill volume: 3 liters - Noise level: 70 dB(A) Media: - Process and cooling medium: water

Condition: used, machine/vehicle number: 12861, Rotor diameter: 400 mm Rotor width: 600 mm 3-knife rotor 2 rows of stator knives Feed opening approx. 400 x 600 mm Nwsdpfxsyr Trce Ag Dsf Drive motor: 22 kW

Condition: excellent (used), Year of construction: 2014, operating hours: 56,851 h, functionality: fully functional, clamping force: 1,100 kN, screw diameter: 25 mm, displacement volume: 86 cm³, injection pressure: 3,000 bar, mold height (min.): 200 mm, opening stroke: 450 mm, overall weight: 4,800 kg, input voltage: 400 V, Equipment: documentation/manual, warehouse no.: 503665 manufacturer: Wittmann Battenfeld type: EcoPower 110-350 controller: UNILOG B6P year of construction: 2014 Nwodpey Akn Refx Ag Djf operation hours: 56851 h clamping force: 1100 kN distance between tie-bars h x v: 470 x 420 mm size of mould plates h x v: 680 x 663 mm min. mould height: 200 mm max. mould height: 450 mm max. open daylight: 830 mm opening stroke: 380 mm screw diameter: 25 mm swept volume: 86 ccm injection pressure: 3000 bar equipment included screen text german Screentext Multi-Language CEE-socket 16A machine incl. water flow regulator Anti vibration mounts measures of machine l x w x h: 4.57m x 1.5m x 2.13m total weight: 4800KG

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, X: 420 mm Y: 1200 mm Z: 2000 mm Nodeyyyvropfx Ag Dowf C: 0 - 90 °

Condition: good (used), Year of construction: 2015, Wittmann S 3 Net Material suction 220 V Nodoyybk Djpfx Ag Dswf year: 2015 price: 790 € contact: Mr. Rainer Eckerle

Condition: excellent (used), Year of construction: 2015, Equipment: documentation/manual, Number of axis: 3 Njdpfeyftw Ejx Ag Dewf Reach: 1500 mm Payload: 6 kg X=420mm Y=1200mm Z=1500mm EUROMAP 67
