WP 80

WITTMANN

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 138337-100, clamping force: 9,000 kN, screw diameter: 105 mm, injection pressure: 1,931 bar, ejector stroke: 300 mm, opening stroke: 2,100 mm, TECHNICAL DETAILS Screw diameter: 105 mm Screw stroke: 525 mm Screw L/D ratio: 22 Theoretical shot volume: 4,545 cm³ Injection pressure: 1,931 bar Maximum screw speed: 167 rpm Maximum plasticizing rate: 151 g/s Screw torque: 8,000 Nm Nozzle travel / nozzle thrust force: 950 mm / 129 kN Injection volume flow rate: 725 cm³/s Injection volume flow rate with double pump (option): 906 cm³/s Air injection volume flow rate with tank (option): 1,812 cm³/s Cylinder heating capacity: 53.9 kW Number of heating zones: 7 Clamping force: 9,000 kN Maximum opening stroke: 2,100 mm Cgodpfx Asy T Hprsppeu Min./Max. tool height: 500 – 1,000 mm Platen size: 1,720 x 1,550 mm Tie bar spacing: 1,200 x 1,000 mm Ejector stroke: 300 mm Ejector force: 165 kN Tool opening force: 300 kN MACHINE DETAILS Pump output: 90 kW Heating capacity: 53.9 kW Oil tank volume: 1,100 l Dimensions & Weight Machine dimensions (L x W x H): 10,100 x 3,400 x 2,700 mm Weight: 35,200 kg

Condition: good (used), Year of construction: 2016, 2016 Wittmann Battenfeld EcoPower 110/130 Injection Moulding Machine With Unilog B6P Control Clamping Force: 110 Ton. Screw Ø22mm. Shot Volume: 41 cm3. Screw L/D Ratio: 20. Calculated Stroke Volume : 41,8 cm3. Correct Injection Pressure : 2,864 bar. Maximum Screw Speed:500 min. Screw Tongue: 150 Nm. Nozzle Path Contact Force : 250/40 mm/kN. Injection Flow Outside : 76 cm3/s. Cylinder Heating Capacity : 6,3 kW. Number Of Heating Zones : 4. Recorded Working Hours: Approx. 35,953. S/No. 137469-100 (2016). Csdpfxszbr A Ej Appegu Approximate Overall Dimensions (L x W x H): 5,000 x 1,600 x 2,300mm. Approximate Weight 4,600kg.

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, overall weight: 50 kg, type of input current: three-phase, power: 12 kW (16.32 HP), year of last overhaul: 2026, Type: TP-DIRECT: 120 Power: 12 kW Codpfxoy Uvwbs Appjgu Maximum operating temperature: 120 °C Medium: Water Temperature control unit Three units available Price: 700 EUR per unit

Condition: good (used), Year of construction: 2010, Ref. no.: 18624 Manufacturer: WITTMANN BATTENFELD Type: EcoPower 180/350 UNILOG B6S All Electric Codpfjy Uiwhox Appegu Year of construction: 2010 Clamping unit Clamping force: 180 ton Opening stroke: 480 mm Distance between tie bars: 570 x 520 mm Mould height min.: 225 mm Mould height max.: 550 mm Platen size (h x v): 810 x 805 mm Injection unit Screw diameter: 35 mm Injection volume: 168 cm³ Shot weight: 163 g Injection pressure: 2083 bar Measurements and weight Dimensions: 5,2 x 1,6 x 2,2 m Machine weight: 6800 kg Further information: Die Wittmann Battenfeld EcoPower Serie steht für hocheffiziente vollelektrische Spritzgießtechnologie, entwickelt für präzise Produktionsprozesse und stabile Fertigungsbedingungen. Alle Hauptbewegungen der Maschine werden durch Servo-Elektromotoren angetrieben. Einspritzen, Dosieren, Schließen und Auswerfen erfolgen vollständig elektrisch und ermöglichen dadurch eine äußerst präzise Bewegungssteuerung, hohe Wiederholgenauigkeit und stabile Produktionsqualität. Im Vergleich zu konventionellen hydraulischen Spritzgießmaschinen kann die EcoPower Serie – abhängig von der Anwendung – Energieeinsparungen von ca. 60% bis 80% erreichen. Zusätzlich bieten die Maschinen eine reduzierte Wärmeentwicklung, einen ruhigen Lauf sowie eine saubere Produktionsumgebung. Die integrierte UNILOG B6 / B6P Steuerung ist bekannt für ihre benutzerfreundliche Bedienung, zuverlässige Prozesskontrolle und stabile Langzeitleistung. In Kombination mit der hochdynamischen Servotechnologie und dem vibrationsarmen Betrieb eignet sich die EcoPower Plattform besonders für technische Kunststoffteile, elektronische Komponenten, Automobilanwendungen und medizinische Produktionen. Die Wittmann Battenfeld EcoPower Serie zählt auch heute noch zu den zuverlässigsten und energieeffizientesten vollelektrischen Spritzgießmaschinenplattformen auf dem Markt.

Condition: excellent (used), Year of construction: 2015, Number of axis: 3 X- 580 mm Y- 1000 mm Z- 1500 mm Reach: 1500 mm Payload: 3 kg Possible buy with rotary unit Gimatic OFN30-90SD Cgedpfxoy Ud Hdj Appsu or rotary unit Gimatic RBT30

Condition: excellent (used), Year of construction: 2018, 🔧 *M028 — Wittmann Battenfeld Wittmann Battenfeld MACROPOWER 700 / 2250* (2018) 📐 *CLAMPING UNIT* • Clamping force: 700 T • Coining: YES Csdpsy Tn Dkjfx Appegu • Max mold weight: 10000 kg • Max mold weight per plate: 6600 kg • Size between bars (WxH): 1100x950 mm • Min mold height: 450 mm • Max mold height: 950 mm • Max stroke open: 1850 mm • Centering ring FIX / MOVE: 200 / 200 mm • Fast clamping system: NO 🔌 *MOLD INTERFACE* • Heating zones: 24 (16 pin TC, 16 pin PW) • Water cooling circuits: 18+6 • Hydraulic circuits (cores): 2+2 • Hot runner sliders hydraulic (nozzles): 12 • Hot runner sliders pneumatic: 7 💉 *INJECTION UNIT* • Screw diameter: 65 mm • Nozzle face + thread: R??+M30x2 • Injection unit type: 2250 • Screw stroke: - mm • Max injection capacity: - cm³ • Max injection pressure: 2070 Bar • Max injection rate: 422 cm³/s • Accumulator SW / HW: NO / NO ⚡ *ELECTRICAL / ROBOT* • Mold ejector clamp: YES • Sockets 400V/16A: 4 • Sockets 400V/32A: 5 • Sockets 400V/63A: 0 • Robot type: Linear • Quick connector gripper: WGS-QLRD Midi • Vacuum ports: 3 • Air pressure ports: 4 • User inputs / outputs: 0 / 0 \+ Robot Wittmann W833PRO-0469 (X-900, Y-1800, Z-3000, Payload: 10,6 kg) \+ conveyor Belt with cage

Condition: excellent (used), Year of construction: 2019, Wittmann Battenfeld EcoPower 110/350 / All-Electric Machine / Operating hours: approx. 15,000 in automatic mode Year of manufacture: 2019 Injection Unit: Screw diameter: 35 mm Shot weight: 153.8 g Injection pressure: 2083 bar Dosage volume: 168 cc Clamping Unit: Clamping force: 110 t Tie bar spacing: 470 x 420 mm Platen size: 682 x 682 mm Ejector: electric Clamping unit: toggle lever Control system: UNILOG B8 - Touchscreen Csdpjy Sly Tefx Appjgu Additional features: Machine in excellent technical condition All-electric machine: energy-efficient and very quiet Operating hours: approx. 15,000 in automatic mode Total operating hours: 21,800 Euromap 67 Robot interface Air valve x 1 Hydraulic core pull x 1 Hot runner control system Injection unit is wear-resistant and corrosion-resistant Central lubrication Dimensions: Weight: 4,800 kg Length/Width/Height: 4.91 x 1.42 x 2.10 m All machines offered are started up by our service technicians prior to sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2017, Wittmann Battenfeld EcoPower 110/350 with the Wittmann W818 robot / Electric machine / Operating hours: approx. 16,000 in automatic mode Year of manufacture: 2017 Injection unit: Screw diameter: 35 mm Injection weight: 153.8 g Cgodpfx Aoy Sly Hoppou Injection pressure: 2083 bar Dosing volume: 169 cc Clamping unit: Clamping force: 110 t Bar spacing: 470x420 mm Size of the clamping plates: 680x660 mm Ejector: electric Clamping unit: toggle lever Control: UNILOG B8 - touchscreen Additional equipment: Perfect technical condition Electric machine: high-speed, energy-saving and very quiet Operating hours: approx. 16,000 in automatic mode Euromap 67 Robot interface Control with Air valve Hydraulic core pull x 1 Control with hot runners Injection unit is wear-resistant and resistant to corrosion Central lubrication Automatic tool height adjustment Parallel movements The machine was serviced in Germany Robot Wittmann W818 Year of manufacture: 2015 4-axis robot: 3 axes are driven by servo motors (electric); axis C - pneumatic Travel paths in axes: X-420, Y-1200, Z-2000 Touch control panel The safety package for robots Robot with adapter, conveyor belt and protective housing Purchase of the robot and the conveyor belt for an additional charge Dimensions: Weight: 4800 kg Length/width/height: 4.91x1.42x2.10 m All machines offered are started by our service technicians before sale. It is possible to receive a video of the technical tests of the selected machine or to take part in live technical tests in our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2014, Wittmann Battenfeld HM 150/750 Servo Power / Hybrid Machine / Operating hours: approx. 29,000 in automatic mode Year of manufacture: 2014 Injection unit: Screw diameter: 50 mm Injection weight: 402.2 g Injection pressure: 1,714 bar Shot volume: 442 ccm Clamping unit: Clamping force: 150 t Tie bar distance: 520x470 mm Dimensions of platens: 760x755 mm Ejector: hydraulic Clamping unit: hydraulic Control system: UNILOG B6P - touchscreen Additional equipment: Cedpfxoy Slvns Appegu Machine in very good technical condition Electric machine: energy-saving and very quiet Operating hours: approx. 29,000 in automatic mode Total operating hours: 36,714 Euromap 67 Robot interface Air valve x 1 Hydraulic core pull x 1 Injection unit is wear-resistant and corrosion-resistant Main drive motor - servo motor driven by inverter - energy saving Dimensions: Weight: 6,600 kg Length/Width/Height: 4.82x1.42x2.20 m All machines offered are started up by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or to participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2015, Wittmann Battenfeld VM 150/525 R1280 Servo Power / Vertical Injection Moulding Machine with Rotary Table Year of manufacture: 2015 Injection Unit: Screw diameter: 35 mm Shot weight: 175.6 g Injection pressure: 2743 bar Dosage volume: 193 ccm Clamping Unit: Clamping force: 150 t Tie bar distance: 0x0 mm Platen size: 1280 mm Ejector: hydraulic Clamping unit: hydraulic Control system: UNILOG B6 Additional equipment: Vertical injection moulding machine with rotary table Hybrid machine: high-speed, energy-saving, and very quiet Air valve x 5 Hydraulic core pull x 1 Hot runner control x 12 Injection unit is wear-resistant and corrosion-resistant Rotary table diameter: 1500 mm Rotary table driven by a servomotor, controlled by an inverter Dimensions: Weight: 11,300 kg Cjdpfx Aoy Slvhjppegu Length/Width/Height: 3.83x1.50x4.07 m All machines offered are started up by our service technicians prior to sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. Price: On request
