Angular Clamping Device

WMW AW 330x310

Condition: used, Technical details: bore capacity in steel (diameter): 16 mm throat: 190 mm bore stroke: 60 mm Distance spindle/table max.: 250 mm range of revolution per miute: 410 / 725 / 1100 / 1700 bei 4step U/min spindle taper MT: MK 2 table surface area: 155 x 155 mm vertical adjustment: Tisch/table = 180 mm table rotating: 360 ° base plate surface area: 175 x 175 mm distance spindle center to floor plate:: max. 360 mm column diameter: 70 mm Bwjdpfx Aju Id Dzeh Ioi machine weight ab.: 65 kg dimensions L x W x H: 0,6 x 0,3 x 0,85 m Drill sleeve equipped with drill chuck 1 - 16 mm table rotatable *

Condition: used, Year of construction: 2003, Technical details: bore capacity in steel (diameter): 25 mm throat: 255 mm bore stroke: 140 mm spindle taper MT: MK 3 spindle speed:: 105 - 2980 / 8step U/min Distance spindle/table max.: min.: 350 / max.: 950 mm table clamping surface:: 420 x 270 mm table rotating: 360 ° table swivable approx.: 30° links / rechts drill table adjustment: 600 manuell mm column diameter: 100 mm current- max.: 400 V / 50 Hz A total power requirement: 0,9 kW weight of the machine ca.: 180 kg dimension machine xH: 0,6 x 0,5 x 1,8 m Equipment: Röhm quick-action chuck 3 - 16mm Bodpsu Idhysfx Ah Iewi Switchover for clockwise/anticlockwise rotation for thread cutting *

Condition: excellent (used), jaw width: 103 mm Bwodpfxefgx R Ue Ah Ioi jaw height: 37 mm span length: 175 mm place requirement: 600 x 180 x 150 mm weight: 27 kg

Condition: excellent (used), Deckel FP1 AKTIV (3-Axis Active) Machine no.: 2102-3240 Year of manufacture: approx. 1988 Travel paths: X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 – S20x2 Spindle speed: 40–2,000 rpm Motor power: 1.6 and 2 kW Power supply: 380 V, 50 Hz Equipment/Accessories: - Active digital readout, 3 axes, HEIDENHAIN type TNC 113 - Infinitely variable feed in X, Y, and Z axes - Vertical milling head quill travel: 60 mm - Vertical milling head swivels and extends 100 mm horizontally - Coolant system (coolant tank in machine base) - Documentation - Central lubrication system - Machine vice - Various toolholders/collets/tools Space required (L x W x H): 1,350 x 1,100 x 1,700 mm Bodoyll A Tepfx Ah Ijwi Weight: 850 kg The machine has been visually reconditioned and technically inspected. Geometry inspection videos can be provided upon request. Backlash Y axis: 0.1 mm Backlash X axis: 0.2 mm Backlash Z axis: 0.15 mm Runout horizontal spindle: 0.001 mm Runout vertical spindle: 0.001 mm Parallelism deviation Y axis: 0.002 mm (measurement path: 150 mm) Parallelism deviation X axis: 0.01 mm (measurement path: 300 mm) Geometry inspection videos can be provided upon request. The following parts have been renewed: - Gears in horizontal head replaced and gear shaft newly mounted - New guide cover for Z axis + various attached parts - Machine refurbished - New LEDs installed - Y-axis chain tensioner overhauled - Reference point programming checked - Function test carried out

Year of construction: 1989, condition: excellent (used), 1 used centering drilling machine make Jones &Shipmann infinitely variable speed up to 1400 rpm drive 0,37 KW Bjdpohg Ennofx Ah Iowi first class condition

Condition: used, Technical details: table diameter: 315 mm Bsdpou N Dz Aefx Ah Iewi rotatability of the table - manual/mechanic: 360 ° weight of the machine approx.: 100 kg dimensions: 620 x 530 x 135 mm The tables were rarely used other features: -with radial scale -surface is finished -center mounting MK3 -dividing circle 19 / 27 / 31 / 41 / 49 / 59 -operation also possible by machine via coupling on both sides (switchable right-/left-hand rotation with automatic changeover) -foot clamping: support size 360 x 420mm with 1 clamping groove on the front side 16 x 200mm *

Condition: used, Year of construction: 1982, Technical details: dimensions of grinding wheel: Ø 150 x 20 mm Bwjdpou Ngxdefx Ah Iji grinding spindle speed: 3600 U/min height over floor: 900 mm current type: 220 V machine weight approx.: 27 kg dimensions L x W x H: 0,37 x 0,35 x 1,4 m Double sanding bench sitting on foot stand (foot Ø 353mm) Left side with drill grinding device (angle 90° - 180°), longitudinal adjustment 25mm incl. accessories *
