CNC Machining Center

Yamazaki Mazak AJV-35/60

Condition: excellent (used), Year of construction: 2006, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 770 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, table width: 1,000 mm, table length: 4,150 mm, table load: 4,000 kg, Magnum: powerful machining in machine construction and tool making Sk50 with extremely powerful spindel 50kw Glas scales in X/Y/Z Chip conveyor and coolant system X - Travel: 3500mm Y - Travel: 1000mm Z - Travel: 770mm Table Length: 4150mm Table Width: 1000mm Dujdpfx Ahswycmms Sel Table load: 4000 Feed rate X-Axis: 30000mm/min. Feed rate Y-Axis: 30000mm/min. Feed rate Z-Axis: 30000mm/min. Spindle Taper: 50ISO/Bt/Mk Power on spindle: 50kW Speeds / ranges: 4500Rpm ATC / revolver: 50 Number of controlled axis:3 Chip conveyor: yes Coolantsystem: yes Length: 8000mm Width: 5000mm Height: 3700mm Weight: 30000kg

Condition: good (used), Year of construction: 2003, X 1740mm, Y 766mm, Z 660mm 10000 rpm Parts shown by hand not come. Duodewyblzspfx Ah Sol

Condition: used, Year of construction: 1996, x-travel 1500 mm y-travel 650 mm z-travel 650 mm size of pallet 1740 x 650 mm spindle taper SK 50 spindle turning speed range 25 - 6000 U/min feeds longditudinal/cross/vertical max. 8 mm/min rapid traverse longitudinal and cross 26 m/min rapid traverse vertical 20 m/min spindle throat 665 mm distance spindle nose and table 200 / 850 mm drilling in full material 50 mmø Duodpetqqtkjfx Ah Sjl threading M 45 ATC 60 Pos tool diameter 125 mm wotkpiece diameter with 2 vacant positions 260 mm workpiece length 400 mm weight of tools max. 20 kg spindle drive 18,5 kW max. torque on the spindle max. 758 Nm Accessories: chip conveyor, coolant

Condition: ready for operation (used), Year of construction: 2003, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,150 mm, travel distance Z-axis: 585 mm, workpiece weight (max.): 4,000 kg, table width: 1,000 mm, table length: 2,240 mm, table load: 4,000 kg, overall weight: 25,000 kg, spindle speed (max.): 6,000 rpm, spindle nose: BT50, number of spindles: 1, number of slots in tool magazine: 30, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, This machine was decommissioned from production while operational and was replaced due to the purchase of a new machine. Unfortunately, the machine cannot be viewed running anymore, but it is displayed in our stock. ATTENTION! The displayed images are both from us and previously from our customer. Additional information: Max. weight on the table: 4,000 kg Chip conveyor Renishaw MP10 workpiece probe Custom-made machine table for easy clamping of workpieces Total weight: approx. 25,000 kg Transport dimensions: 1 Colli MAZAK machine, 620x319x307 cm, weight approx. 19,000 kg Duedpjwvkcnsfx Ah Sol 1 Colli coolant tank, 3x1.1x0.7 m, weight 210 kg 1 Colli magazine, 5x1x1.9 m, weight approx. 1,450 kg 1 Colli chip conveyor, 4x1x1.6 m, weight 220 kg
