Filtration system

Alfa Laval

Year of construction: 2019, condition: ready for operation (used), There is a recirculating air cooling system consisting of an Alfa Laval plate heat exchanger and a Thermofin finned tube heat exchanger. 1) Alfa Laval M10-BW plate heat exchanger, year of manufacture: 2005, cooling capacity: 115kW, flow rate: 28.2m³/h, refrigerant NH3. 2) Finned tube heat exchanger Thermofin TBN, year of manufacture: 2019. Including panel housing and condensate drip tray. Documentation available. Ibedpfx Anst R Tr Sjmja

Year of construction: 2009, condition: ready for operation (used), A complete plate heat exchanger pasteurization system Alfa Laval, consisting of four sections, is available. Product: 13% whole milk, throughput capacity: 25000kg/h, total capacity: approx. 2000kW, volume: 588l, max. pressure: 10bar, max. temperature: 120°C, test pressure: 14.3bar, number of plates: 338, expansion option: 82 plates, heat transfer area: 210m², plate thickness: 0.6mm, gasket system: Clip-On, gasket material: NBRFF, total pressure loss on the product side: 422kPa, heat exchange stages: regeneration/heating/intermediate stage/cooling, plate pack length: 1856mm, carrying bar length: 3600mm, tightening bolt length: 3560mm. Overall system dimensions X/Y/Z: approx. 3850mm/850mm/2200mm, weight: approx. 2850kg. Documentation available. An on-site inspection is possible. Ibodpfx Aoyvuuujnmea

Year of construction: 2021, condition: ready for operation (used), Suitable for the separation of free oils from cooling lubricants, max. output: 500l/h, max. liquid temperature: 70°C, pH value: 6-9, length: 620mm, width: 510mm, height: 1140mm, weight: 60kg, with documentation. Iodpfxok E Nccj Anmsba

Condition: new, Alfa Laval M6-MFG plate heat exchanger, 30107-39733, unused, 100% functional. Scope of delivery as shown in the photos. PLEASE NOTE: Please request a separate quote for packaging and shipping costs! Ijdpfxozt H Edo Anmeba

Condition: used, Year of construction: 1992, Two-stage counterflow plate heat exchanger: Section 1: Heating or regeneration: Product/product Product inlet 6°C, outlet 66.2°C, Flow rate 300 hl/h Product inlet 72°C, product outlet 69.8°C Flow rate 300 hl/h Section 2: Heating: Product/hot water Product inlet 66.2°C, product outlet 70°C, flow rate 300 hl/h Hot water inlet 72°C, hot water outlet 69.8°C, flow rate 500 hl/h Additional title: two-stage heat exchanger Capacity product: 300 hl/h Ibsdpfxozty Ryo Anmea Capacity hotwater: 500 hl/h Max. pressure: 21 bar Working temp.: 110 °C Systemic volume: 695 Liter Length: 3250 mm Width: 910 mm Height: 2160 mm Weight: 2656 kg Material: plates: AISI 316, thickness 0,6 mm, Clip-on gasket-material: Nitrile Features: Section 1: heat exchanger surface 160,58 m², content 317,2 / 317,2 liter, pressure drop 1,2 / 1,2 bar Section 2: heat exchanger surface 14,88 m², content 29,3 / 31,7 liter, pressure drop 0,2 / 0,5 bar

Condition: good (used), Used stainless steel tank with agitator Iodpfx Aneff Abxomoba The agitator is not functioning. Article number: 10483 Last application: Cosmetics Volume: approx. 2000 liters Type: Standing on 3 legs Material (in contact with the medium): 1.4301 stainless steel Design: Single-walled Manhole: 510x410 mm Bottom: Conical bottom Top: Arched Operating pressure according to nameplate: ATM Tank dimensions: Outer diameter: 1280 mm Height of legs: 770 mm Distance from outlet to bottom: 520 mm Overall height: 2880 mm Overall width: 1460 mm Materials: Inside: 1.4301 / AISI304 Exterior parts: 1.4301 / AISI304 Equipment: Nameplate: yes Outlet: DN 40mm Various connections Agitator

Condition: good (used), Used stainless steel pressure vessel Article number: 10398 Volume: 400 liters Type: Standing on rollers with forklift tunnel Material (in contact with the medium): 1.4404 / AISI316L Manhole: 410mm Design: Single-walled Bottom: Conical bottom Top: Curved Ibjdpfx Anod R Hfdsmsa Operating pressure according to nameplate: +2.2 bar Vessel dimensions: Outer diameter: 750mm Distance from outlet to bottom: 120mm Overall height: 1840mm Overall width: 900mm Overall length: 750mm Features: Nameplate: Yes Outlet type: Camlock

Condition: good (used), Used stainless steel pressure vessel on rollers Item number: 10399 Volume: 400 liters Type: Standing on rollers with forklift tunnel Material (in contact with media): 1.4404 / AISi316 Manhole: 410mm Design: Single-walled Bottom: Conical bottom Top: Curved Ibjdpjd R Hfhofx Anmea Operating pressure according to nameplate: +2.2 bar Dimensions of the vessel: Outer diameter: 750mm Distance from outlet to bottom: 170mm Overall height: 1800mm Overall width: 890mm Overall length: 820mm Equipment: Various connections Nameplate: Yes Outlet type: Camlock

Condition: ready for operation (used), Alfa Laval M6-MFM plate heat exchanger 30103-32067 - 6 bar - with inspection report, used, in good condition, 100% functional. Scope of delivery as shown in the photos. PLEASE NOTE: Please request a separate quote for packaging and shipping costs! Iodpfxoztmkae Anmoba

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, machine/vehicle number: P260302015, total height: 350 mm, total width: 300 mm, total length: 800 mm, overall weight: 80 kg, machine base height: 180 mm, STOCK STATUS: 3 UNITS Ibsdpjzrmvaofx Anmoa For sale is a professional, multi-section process module manufactured to hygienic standards, designed for the food, brewing, or chemical industry. Main components of the set: • Pumps: Series of centrifugal pumps in stainless steel housings (protection against flooding/hygienic standard). • Flow measurement: Integrated electromagnetic flowmeters (visible control units with LCD displays, e.g., from Endress+Hauser or a similar class). • Construction: The entire unit is mounted on a stable stainless steel frame (skid type), which facilitates transport and installation in a new production line. • Piping: Complete acid-resistant piping with flanged and hygienic connections. Key advantages: • Precision: Thanks to the flowmeters, the system allows for very accurate liquid dosing or media transfer monitoring. • Hygiene: Stainless steel construction allows operation in CIP (Cleaning In Place) systems. • Ready for operation: Complete module ready to be integrated into an existing technological installation. Technical condition: Very good, regularly serviced, operating in a clean production environment. A pump without an electromagnetic flowmeter can also be purchased for 15,000 PLN. This description may have been translated automatically. For further information, please contact us. The information contained in this advertisement is for informational purposes only. We suggest verifying the details with the seller before making a purchase.
