Laser Welder

Alpha Laser ALM200

The ALPHA LASER ALM 200 laser welder was manufactured in 2014 in Germany by Alpha Laser GmbH but has been in operation since 2017. This mobile laser welding machine is equipped with a 200 W laser source (9 kW laser beam power), which enables the repair and modification of various components such as dies, molds, injection molds, tools, and machine parts at any chosen location. Welding is performed in semi-automatic mode. The mobile laser welding system features a narrow laser head, allowing access to the interior of the workpiece. The unit is controlled via computer, joystick, and foot switch. The machine is in excellent technical and visual condition, with regular servicing.

The machine comes complete with a table.

Price: 180,000 PLN net (VAT invoice available).

Technical specifications of the ALPHA LASER ALM 200 laser welder:

– Power: 200 W
– Wavelength: 1064 nm
– Travel speed (X, Y, Z): 0-25 mm/s
– Travel range (X, Y, Z): 140 x 120 x 1300 mm
– Pulse energy: 90 J
Lrsdpfx Agstqtrfomow
– Pulse duration: 0.5-20 ms
– Pulse frequency: 100 Hz
– Laser beam power: 9 kW
– Laser beam diameter: 0.2-2.0 mm
– Operating mode: pulsed
– Focal length: 150 mm
– Power supply: 380 V / 50-60 Hz / 16 A / 8 kW
– External dimensions: W-1410 x D-730 x H-1585 mm
– Machine weight: approx. 320 kg
– Operating hours: 11,065
– Serial number: 03001212-03.14

Additional features and equipment of the ALPHA LASER ALM 200:
– Optics: LEICA microscope mount with 10x magnification, optionally 16x
– Display with keyboard
– Multifunctional foot switch
– Joystick
– Adjustable laser arm
– Complete workstation with table
– Various spare parts and accessories (e.g., lamps, hoses, wire holders, detail positioning balls/bases, magnets) available at competitive prices
– Various welding wires available at good prices
– Option to purchase a fume extraction system

The listing was translated automatically. Translation errors are possible.
