Panel sizing circular saws

ALTENDORF F45

Condition: used, Year of construction: 1998, Used machine Year of manufacture: 1998 Equipment and technical specifications: - Cutting length: 3400 mm - Cutting width: 1300 mm, CNC-controlled - Motor: 5.5 kW Dedjx Sttnspfx Ah Sjkg - Automatic brake - Digital display for cutting width - Digital display for tilting - Digital speed display - Digital display for mitre fence - Scoring unit: electric H+S F45 - RAPIDO scoring system - Automatic guard control - Parallelogram guard device F45 - Table extension: 800 mm - CE version - Anodised version Availability: approx. mid-April 2026 Location: Hesse

Condition: used, Year of construction: 2018, machine/vehicle number: Werksüberarbeitungsnummer: WÜA18031207013284, cutting length (max.): 3,000 mm, cutting width at rip fence: 1,300 mm, table length: 840 mm, main saw diameter: 450 mm, power: 7.5 kW (10.20 HP), Equipment: rotational speed infinitely variable, Used machine GM010.0399 Dkodpfxew Nii Ss Ah Ssg F45 Pro Drive Year of manufacture: 2018 Template holder Max. saw blade diameter: 450 mm Motor: 7.5 kW Vario DRW: 3000 mm TPL: 840 mm WGA Digit-L PA 1300 mm CNC Front support roller Air cushion table

Condition: used, Year of construction: 1982, Altendorf panel saw F 45, year of manufacture: 1982, machine no.: 82-12-44, motor: 5.5 kW / 400 Volt, cutting length: 2500 mm, cutting width: 1000 mm, raise/lower and tilt up to 45° via handwheel, speeds: 3, 4, 5 and 6000 rpm, max. saw blade diameter: 400 mm, max. cutting height: 130 mm, parallel guard device. Dkedpfxsx S Hrqj Ah Sog

Condition: reconditioned (used), Year of construction: 2023, functionality: fully functional, machine/vehicle number: GM010.0396, cutting length (max.): 3,200 mm, cutting width (max.): 1,300 mm, saw blade diameter: 550 mm, table length: 840 mm, power: 5.5 kW (7.48 HP), Factory-refurbished Altendorf F45 with ProDrive control system! TECHNICAL DETAILS Cutting Data Cutting length: max. 3,200 mm Cutting width at rip fence: 1,300 mm Saw blade diameter: 550 mm Saw blade projection at 90°: 204 mm Saw blade projection at +45°: 141 mm Carriage length, double roller carriage: 3,200 mm Table Data Table length: 840 mm Performance Data Power output: 5.5 kW MACHINE DETAILS Machine height: 910 mm Motor power: 5.5 kW (7.5 HP) Dust Extraction Connection Extraction, top: Ø = 80 mm Extraction, bottom: Ø = 120 mm Negative pressure: 1,200 Pa at total suction port, Ø = 140 mm Air consumption: v_min = 1,110 m³/h at 20 m/s Air Cushion Table Compressed air consumption: 200 l/min at 1 bar (max. 400 l/min at max. 3 bar) EQUIPMENT Lighting Continuously variable speed control Scorer unit LED lighting 3-axis scorer including park position On/off switch on the double roller carriage Angle/miter fence Parallel stop DIGIT X 1,300 mm Front support roller Second support on the double roller carriage Dkedpfoxc Uq Hox Ah Ssg

Condition: new, engine output 5 kW saw-blade dia. 300-350 mm Working speed 0-40 m/min Dkedpfjwli Nrjx Ah Sjg weight ca. 1.300 – 1.800 kg kg

Condition: excellent (used), Altendorf F45 panel saw, sliding table 320 cm, max. blade diameter 500 mm, unit tilt 0-45 degrees, blade tilt and height adjustment are motorized, right-side fence adjustable up to 1040 mm, motorized 2-axis scoring unit, Dsdpfx Ahjx Sw Agj Sekg main motor 5.5 kW, used machine.

Condition: used, Year of construction: 1996, machine/vehicle number: 96-02-044, Operator panel control: LCD screen, eye-level, swiveling, cutting width, cutting height, saw blade tilt Edging table: 3200 mm (double roller carriage with hardened chrome guides) Cutting width: 1300 mm Main saw: ø250–400 mm, 5.5 kW, speed 3,000–6,000 rpm 0–46° NC electric adjustment: yes Scorer: none Parallelogram table: extendable 700 mm Djdpfxjx Ry Sho Ah Sskg Length stop: angle stop with fixed 90° position, 2 stop flaps, cross-cutting up to 3500 mm Condition: Well-maintained machine, technically and functionally tested

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, Exhibition machine – as new – including the following options: - Laser cutline indicator - Saw motor with 7.5 kW (10 HP) - Mitre fence swivels +/- 50° with length compensation - Programmable saw blade height adjustment Saw unit swivels up to 46° Pressure beam, including: LED lighting with 3 different action colors: - WHITE: Machine at standstill - RED: Pressure beam lowering or emergency stop function - BLUE: Saw unit in motion Up to 3,400 mm extendable telescopic stop with 2 digital displays 4 parallel, motorized positioning width stops on a 2,000 mm wide support table, size adjustment up to 1,300 mm Automatic stop retraction Versatile support table 800 x 200 mm Scoring system using the main saw blade in synchronised rotation Automatic workpiece length detection for minimum travel distances Mobile, height-adjustable control panel, including: - Touchscreen control panel with cut plan creation - Saw blade stand - Template holder - Emergency stop button, start button, selector switch for grooving/groove sawing/cutting, rotary switch for feed speed Djdpfx Ahew Uf Nlj Sjkg - Switch for laser (option) - USB socket Attention: Machine is supplied without saw blade! Technical data: Cutting length: 3,200 mm Max. saw blade projection: 100 mm at 90°, 72 mm at 45° Saw blade: Diameter 300 – 350 mm, bore 30 mm Saw blade speed: 4,000 rpm Motor: 5 kW (= 7.5 HP) Feed speed: 0 – 40 m/min Overall length: approx. 4,270 mm Weight: from approx. 1,150 to 1,550 kg (depending on equipment) Required air pressure: 7 bar Extraction ports: 1 x 100 mm, 1 x 120 mm

Condition: used, Good day! 1 used Altendorf F 45 sliding table saw - Hydraulic height and tilt adjustment - Digital display (speed and tilt) - 4.5 m trimming length - Automatic star-delta start - 105 mm cutting height with 350 mm saw blade with scorer - 155 mm cutting height with 450 mm saw blade without scorer - 3000/4000/5000/6000 rpm - Automatic motor brake - Rip fence with fine adjustment - Parallelogram guard - Table extension and table width extension Dsdpfxjx Rt E Us Ah Sskg - Chassis - Extraction ports top and bottom - Trimming shoe - Adjustable handle on the sliding carriage - Operating tools - Operating manual/spare parts list New parts: - Narrow extraction hood 90° 181.00 + 19% - Wide extraction hood 45° 268.80 + 19% - Poly Flex V-belt 11W875 35.50 + 19% - Flat belt for scorer 32.50 + 19% - Gas pressure spring 50N for scorer 45.30 + 19% - GUHDO saw blade 350 mm 78.50 + 19% - Saw spindle new bearings fitted 250.00 + 19% - Scorer new bearings fitted 150.00 + 19% Special equipment: - 7.5 kW 380 Volt motor New price: €1,350 + 19% - Scorer New price: €3,150 + 19% - 4.3 m sliding carriage New price: €4,250 + 19% - Pneumatic pressure beam 3.2 m New price: €3,800 + 19% - Rip fence with fine adjustment 1.3 m New price: €580 + 19% - Duplex double-sided mitre fence New price: €1,350 + 19% - LASER cut line indicator New price: €2,300 + 19% - Circular saw feed Panhans Type 76 New price: €4,665 + 19% Price: €13,800 + 19% VAT The machine has been technically inspected, cleaned, adjusted, and newly painted. Cables and plug included – ready for immediate use. Payment by cash or bank transfer prior to collection/shipping only. The machine is sold without any warranty or guarantee. Please send me a brief message. Thank you!

Condition: good (used), Elmo 2 model Electric lift/lower Electric 45-degree tilt Manual side guide Top and bottom controls 3400 mm trolley Dedex Rg Ucjpfx Ah Sskg

Condition: used, Year of construction: 2013, Available by arrangement. Saw unit: tiltable 45°. Carriage length: 3200 mm. Max. saw blade diameter: 550 mm. Max. saw blade projection at 90°: 200 mm. Max. saw blade projection at 45°: 141 mm. Saw blade bore: 30 mm. Motor power: 5.5 kW. Max. cutting width: 1000 mm. Control panel: mounted at the lower machine housing. Control panel design: with buttons and LCD screen. Height adjustment: electric motor driven. Tilting adjustment: electric motor driven. Tilt angle display: on screen. Cutting width adjustment: manual with fine adjustment. Cutting width display: scale. Sliding carriage guide: steel. Table extension length: 840 mm. Crosscut at cross fence: 3500 mm. Cross fence display: scale. Cross fence design: tiltable. Speeds: 3/4/5000 rpm. Scoring unit: prepared—retrofit possible. PSV safety guard: Yes. End position lock: Yes. Automatic motor brake: Yes. Working height or infeed table height: 910 mm. Weight approx.: 1050 kg. Extraction diameter: 120/80 mm. Storage location: Dksdpfx Ahex Rdmps Sjg

Condition: good (used), Year of construction: 2003, Tilting Panel Saw Altendorf F45 with ELMO IV-plus package, 2-axis scorer, 3m sliding table, and Control-Plus control system Sliding table length: 3000 mm Saw blade tilting from 0 to 45 degrees Speeds: 3000, 4000, 5000, and 6000 rpm with electronic speed display Drive motor: 5.5 kW with automatic motor brake Eye-level control panel with Control-Plus system 4-axis CNC control Cutting of chain dimensions and grooves on the rip fence and crosscut fence Cutting width correction on the rip fence and crosscut fence when using the tilting saw blade 600 cutting programs Calculator function with result transfer to the corresponding axis Tool management Saw blade diameter up to 450 mm Maximum cutting height: 150 mm Dkjdsxw Ii Sepfx Ah Seg Cutting width up to 1040 mm, electrically adjustable Tilting angle and height adjustment electrically adjustable Crosscut fence length: approx. 3210 mm, electrically adjustable, automatic coupling of second stop flap for large cutting dimensions Rip fence foldable Extraction ports: 120 + 80 mm Sliding carriage with locking function Additional mitre fence 2 used saw blades and one scorer 2 riving knives 2-axis scoring unit, electrically adjustable while the machine is running 2 safety hoods 3 emergency stop switches Clipboard at the control panel CE mark Machine with signs of use. No cuts in sliding table. Original paint (special color), partially retouched. Machine has 18,985 operating hours. It comes from a furniture factory and was obviously regularly serviced and well maintained. Condition as shown in the original photos. A video of the machine in operation can be sent on request. Dimensions approx. 3150 x 3750 x 1900 mm (LxWxH). Weight approx. 1400 kg. The machine can be demonstrated on-site by appointment. We only offer machines that are ready for demonstration in our warehouse. See "more offers from this supplier."

Condition: used, Year of construction: 1990, Carriage length: 3800 mm Cutting width at rip fence: 600 mm Cutting width at crosscut fence: 2800 mm Cutting depth: 150 mm Scoring unit: yes Saw blade height adjustment: manual / hydraulic Saw blade tilt adjustment: manual / hydraulic Rip fence adjustment: manual Saw blade angle display: scale Cutting height display: - Rip fence display: scale Crosscut fence display: scale Dodotk H Tnopfx Ah Sjkg Saw blade diameter: 450 mm Speeds: 4 Motor power: 7.5 kW Motor brake: yes Extraction connection: 80 mm and 120 mm Machine length: 3870 mm Machine width: 1200 mm Weight: 1000 kg
