Panel saw ALTENDORF F45 -used-

ALTENDORF F45

Year of construction: 1990, condition: ready for operation (used), Saw blade diameter: 450mm, Cutting height: 150mm, Bore: 30mm, Swivel: 45°, Cutting width: 1000mm, Machine dimensions X/Y/Z: approx. 3300mm/2000mm/1600mm, Weight: approx. 1200kg. An on-site inspection is possible. Hodpfxeynlt Rj Afcei

Condition: excellent (used), Year of construction: 1993, machine/vehicle number: 93-09-065, functionality: fully functional, power: 5.5 kW (7.48 HP), input voltage: 380 V, input frequency: 50 Hz, cutting height (max.): 155 mm, cutting width (max.): 1,380 mm, saw blade diameter: 450 mm, tilt adjustment saw blade: 45 °, height adjustment type: hydraulic, actuation type: manual, rotational speed (max.): 6,000 rpm, rotational speed (min.): 3,500 rpm, total length: 3,200 mm, Manufacturer: Altendorf Model: F45 The machine is in very good and well-maintained condition. Longitudinal sliding table: 3200 mm Cutting width at rip fence: 1380 mm Crosscut fence with extension up to 3800 mm Cutting depth: 155 mm Scoring unit: no Saw blade height adjustment: hydraulic Saw blade tilt adjustment: hydraulic Rip fence adjustment: manual Crosscut fence adjustment: manual Saw blade angle display: digital readout Maximum saw blade diameter: 450 mm Hsdpfx Ajym U Stofcsi Speeds: 4 Motor power: 5.5 kW

Condition: used, Year of construction: 2023, machine/vehicle number: Werksüberarbeitungsnummer: WÜA23051204239033, functionality: fully functional, power: 5 kW (6.80 HP), cutting width at rip fence: 1,300 mm, main saw diameter: 550 mm, section length (max.): 3,200 mm, table length: 840 mm, F45 Elmo Drive GM010.0407 Machine height: 910 mm Eye-level control panel Double-sided tilting Max. blade diameter: 550 mm Hedeymdh Dspfx Afcsi Motor: 5.0 kW (6.8 HP) Vario 2-axis scoring unit with double-sided tilt LED lighting Table extension: 840 mm Double roller carriage: 3200 mm Mitre/fence stop DIGIT LD CNC parallel fence: 1300 mm Front support roller DUPLEX 1350 mm (2019)

Condition: used, Year of construction: 2004, Sliding carriage length: 3000 mm Hedpfjyl Tihex Afcei Cutting width at rip fence: 1350 mm Cutting width at crosscut fence: 3200 mm Cutting depth: 170 mm Scoring unit: no Saw blade height adjustment: electric Saw blade tilting adjustment: electric Rip fence adjustment: manual Crosscut fence adjustment: manual Saw blade angle display: digital readout Cutting height display: digital readout Rip fence display: digital readout Crosscut ruler display: scale Saw blade diameter: 500 mm Spindle speeds: 4 Motor power: 7.5 kW Extraction port: 80 and 120 mm Machine length: 3600 mm Machine width: 2200 mm Weight: 1200 kg

Condition: used, Year of construction: 1995, incl. duplex stop, overhead control panel, 5.5 kW motor, sliding table 3200 mm, scoring unit. Saw blade diameter without scorer: max. 450 mm. Saw blade diameter with scorer: max. 400 mm. Speeds: 3000/4000/5000/6000 rpm. Digital speed display. Digital display at the parallel fence (DIGIT X). Cutting width: 1300 mm. Table extension 800 mm. Storage location: supplier. Hodjylxa Espfx Afcji

Condition: good (used), Code: 0302 Brand: ALTENDORF Model: F 45 - CE Standard CNC-controlled 3-axis panel saw with tilting blade for furniture, custom-made furnishings, panels, doors, wooden window frames, plastics, composite materials and various - CE Standard Technical data: Precise sliding double roller carriage Aluminium carriage length 3200 mm Max blade diameter 450 mm Max cutting height 150 mm Cutting height at 45° 105 mm Scoring unit blade diameter 120 mm 3 controlled axis (lifting/blade tilting/parallel guide) Electric motor adjustment 2-axis scoring unit Control panel at operator height with colour LCD screen Anodised aluminium table extension 840 mm Parallelogram blade guard Register for oblique square cuts, manual adjustment, with length compensation, end cutting up to 3500 mm Blade locking system Work table height 910 mm Overall dimensions of assembled machine mm 3400 x 3400 x 1700 h Hodpfxeylhmzj Afcoi Overall dimensions for transport mm 3400 x 2100 x 1700 h Weight kg 1050

Year of construction: 1995, condition: ready for operation (used), Sliding table length: 2800mm, Cutting width: 1000mm, Saw blade tilting: 45°, Saw blade diameter min./max.: 250mm/450mm, Motor power: 5.5kW, Weight: approx. 1250kg. An on-site inspection is possible. Hedpfx Afeyit H Ujcji

Condition: used, Year of construction: 2007, Carriage length: 3000 mm Cutting width at rip fence: 1300 mm Hsdpfx Aeyhgiyefcji Cutting width at cross-cut fence: 3200 mm Cutting depth: 154 mm Scoring unit: yes Saw blade height adjustment: electric / position control Saw blade tilt adjustment: electric / position control Rip fence adjustment: electric / position control Cross-cut fence adjustment: manual Saw blade angle display: digital readout Cutting height display: digital readout Rip fence display: digital readout Cross-cut ruler display: digital readout Cross-cut ruler with mitre function: yes Saw blade diameter: 450 mm Speeds: variable Motor power: 5.5 kW Extraction port: 80 and 120 mm Machine length: 3200 mm Machine width: 2200 mm Weight: 1200 kg

Condition: used, Year of construction: 2006, Carriage length: 3400 mm Cutting width at rip fence: 1350 mm Cutting width at crosscut fence: 3200 mm Cutting depth: 170 mm Scoring unit: yes Saw blade height adjustment: electric Saw blade tilting adjustment: electric Rip fence adjustment: manual Crosscut fence adjustment: manual Saw blade angle display: digital readout Cutting height display: digital readout Rip fence display: digital readout Hjdpfsyhgitex Afcoi Crosscut fence scale: analog scale Saw blade diameter: 500 mm Number of speeds: 4 Motor power: 5.5 kW Extraction port: 80 and 120 mm Machine length: 3600 mm Machine width: 2200 mm Weight: 1200 kg

Condition: new, ALTENDORF Model F45 Pro Drive Offer type: New machine, SALE ONLY IN AUSTRIA! Immediately available new machine with promotional price and full manufacturer warranty. Pro Drive control: Hsdpfxoiz Aufe Afcei 3,5" color screen with separate keyboard Automatic dimensional correction on the rip fence and angle fence when tilting the saw unit Simple calibration of the axes Machine diagnostics, operating hours counter, USB interface Recall of the last dimension input (back function) 99 storable cutting programs Grooving: with automatic step-by-step positioning of the rip fence 400V / 50Hz - Europe , Scale: scale in mm Electromotive height and tilt adjustment 0 - 46° for the main saw blade with automatic correction of the cutting height when the saw unit is tilted Machine height 910 mm (basic equipment) The control panel of the F 45 is mounted at eye level. This makes it easy to control all axes, and all settings are in view. The one-handed operation of the swing-away device is easily accessible from the working position in front of the machine. Another advantage: nothing stands in your way at the smooth machine front. INCL. OPTIONS: M62003 Template holder M64080 Extended cutting height with saw blade projection of max. 204 mm. M51101 One-sided tilting saw unit with 7.5 kW (10 HP) motor, M24030 2-axis scoring unit with electric motor-driven height and side adjustment M24037 LED lighting for the danger area of the scoring unit M41010 Table top extension 840 mm M34204 Double roller carriage, carriage length 3200 mm M44404 Angle miter fence, cutting to length up to 3500 m. M44443 CNC parallel fence, cutting width 1300 mm. M44450 Front support roller. M37003 On/off switch on the sliding table. Note used machines: - Errors in technical specifications and subject to prior sale. - Indicated prices are valid as pickup prices ex location - free loading! - The machines have been cleaned and functionally tested. - All machines are bought as seen without any claim to warranty. The buyer is free to inspect the machines at the site. - Special agreements are only possible in written form. (We answer inquiries only under indication of your address + telephone number!)
