304 stainless steel tank - 1,520 L

ARSILAC

Condition: used, functionality: fully functional, total height: 5,200 mm, pressure: 1 bar, tank capacity: 25,800 l, inner diameter: 2,900 mm, TECHNICAL SPECIFICATIONS - Flat-bottom tank on legs - Material: stainless steel - Capacity: 25,800 litres RING - 1 ladder support bar - 1 lifting tube - 1 support and level tap - 1 oval autoclave door - 1 partial drain valve on square flange Iedpfxoxz Da Ij Ahueht BOTTOM - Flat - 1 total drain valve on square flange - Feet DIMENSIONS - Diameter: 2,900 mm - Height: 5,200 mm

Condition: used, functionality: fully functional, total height: 4,400 mm, total width: 3,200 mm, overall weight: 2,500 kg, operating pressure: 1 bar, tank capacity: 24,700 l, inner diameter: 3,200 mm, TECHNICAL SPECIFICATIONS - Conical bottom tank on legs - Material: stainless steel - Capacity: 24,700 litres ROOF - 1 off-centre chimney with hatch BOTTOM - Conical - On legs DIMENSIONS Iodpfx Ahjxz A Tyouoht - Diameter: 3,200 mm - Height: 4,400 mm - Weight: 2,500 kg

Condition: used, functionality: fully functional, total height: 5,100 mm, total width: 2,800 mm, pressure: 1 bar, tank capacity: 19,800 l, inner diameter: 2,800 mm, TECHNICAL SPECIFICATIONS - Vertical cylindrical tank - Capacity: 9,400 l + 10,400 l = 19,800 litres - Material: stainless steel ROOF Iodpfx Ahexz A Htjueht - 1 off-centre chimney at the front with hatch RING - 1 complete level tube for each of the two compartments - 1 oval autoclave door for each of the two compartments - 1 tasting tap on each of the two compartments - 1 rectangular door on the upper compartment - 2 partial drain valves on each of the two compartments - 1 cooling circuit on each of the two compartments BOTTOM - Conical - 4 feet - 1 total drain valve DIMENSIONS - Diameter: 2800 mm - Overall height: 5100 mm

Condition: used, functionality: fully functional, total height: 5,000 mm, overpressure (max.): 1 bar, tank capacity: 20,000 l, warranty duration: 6 months, inner diameter: 3,000 mm, TECHNICAL SPECIFICATIONS - Cylindrical with self-draining skirt - Closed - Capacity: 200 HL - Material: STAINLESS STEEL - Bottom: sloped - Tank numbers: 8 and 9 ROOF - Central hatch Ø 500 mm RING - 1 tasting tap - 1 rectangular door 700×500 mm at the bottom of the ring - 1 50 Mâcon ball partial drain valve with cap - 1 complete level gauge - 1 lift tube BOTTOM - 1 total drain valve with 50 Mâcon ball and cap DIMENSIONS - Diameter: 3000 mm - Total height: 5000 mm APPENDICES - Tank for product density 1 - Conditions of use: atmospheric pressure Iedpsxvb Huofx Ahuoht - 6-month warranty - Complies with CE standards

Condition: used, tank capacity: 39,000 l, GENERAL INFORMATION Equipment: butterfly valve, crane lugs Design: vertical Remarks: All 3 chambers with separate manway & outlet (butterfly valve) External diameter: 3,000 mm Total height: 7,000 mm Ihodpfxoxqdb Rj Ahuot Base design: height-adjustable feet Location: outdoor storage Nameplate: Volume: 39,000 litres Product-contact material: V4A 1.4401/04 (AISI316) Condition: used Cylindrical height: 5,250 mm TANK Bottom: conical bottom Number of feet: 6 units EQUIPMENT Manway/Hatch: in cylinder Outlet: present Note: light residues

Condition: used, functionality: fully functional, total height: 4,000 mm, operating pressure: 1 bar, tank capacity: 10,500 l, warranty duration: 6 months, inner diameter: 2,100 mm, TECHNICAL SPECIFICATIONS - Cylindrical, closed, on legs - Capacity: 105 HL - Material: STAINLESS STEEL - Bottom: conical, on legs - Tank numbers: 23 and 22 ROOF - 1 off-centre chimney at the front Ø 400 mm RING - 1 ladder support bar - 1 level tube on ruler - 1 tasting tap - 1 rectangular door 500/400 mm at the bottom of the ring - 1 partial drain ball valve * Tank No. 23: Ø 50 MÂCON with plug * Tank No. 22: Ø 60 MÂCON with plug BOTTOM - 1 total drain ball valve * Tank No. 23: Ø 50 MÂCON with plug * Tank No. 22: Ø 60 MÂCON with cap - 5 stainless steel feet: height 470 mm DIMENSIONS - Diameter: 2100 mm - Total height: 4000 mm APPENDICES - Tank for product density 1 - Conditions of use: atmospheric pressure Ihedjw Uqzmopfx Ahust - 6-month warranty - Complies with CE standards

Condition: used, functionality: fully functional, total height: 4,700 mm, tank capacity: 10,000 l, inner diameter: 2,500 mm, TECHNICAL SPECIFICATIONS - Cylindrical with legs - Floating head - Capacity: 100 HL - Material: stainless steel - Bottom: conical with legs - Top: floating head - Tank numbers: 27 and 28 ROOF - 1 stainless steel floating head Iedpfx Ahew Uqz Hjueht RING - 1 ladder support bar - 1 gallows - 1 tasting tap - 1 rectangular door 430×540 mm at the bottom of the ring - 1 MÂCON 50 ball valve for partial drainage - 1 complete level with tap and ruler (polycarbonate tube) BOTTOM - 1 MÂCON 50 ball valve for total drainage - 4 stainless steel legs 700 mm DIMENSIONS - Diameter: 2500 mm - Collar height: 3060 mm - Total height: 4700 mm APPENDICES - Tank for product density 1 - Conditions of use: atmospheric pressure - 6-month warranty - Complies with CE standards

Condition: new, functionality: fully functional, total height: 2,300 mm, overall weight: 145 kg, tank capacity: 1,789 l, inner diameter: 1,200 mm, TECHNICAL SPECIFICATIONS - Brand: ARSILAC - Model: STOBP1700 - Material: 316L stainless steel - Total capacity: 1789 litres - Base: curved on legs - Roof: centred conical - Interior finish: bright annealed - Exterior finish: brushed ROOF - Off-centre upper hatch with lever, diameter 200 mm - 1 DN40 MÂCON connection on hatch chimney with cap - Empty lifting rings RING - 1 ladder support - 1 round door, diameter 400 mm, at the bottom of the ring, opening outwards - 1 partial drain with square flange 100x100, stainless steel ball valve 40 MÂCON and stainless steel plug and decanter elbow - 1 tasting tap on DIN 15 connection - 1 needle thermometer - 1 complete stainless steel level gauge with tap and stainless steel ruler (polycarbonate tube) - 1 honeycomb belt with 1.8 m² exchange surface - Circuit operating pressure 3 bar, test pressure 10 bar - 1 inlet and 1 outlet on the honeycomb circuit, 3/4" male GAS connection Iedpow Tly Usfx Ahusht - 1 connection with protective sleeve for control probe - 1 identification plate BOTTOM - 1 total drain with 100x100 square flange, 40 MÂCON stainless steel ball valve and stainless steel plug - 3 stainless steel feet, height 400 mm, adjustment screws and base plate DIMENSIONS - Diameter: 1200 mm - Ferrule height: 1500 mm - Total height: 2300 mm - Weight: 145 kg - Roof thickness: 12/10 mm - Ferrule thickness: 15/10 mm - Curved base thickness: 15/10 mm

Condition: new, functionality: fully functional, total height: 3,050 mm, overall weight: 168 kg, tank capacity: 2,623 l, inner diameter: 1,200 mm, TECHNICAL SPECIFICATIONS - Brand: ARSILAC - Model: STOBP2500 - Material: 316L stainless steel - Total capacity: 2623 litres - Base: curved on legs - Roof: centred conical - Interior finish: bright annealed - Exterior finish: brushed ROOF - Off-centre upper hatch with lever, diameter 200 mm - 1 DN40 MÂCON connection on hatch chimney with cap - Vacuum lifting rings RING - 1 ladder support - 1 round door, diameter 400 mm, at the bottom of the ring, opening outwards - 1 partial drain with square flange 100x100, stainless steel ball valve 40 MÂCON and stainless steel plug and decanter elbow - 1 tasting tap on DIN 15 connection Ijdew Tlw Tepfx Ahueht - 1 needle thermometer - 1 complete stainless steel level gauge with tap and stainless steel ruler (polycarbonate tube) - 1 honeycomb belt with 1.8 m² exchange surface on top of the ring - 1 honeycomb belt with 1.2 m² exchange surface around the door - circuit operating pressure 3 bar, test pressure 10 bar - 1 inlet and 1 outlet on the honeycomb circuit, 3/4" male GAS connection - 1 connection with thermowell for control probe - 1 identification plate BOTTOM - 1 total drain with 100x100 square flange, 40 MÂCON stainless steel ball valve and stainless steel plug - 3 stainless steel feet, height 400 mm, adjustment screws and plate DIMENSIONS - Diameter: 1200 mm - Shell height: 2250 mm - Total height: 3050 mm - Weight: 168 kg - Roof thickness: 12/10 mm - Collar thickness: 15/10 mm - Curved base thickness: 15/10 mm

Condition: new, functionality: fully functional, total height: 3,500 mm, overall weight: 400 kg, tank capacity: 5,205 l, inner diameter: 1,600 mm, TECHNICAL SPECIFICATIONS - Brand: ARSILAC - Model: STOIPSER5300 - Material: 304 stainless steel - Total capacity: 5,205 litres - Base: flat sloped, 4% slope - Roof: centred conical - Interior finish: bright annealed - Exterior finish: brushed Isdpow Tlu Esfx Ahusht ROOF - 1 hatch, diameter 400 mm, with lever - 1 connection with PVC ball vent RING - Lifting rings - 1 ladder support - 1 rectangular door, 420×530 mm, at the bottom of the ring, opening outwards - 1 partial drain with 100×100 square flange, 40 MÂCON stainless steel ball valve and stainless steel plug - 1 tasting tap on DIN 15 connection - 1 needle thermometer - 1 complete stainless steel level gauge with tap and stainless steel ruler (polycarbonate tube) - 4 coil turns with 2.15 m² exchange surface on the shell - 2 coil turns with 0.75 m² exchange surface around the door - Maximum pressure on coil circuit: 1.5 bar - 1 inlet and 1 outlet on the coil circuit, 1‘ 1/4’ male GAS connection - 1 connection with thermowell for control probe - 1 identification plate BOTTOM - 1 total drain with 100×100 square flange, 40 MÂCON stainless steel ball valve and stainless steel plug - 3 stainless steel feet, height 500 mm, adjustment screws and base plate DIMENSIONS - Diameter: 1600 mm - Shell height: 2500 mm - Total height: 3500 mm - Weight: 400 kg - Roof thickness: 15/10ᵉ mm - Shell thickness: 15/10ᵉ mm - Bottom thickness: 20/10ᵉ mm
