Screw compressor

Atlas Copco GA50VSD

Year of construction: 2007, condition: ready for operation (used), Three Atlas Copco compressors are available. 1) Atlas Copco GA 37 VSD, year of manufacture: 2007, air flow rate: 7.25m³/min, max. operating pressure: 12.8bar, power: 37kW, refrigerant: R404a, weight: approx. 1200kg, operating hours: approx. 120844h. 2) Atlas Copco GA 50 VSD, year of manufacture: 2003, max. operating pressure: 13bar, air flow rate: 9.18m³/min, power: 50kW, refrigerant: R404a, weight: approx. 1300kg, operating hours: approx. 159308h. 3) Atlas Copco GA 30, year of manufacture: 2003, air flow rate: 5.34m³/h, max. operating pressure: 8bar, power: 30kW, refrigerant: R404a, weight: approx. 1000kg, operating hours: approx. 29700h. Documentation available. An on-site inspection is possible. Dcodpsyn Nzxsfx Afpef

Condition: ready for operation (used), Year of construction: 2020, operating hours: 8,950 h, functionality: fully functional, overall weight: 916 kg, total length: 1,200 mm, total width: 1,100 mm, total height: 2,000 mm, motor manufacturer: Atlas Copco, power: 55 kW (74.78 HP), fuel type: electric, volume flow: 650 m³/h, operating pressure: 13 bar, Equipment: documentation/manual, type plate available, Atlas Copco Screw Compressor Model: FA55VSD+ Year of manufacture: 2020 Operating hours: 8,950 h Motor rated power: 55 kW Pressure: 4.0 to 13.0 bar Volume flow: 182.5 l/s or 10.9 m³/min Voltage/Frequency: 400 V / 50 Hz Dimensions (L/W/H): approx. 1,200 / 1,100 / 2,000 mm Weight: 900 kg Dcodpfx Ajx Dfmzofpsf The compressor is in excellent working condition and has been regularly inspected and maintained. It is currently still powered and can be viewed in operation. An associated air dryer and compressed air tank can be purchased optionally (see further listings).

Condition: like new (used), GA (W) VSDs (Variable Speed Drive) are single-stage, oil-injected, electric motor-driven, stationary screw compressors. The cooling system is equipped with an air cooler and an oil cooler. GA VSD are air-cooled compressors; cooling air is provided by a fan. Main features: - Maximum air inlet temperature: 40°C. - Maximum cooling water outlet temperature: 50°C - Temperature of the air leaving the outlet valve approx.: 30°C Dsdpfowxwxzox Afpecf - Approximate oil capacity: 17.9 L

Condition: excellent (used), Year of construction: 2002, Screw compressor ATLAS COPCO GA50VSD machine after service with inverter Technical data: capacity: 9.18 m3/min; 50 KW motor,; 13 bar max pressure; year;2002 mileage;14276h 23500 net 28905 gross Compressor fully operational,ready to work,warranty Dedpfx Asrxtddsfpecf we provide service.

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, We offer Atlas Copco compressors TYPE GA 55 Pressure 10 bar Motor 55 kW Year 2000 Dedpswa Iz Aofx Afpocf Compressor with documentation We also have other compressors from Atlas Copco, Kaeser, and Mahle

Condition: excellent (used), Year of construction: 2002, Screw compressor ATLAS COPCO GA50VSDFF machine after service, with inverter and air dryer Technical data: capacity: 9.27 m3/min; 50 KW motor,; 12.8 bar max pressure; year;2002 mileage;15194h 24500 net 30135 gross Dcsdpfx Asrxtd Njfpof Compressor fully operational,ready to work,warranty we provide service.

Condition: good (used), Year of construction: 2007, overall weight: 1,400 kg, volume flow: 522 m³/h, pressure (max.): 12.8 bar, Equipment: refrigerant dryer, PROD. ATLASCOPCO TYPE GA45VSDFF YEAR 2007 CAPACITY (kW) 45 45kw OUTPUT (m3/min) 8.7 CIS (bar) 12.8 INVERTER yes BUILT-IN DRYER yes EXCHANGER no COOLED (AIR/WATER) air ON TANK no DOCUMENTS no Dcodevrg R Uopfx Afpsf CONNECTION 1 1/2 NEW/USED USED

Condition: used, Year of construction: 2009, MANUFACTURER: ATLASCOPCO MODEL: GA75 VSD SERIAL NUMBER: API656533 YEAR: 2009 Dcedpfx Ajxxm Atefpsf POWER (kW): 75 CAPACITY (m3/min): 14.68 PRESSURE (bar): 13

Condition: used, Year of construction: 2020, functionality: fully functional, machine/vehicle number: API629410, Technical characteristics: Core Specifications Attribute Value Motor Power: 55 kW (75 hp) Maximum Working Pressure: 7.5 bar Free Air Delivery (FAD): approx. 174.4 l/s (approx. 369 CFM) Cooling Type: Air-cooled Noise Level: approx. 67 dB(A) Drive Type: Gear-driven Integrated Dryer: Yes (Full Feature “FF” version) Electrical Supply: 400V / 50Hz Regulation System: Full load / no load with Elektronikon® controller Dimensions (L×W×H): approx. 1656 × 1100 × 1968 mm Weight: approx. 1100 kg Design & Features: - Sound-attenuating enclosure: Steel canopy with flame-retardant insulation for quiet operation. - Elektronikon® Controller: 3.5” color display with programmable pressure bands, remote monitoring, and auto-restart capability. - Zero-loss condensate drain: Integrated into the dryer for efficient moisture removal without wasting compressed air. - Integrated moisture separator: Labyrinth-style, built into the aftercooler for enhanced air quality. - IP55-rated motor: Dust and water-resistant, suitable for industrial environments. Reliability & Maintenance: - Synthetic oil: Rated for 8,000-hour change intervals. - Spin-on oil filter: With integrated bypass valve for easy servicing. - ASME-approved air/oil separator: For long service life and minimal oil carryover. Djdpfx Afeyam Nqspscf Machine status: WORKING

Condition: excellent (used), Year of construction: 2010, ATLAS COPCO GA45VSDFF screw compressor, WATER-COOLED machine with inverter and dryer, after service Dedpfeyt Hzgex Afpocf Technical data: Capacity: 8.67 m³/min; motor power: 45 kW; Max. pressure: 12.75 bar; year: 2010 Hours: 9714 h!!! 33,500 EUR net 41,205 EUR gross The compressor is fully operational, ready for work, with warranty. Service provided.
