Coordinate measuring machine

Baty SM 20 E

Condition: new, Year of construction: 2024, functionality: fully functional, Baty SM300 profile projector - Compact and precise optical inspection The Baty SM300 profile projector is a versatile and precise projector designed specifically for demanding quality control on the shop floor or production floor. With a vertical light path and a 300 mm screen, it is ideal for inspecting small and medium-sized workpieces. The SM300 offers a high resolution of 0.5 microns and a measuring range of 150 mm x 50 mm, enabling detailed and precise measurement of components. The device is available with different magnification lenses, including 10x, 20x, 50x and 100x, to meet the specific requirements of your inspection tasks. The GMR display, which enables full geometric functionality, is available as a display option on this profile projector. These features make the SM300 an ideal choice for quality control applications where precision and efficiency are critical. Features: 300 mm screen with finely ground glass for clear projections. Robust design suitable for use in harsh environments. Magnification options: 10x, 20x, 50x, 100x. Measuring range of 150 mm x 50 mm with a resolution of 0.5 micrometers. Integrated profile and surface illumination for sharp and precise images. Digital angle measurement and complete geometric measurement functions with the GMR display system. Dkedsuyh N Sopfx Akten The SM300 is particularly suitable for workshops where reliable and precise inspection is required. The robust design ensures a long service life and consistently high measuring accuracy, even under difficult conditions.

Condition: new, Year of construction: 2024, functionality: fully functional, Baty SM20 profile projector - compact performer for optical inspection The Baty SM20 offers a vertical light path and a 500 mm screen, making it ideal for the inspection of medium to large workpieces. The device offers a robust design and a generous measuring range of 250 mm x 125 mm, making it ideal for precise inspections on the production floor. XLS: A simple 2-axis digital display for X and Y measurements, ideal for basic applications. MX200: This model extends the functions to include geometric measurements, including the calculation of angles, radii and distances. It also enables the creation of tolerance reports. FT2: The most advanced version offers a touchscreen interface with Fusion 2D software. This version includes optical edge detection and full reporting, including SPC diagrams and DXF overlays. Dkodpfx Ajuyh N Ejktjn With a choice of magnification lenses (up to 100x) and advanced features such as digital angle adjustment and optional edge detection, the SM20 is ideal for a wide range of quality assurance and process monitoring applications. Users can also choose from a range of display options, from simple measurement functions to comprehensive reporting with the FT2-E variant.
