Cold Circular Saw

BERG & SCHMID VKS 315

Condition: new, saw blade diameter 315 mm capacity 90 degrees: round 108 mm capacity 90 degrees: square 93 mm 150 x 90 mm Working height 920 mm saw blade turning speeds 17+33 oder 33+66 U/min Nedsd Iin Ropfx Akusct total power requirement 1,5/1,8 kW weight of the machine ca. 0,36 t dimensions of the machine ca. 0,8x0,9x1,95 m SPECIAL PRICE!!! High-performance vertical circular saw VKS 315 HA (20154/20155) • miter left 60° + right 45° • Vice with double clamping arm (fixed 4 times) for low-burr cuts and lateral quick shift • Saw table with large rotating plate and particularly stable vice for optimal material tension • Robust prism guide of the saw head (dovetail guide adjustable) • Automatic cooling • Machine base with chip drawer • Metal handle for high clamping force • Spring package Semi-automatic function: 1. Saw starts 2. Clamp material 3. Rapid lowering to the beginning of the material or cut the same for series cutting 4. Saw band off 5. Raise the frame to just above the material 6. Open the vise ATTENTION: Price is without saw blade!!! (saw blade price EUR 109)

Year of construction: 1997, condition: excellent (used), A used very good condition cold circular saw from EISELE equipped with 370mm circular saw blade, infinitely variable hydro-pneumatic feed, pneumatic material clamping, coolant device and documentation. Speed: 17/ 34 rpm Cutting range: Round 90°/ 45° r. l./ 30° r. 130/ 130/ 105mm. Nodjkfp D Topfx Akujct square 90°/ 45° r. l./ 30° r. 120x120/ 100x100/ 90x90mm rectangle 90°/ 45° r. li/ 30° r. 200x100/ 140x100/ 100/100mm Pneumatic connection 7 bar working height 900mm Machine dimensions WxDxH 865x1332x2175mm Weight 460kg Further tech. Data see pdf. document Tech. Data and dimensions: Errors excepted

Condition: new, saw blade diameter 315 mm capacity 90 degrees: round 108 mm capacity 90 degrees: square 93 mm 150 x 90 mm Working height 920 mm Ncedpfxed Iin Ss Akust saw blade turning speeds 17+33 oder 33+66 U/min total power requirement 1,5/1,8 kW weight of the machine ca. 0,328 t dimensions of the machine ca. 0,8x0,9x1,7 m ACTION PRICE!!! High-performance vertical circular saw VKS 315 (Article 20150) • miter left 60° + right 45° • Vice with double clamping arm (fixed 4 times) for low-burr cuts and lateral quick shift • Saw table with large rotating plate and particularly stable vice for optimal material tension • Robust prism guide of the saw head (dovetail guide adjustable) • Automatic cooling • Machine base with chip drawer • Metal handle for high clamping force ATTENTION: Price is without saw blade!!! (saw blade price EUR 109)

Condition: new, Year of construction: 2024, saw blade diameter: 315 mm, cutting height (max.): 150 mm, cutting range round steel at 45°: 108 mm, cutting range round steel at 90°: 108 mm, rotational speed (min.): 17 rpm, rotational speed (max.): 33 rpm, BERG+SCHMID vertical circular saw model VKS 315 Speed: 17+33 rpm - Miter left 60° + right 45° - Clamping vice with double clamping arm (4-fold fixed) for low-burr cuts and quick lateral movement - Saw table with large turntable and particularly stable vice for optimum material clamping - Robust prismatic guide of the saw head (adjustable dovetail guide) - Automatic cooling system - Machine base frame with chip drawer - Metal handle for high clamping force - Counter holder with spring assembly a. Saw blade dimensions: 315x40mm Nsdpfsrrvn Aox Akuect Further accessories such as saw blades, roller conveyors, measuring stops, minimum quantity lubrication etc. available on request! Delivery time: ex stock Waiblingen Beinstein

Condition: used, Year of construction: 1979, cutting diameter 440 mm Ncodpfxof Dwa Ue Akuot weight of the machine ca. 780 kg +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: new, metric thread diameter (min.): 3 mm, metric thread diameter (max.): 24 mm, Model RE16 to M16, model RE24 to M24 - ball bearing mounted wear-free parallel arm with radii of 1270 or 1800mm - Connection 230V / 1Ph - Infinitely variable speed adjustment - Digital speed display - digital depth control with memory for 5 programs - quick-change holder according to DIN standard Options: Micro spray system for model 1800 Cast iron table Wheels for cast iron table Nsdporb Akmofx Akujct Multifunctional head for cutting at any angle

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, SEMI-AUTOMATIC CIRCULAR SAW MEP TIGER 352 SX EVO Nodjxdr Rtspfx Akujct - Blade rotation at 4 speeds (15/30/45/90 rpm) - Rotating table mounted on central spindle and axial bearing - Cutting head feed on double linear guideway - Mechanical stops at -45°, 0°, +45°, and +60° with locking device at any angle - User interface with display

Condition: used, Year of construction: 1984, functionality: fully functional, machine/vehicle number: 0278, Mitre cold circular saw EISELE type VMS-III-S-HYD Type No. 430 Machine. No. 0278 Year of construction 1984 Sawing range at 90°: (round) Ø 120 mm Sawing area at 90°: (flat) 150 x 110 mm Sawing range at 45°: (round) Ø 100 mm Sawing range at 45°: (flat) 120 x 100 mm Saw blade diameter: 350 mm Saw blade speed: 8, 16, 33, 66 rpm. (2 gear stages + 2 motor speeds) Mitre cut 45° to the left, 90° and up to 30°(60°) to the right, infinitely variable Motor power: 2 and 2.6 kW Mains connection: 380 Volt, 50 Hz Features: - Semi-automatic vertical cold circular saw - Hydraulic material quick clamping device Nodot A Arljpfx Akuoct - Infinitely adjustable hydraulic saw blade feed - Convenient miter adjustment with fixed stops - Saw carriage on very stable rectangular guide - Convenient and stepless stroke adjustment of the saw unit via clamping lever - Generously dimensioned gearbox - with Eisele rotation compensation for long saw blade service life - Simple saw blade change - High productivity with minimum space requirement (less than 1 m²) - Coolant system in the machine base - Central lubrication (manually operated) Space requirement: 1100 x 710 x 1900 mm (L x W x H) Weight 490 kg The machine can be tested / demonstrated under power on site. All information without guarantee. Subject to prior sale. The object of purchase is sold under exclusion of any warranty. The exclusion does not apply to claims for damages arising from grossly negligent or intentional breach of obligations by the seller or for any injury to life, limb or health.

Condition: new, saw blade diameter 370 mm capacity 90 degrees: round 120 mm capacity 90 degrees: square 100 mm 180x100 mm Working height 925 mm saw blade turning speeds 15 - 70 U/min total power requirement 1,8/2,2 kW weight of the machine ca. 0,4 t dimensions of the machine ca. 0,8 x 1,0 x 1,85 m SPECIAL PRICE!!! High-performance vertical circular saw VKS 370 (20177/201178) · miter left 60° + right 45° · Vice with double clamping arm · Robust prism guide of the saw head, adjustable dovetail guide. · Chip brush · Automatic cooling · Metal handle for high clamping force · Solid, strong cast iron table · Spring pack · Chip removal brush ATTENTION: Price is without saw blade!!! (saw blade price EUR 204) Ncedpfx Akot Eafnjuot

Condition: used, Hydropneumatic operation Max. punching height: 90 mm Abutment stroke: 100 mm Njdpfxjw Inudo Akusct Punching stroke: 20 mm Pressing force: 30 kN Max. profile height: 100 mm Weight: approx. 280 kg
