Drill grinding machine

BERGER technologie EPG1 / easy point grinder

Condition: new, Year of construction: 2025, machine/vehicle number: 2024, Optical precision drill grinding High-precision and very easy-drill grinding with optics and , Costsaver and Swiss in 100% quality. grind drills, thinning and check in the shortest time and with maximum precision. With MEGA POINT blue line you win more than once, achieve with it: - Better positioning - Improved accuracy of diameter - Significantly longer service life - Feed force is greatly reduced The MEGA POINT blue line is a versatile precision drill grinding machine, which is easy and ergonomic operation and a variety of drills handelsueblichen nachschleift perfect and optimized. MEGA POINT blue-line 1-20mm (Optiom to 30mm) Technical specifications: Our MEGA POINT drill grinding allows precise and rapid regrinding and thinning all handelsueblichen drills. Our customers have so always perfectly ground drills for disposal. The sophisticated design provides enormous flexibility in terms of the different cut angles and the thinning of the drill. Without a doubt, the world's best conventional drill grinding! Technical specifications Drill material grinding HSS and carbide HSCO Point angle adjustable 80 ° - 150 ° optional tip angle adjustable up to 180 ° Chuck with collets for drill diameters from 1 to 6.5 mm Dcslhce R R R Sjdw Isi Chuck with collets for drill diameter 7 - 20 mm optional Spannzangenset for drill diameter 20 - 30 mm Average / free angle adjustable 0 - 40 ° Ausspitzvorrichtung, Ausspitztiefe adjustable CBN grinding wheel double-fine / coarse D 125 mm optional DIAMOND grinding wheel (for carbide drills) D 125 mm CBN grinding wheel for thinning D 50 mm x 4 mm Engine power 0.3 kW Spindle speed 2800 r / min Power supply 230 volt 50 Hz Dimensions (L x W x H) 50 x 50 x 50 cm Weight about 42 kg Standardausfuehrung For right- and left-cutting, two- and dreilippige drills. With built-in optics (10x Zoom) separate Ausspitzvorrichtung and: 1 Machine light 2 chucks with collets D 1 -6.5 mm and D 7 - 20 mm 1 CBNDoppel grinding wheel D 125 mm fine / coarse 1 CBNSchleifscheibe D 50 x 4 mm 1 Set of service tools 1 instruction manual with spare parts list 1 CD-ROM with manual (CE Declaration) Danger: OPTIMA / TATAR Parts BERGER technology will take over on January 1, 2016, the stock of spare parts of HighTech OPTIMA AG. We can now offer genuine spare parts and service for the OPTIMA and TARTAR Boherschleifmaschinen.

Condition: new, Year of construction: 2025, operating hours: 1 h, Standard equipment red line Delhcobrpr Uodw Ioci Optical precisions drill point grinding machine for 2 fluted drills regrinding and point splitting in one chucking diameter range 2 to 16 mm (1 to 20 mm as option) point angle 80° - 150° infinitely adjustable cutting angle 0° - 20° infinitely adjustable relief angle set to 30° incl. complete electrical instalation with single phase electrical motor 0,3KW 115V 60Hz (or 220V 50Hz) and integrated power-supply for illumination of the optical system incl. built-in optical projection system with 10 power lens (zoom lens with 6 - 20 power as option) incl. integrated point splitting device incl. one precision collet holder and one set of double-tapered precision-collets of your choice (MP 16 for drill-dia. 3-16 mm, MP 6,5 for drill-dia. 1-6.5 mm or MP 20 for drill-dia. 6.5-20 mm) incl. 1 double sided grinding wheel dia. 125mm CBN (one side coarse [grit ~100] second side medium [grit ~200]) incl. wheel guard with connection system for vacum cleaner incl. 1 each of detailed operating manual with pictures, spare parts list, CD-Rom and CE-Declaration (on demand)
