Edge banding machine NEW

BIESSE JADE 240

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, Edge thickness: 0.4 to 8 mm Panel thickness: 10 - 60 mm Grinding unit Gluing system End trimming unit Trimming unit Corner rounding unit Edge scraper unit Iijdpsy Dkidefx Apcja Glue scraper unit Brush unit Control: Touch screen Available within 1 or 2 weeks

Condition: excellent (used), SINGLE SIDE EDGE BANDER (Left) Edges (band in rolls) thickness (Min/Max) mm 0,4 / 3 Edges thickness in strips / lippings (min/max) mm 0,4 / 8 (12)* Panels thickness (min/max) mm 8 / 60 Numerical Control "StarTouch" + "Touch 7" Feeding speed m/min 12-18 Top pressure system with rubber belt (C.N.) Spraying unit (Anti-sticking liquid) AAR In-feed fence, adjustable by N.C. "EASY SIZE PLUS" Pre-milling Unit (vertical joint trimmers) 2 x Kw Lamps to heat the workpieces side Glueing Unit (P.U.R. Glue + Quick Melt system) "VC/800" - "VC/6" + "AirFusion AF15" Band Pressure zone (N.C. adjustment) Edge coils supporting unit - 1 Snipping (end-cutting) K/SEL Rough Trimming unit RS/K Fine Trimming unit RI / 800 (3 pos.) Multi Function Unit (Profile contour Trimming Unit) “4 EDGE” KIT Spraying Unit (for sliding liquid) Profile edge scraping unit RAS/1000 Glue scraper RCA / 2C Iiedpoxlqntofx Apcea Milling grooving unit K-100 (1 x Kw 1,8) 90° Hot Air Heater (to reactivate the color of plastic tape) Panels Return System "SAG" Mod. SPINNER 47 / 63

Condition: as good as new (ex-display), Year of construction: 2021, functionality: fully functional, input voltage: 400 V, input current: 24 A, input frequency: 50 Hz, type of input current: three-phase, overall weight: 915 kg, Worktable dimensions 3465x710mm, height 875mm Gluing thickness roller edges 0.4 - 3mm Glue-on thickness strip edges up to 5mm, min - max. workpiece thickness 8-50mm min. Workpiece length/width with roller edges 190/110mm min. Length of panel 120mm Feed speed 9 m/min Ijdpfx Apouacqzjceia Feed motor 0.55 kW Working air pressure of pneumatics 6.5 bar Suction hood glue container 80mm 2 suction hoods Flush trimming unit 60mm 2 extraction hoods Pre-milling unit 80mm Working temperature 20-190C° Equipment: Pre-milling unit (jointing) Rounding unit (corner copying) Gluing unit, applying and pressing on the edge (self-lubricating glue pot) Trimming unit, for cutting off 90° of the protruding edge at the front and rear Flush trimming unit (joining) Scraper unit Buffing unit Surface scraper Automatic application of the strip edges with edge magazine Kit for quick change of the glue container Device for heating the panel edge Non-stick agent spraying unit Spraying unit for finishing the edge

Condition: used, Year of construction: 2009, Used SCM edgebander model OLIMPIC K1000 Control panel with membrane keyboard Technical data: Min. panel height: 8 mm Max. panel height: 55 mm Min. edge thickness (roll): 0.4 mm Max. edge thickness (roll): 3 mm Max. edge thickness (solid wood): 12 mm Configuration: Strip edge magazine Glue pot capacity 1.5 kg, with independent motor No. 4 pressure rollers with pneumatic feed, first roller with independent motor Iiodpfx Aoxrndxjpcja Edge roll guillotine End trimming unit with 2 independent motors, tiltable 0-15° - each 0.35 KW - 12,000 rpm Overlapping trimming unit with 2 motors, each 0.65 KW - 12,000 rpm - tools with reversible knives Tiltable corner rounding unit for flat/radius finishing; 2 motors each 0.5 KW - 12,000 rpm, electro-pneumatic positioning - tools with reversible knives Electro-pneumatic exclusion of the unit Glue scraper unit Machine length: 4,310 mm Year of manufacture: 2009 CE marked

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2650x640x1400 mm Weight 700 kg Iodpfx Ajvz E T Hjpcsia Total power requirement 5 kw
