50 T2

Boy

Condition: excellent (used), Year of construction: 2014, Boy 100E / Hybrid machine Year of construction: 2014 Injection unit: Screw diameter: 32 mm Injection weight: 92.3 g Injection pressure: 2127 bar Dosing volume: 96.5 ccm Clamping unit: Clamping force: 100 t Distance between tie bars: 430x360 mm Size of the clamping platens: 750x650 mm Ejector: hydraulic Clamping unit: hydraulic Control system: Procan Alpha 2 - touchscreen Additional equipment: Hybrid machine: high-speed, energy-saving and very quiet Euromap 67 Robot interface Control system with air valve Hardened spraying unit - Bimetal Main motor of the machine - Servo motor driven by inverter - Energy saving Dimensions: Weight: 3530 kg Length/width/height: 4.37x1.21x2.20 m Drive: Pump/motor: 15 kW Kjdpfx Afsylixfeveln Heating output: 7.7 kW Total output: 22.7 kW All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or participate in live technical tests at our company in Łódź. Price: On request

Condition: used, Year of construction: 1998, clamping force: 50 kN, displacement volume: 200 cm³, injection pressure: 2,587 bar, overall weight: 2,500 kg, load hours: 4,500 h, screw conveyor diameter: 18 mm, terms of delivery: FCA Pegnitz Kjdpfx Afswi Uzhjvjln delivery time: on request terms of payment: 100% prior to delivery

Condition: excellent (used), Year of construction: 2020, Boy XS / Excellent technical condition Year of manufacture: 2020 Injection Unit: Screw diameter: 12 mm Shot weight: 4.1 g Injection pressure: 3128 bar Metering volume: 4.5 ccm Clamping Unit: Clamping force: 10 t Tie bar spacing: 160 mm Platen size: 321x246 mm Ejector: hydraulic Clamping unit: hydraulic Control system: Procan Alpha 4 - Touchscreen Additional equipment: Machine like new Euromap 67 Robot interface Air valve x 6 Automatic Wittmann material loader with Farratech brand dryer Dimensions: Weight: 450 kg Length/Width/Height: 1.48x0.52x1.38 m All offered machines are started up by our service technicians before sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our facility in Łódź. Kljdpoylillofx Afvon Price: On request

Condition: excellent (used), Year of construction: 2017, Boy 55A Pro / Operating hours: 17,083 in automatic mode / Machine in very good technical condition. Year of manufacture: 2017 Injection unit: Screw diameter: 38 mm Injection weight: 123.9 g Injection pressure: 1508 bar Metering volume: 136.1 ccm Clamping unit: Clamping force: 55 t tie bar distance: 360x335 mm size of clamping platens: 665x600 mm ejector: hydraulic clamping unit: hydraulic Control system: Procan Alpha - touch screen Additional equipment: Machine in very good technical condition Operating hours: 17.083 in automatic mode Pneumatic core x 2 injection unit hardened - bimetal The machine has been regularly serviced by the authorized service boy in France Kodpfx Afoylik Ujvoln It is possible to change the screw diameter for fi 32 mm or 42 mm Dimensions: Weight: 2430 kg Length/width/height: 3.25x1.14x2.02 m Drive: Pumps/motor: 11 kW Heating power: 7,7 kW Total power: 18,7 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: reconditioned (used), clamping force: 500 kN, screw diameter: 38 mm, injection pressure: 1,341 bar, Awaiting refurbishment at our headquarters in Northamptonshire is this BOY 50M injection moulding machine. Any machines awaiting refurbishment with us can be reserved with a 10% deposit and we then prioritise the refurbishment and aim to have the machine available for inspection within 8 weeks from order. Refurbished machines from STV Machinery undergo a comprehensive test procedure during which every function of the machine is tested and if necessary repaired. A production run of at least 5000 fault free cycles prior to sign off ensures trouble free operation once delivered. Machines are ultra clean and cosmetically as good as we can get them. We guarantee our refurbs are delivered fault free and leak free. Kledpfjwfp Hksx Afven Prices shown are ex-works, but we can quickly provide DAP (Delivered at Place) Incoterm pricing on request. We can take out the hassle and additional costs of purchasing machinery within the UK and EU. Contact us with a potential delivery address and we’ll do the rest.

Condition: excellent (used), Year of construction: 2017, Boy 55A Pro / Operating hours: 16,624 in automatic mode / Machine in very good technical condition. Year of manufacture: 2017 Injection unit: Screw diameter: 38 mm Injection weight: 123.9 g Injection pressure: 1508 bar Metering volume: 136.1 ccm Clamping unit : clamping force: 55 t tie bar distance : 360x335 mm size of clamping platens: 665x600 mm Ejector: hydraulic clamping unit: hydraulic Control system: Procan Alpha - touch screen Additional equipment: Machine in very good technical condition Operating hours: 16.624 in automatic mode Pneumatic core x 2 injection unit hardened - bimetal The machine has been regularly serviced by the authorized service boy in France It is possible to change the screw diameter for fi 32 mm or 42 mm Dimensions: Weight: 2430 kg Length/width/height: 3.25x1.14x2.02 m Drive: Pumps/motor: 11 kW Heating power: 7,7 kW Total power: 18,7 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Klodpfx Afsylik Isvon Price: Upon request

Condition: excellent (used), Year of construction: 2016, Boy 55A Pro / Operating hours: 18,153 in automatic mode / Machine in very good technical condition. Year of manufacture: 2016 Injection unit: Screw diameter: 38 mm Injection weight: 123.9 g Injection pressure: 1508 bar Metering volume: 136.1 ccm Clamping unit: Clamping force: 55 t tie bar distance: 360x335 mm size of clamping platens: 665x600 mm ejector: hydraulic clamping unit: hydraulic Control system: Procan Alpha - touch screen Additional equipment: Machine in very good technical condition Operating hours: 18.153 in automatic mode Pneumatic core x 2 injection unit hardened - bimetal The machine has been regularly serviced by the authorized service boy in France It is possible to change the screw diameter for fi 32 mm or 42 mm Dimensions: Weight: 2430 kg Length/width/height: 3.25x1.14x2.02 m Kledoylikbjpfx Afvsn Drive: Pumps/motor: 11 kW Heating power: 7,7 kW Total power: 18,7 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: excellent (used), Year of construction: 1997, Boy 80 M Year of manufacture: 1997 Kledpfx Afoyliiqjvon Injection unit: Screw diameter: 36 mm Shot weight: 132 g Injection pressure: 2085 bar Dosage volume: 147.6 cm³ Clamping unit: Clamping force: 80 t Tie bar distance: 410 x 358 mm Platen size: 680 x 555 mm Ejector: hydraulic Clamping unit: toggle lever Control system: Procan CT Additional equipment: * Dimensions: Weight: 3200 kg Length/Width/Height: 4.14 x 1.21 x 2.07 m Drive: Pump/Motor: 15 kW Heating capacity: 10.4 kW Total power: 25.4 kW All machines offered are started up by our service technicians prior to sale. It is possible to receive a video of the technical tests performed on the selected machine or to participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2004, Boy 90 M Year of manufacture: 2004 Injection unit: Kedpfx Afeyliiksvjln Screw diameter: 42 mm Injection weight: 193 g Injection pressure: 1724 bar Metering volume: 214.7 ccm Clamping unit : clamping force: 90 t tie bar distance: 430x360 mm size of clamping platens: 635x610 mm ejector: hydraulic clamping unit: hydraulic Control: Procan - touch screen Additional equipment: Euromap 12 Robot interface Air valve x 1 Dimensions: Weight: 3100 kg Length/width/height: 4.37x1.21x2.20 m Drive: Pumps/motor: 15 kW Heating power: 11,3 kW Total power: 26,3 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: excellent (used), Year of construction: 2016, operating hours: 7,278 h, functionality: fully functional, clamping force: 550 kN, screw diameter: 32 mm, displacement volume: 96 cm³, injection pressure: 2,127 bar, Dr. Boy 55 A DUROPLAST (nur 7.278 h) Manufacture year: 2016 Operating hours: 7,278 Stunden Screw: 32 Duroplast mm Injection pressure: 2127 bar Stroke volume: 96 cm³ Clamping Force: 55 t Ksdjylac Iepfx Afvoln Tie bar distance: 360 x 335 mm Mould installation height min.: 250 mm Plate distance max.: 650 mm Dimensions: 3200 x 1200 x 2000 mm Eeight: 2430 kg Connected load: 11 kW THERMOSET Granule injection unit, Corepuller, Airvalve, Hotrunner 4x price: on request contact: Mr. Ralf Schulz

Condition: excellent (used), Year of construction: 2012, operating hours: 49,130 h, functionality: fully functional, clamping force: 900 kN, screw diameter: 42 mm, displacement volume: 214 cm³, injection pressure: 1,724 bar, ejector force: 20,400 N, ejector stroke: 130 mm, plate length: 610 mm, plate width: 635 mm, total length: 4,370 mm, total width: 1,210 mm, total height: 2,200 mm, overall weight: 3,730 kg, type of input current: three-phase, input frequency: 50 Hz, input voltage: 400 V, clear span: 725 mm, Equipment: documentation/manual, warehouse no.: 503452 manufacturer: BOY type: 90 E controller: Procan ALPHA year of construction: 2012 operation hours: 49130 h clamping force: 900 kN distance between tie-bars h x v: 430 x 360 mm size of mould plates h x v: 635 x 610 mm min. mould height: 250 mm max. open daylight: 725 mm opening stroke: 475 mm screw diameter: 42 mm swept volume: 214.7 ccm injection pressure: 1724 bar screw length: 20 l/d screw stroke: 155 mm screw speed: 280 min screw torque: 700 N plasticising rate: 136 g/s PS number of heating zones: 4 nozzle stroke: 250 mm equipment included screen text german core pulling hydraulically 1x machine without material hopper Kjdpeyknr Iefx Afvsln machine without water flow regulator Anti vibration mounts interface EUROMAP 67 interface USB measures of machine l x w x h: 4.37m x 1.21m x 2.2m total weight: 3730KG

Year of construction: 2005, condition: ready for operation (used), There are two BOY 55M available, both year of construction 2005. Clamping force: 550kN, screw diameter: 38mm, stroke volume: 196cm³, injection pressure: 2000bar, platen dimensions: 565mm/540mm, tie bar distance: 360mm/335mm. Workpiece height min./max.: 250mm/650mm, opening stroke: 400mm, max. platen distance: 1050mm, ejector stroke: 80mm, max. mold weight: 600kg. Dimensions X/Y/Z: approx. 3300mm/1200mm/2100mm, weight: approx. 2300kg, operating hours: 29664h, control: Procan MD. Robot interface Euromap 12 included. Kedpfx Aotyaypofveln
