Die-sinking electrical discharge machining

CHARMILLES Roboform 31 RTC

Condition: excellent (used), Sound insulating cabins. For Bruderer high speed automatic presses. Nlodoiw Icbopfx Agrsg On stock available cabins for machines: BSTA 25 BSTA 41 BSTA 50 BSTA 60 BSTA 80 Cabins sold refurbished, carefully disassembled and packed for transport. Painted in white and anthracite (or colors requested by customer). Cabin is equipped with all needed holes for easy use of a Bruderer press. Front and rear doors with inspection glass. Air ventilator for climate control on top cover. For more information don't hesitate to contact us. We have on stock Bruderer BSTA 25, BSTA 30, BSTA 50, BSTA 110, also Mabu and Schaal automatic punching machines.

Condition: used, Year of construction: 1995, functionality: unexamined, machine/vehicle number: XXX, We are going to sell 3 wire edm machines and 1starthole edm machine Nlodpetylpcefx Agrjg

Condition: used, TECHNICAL DETAILS - Travels on X/Y/Z axes : 400 x 300 x 350 [mm] - Rapid traverses rates (X/Y/Z) : 6 / 6 / 15 [m/min] - Min./max. distance between table and chuck : 170 / 520 [mm] - Max. part dimensions : 820 x 580 x 250 [mm] - Max. part weight : 800 [kg] - Max. electrode weight : 50 [kg] - C axis : 0 - 100 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 9.1 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 4.700 x 2.750 [mm] - Machine height : 2.680 [mm] - Machine weight : 3.830 [kg] - Number of working hours : 13659 [h] EQUIPMENT - CNC : AGIEVISION 5 - Workpiece loading / unloading robot - Spindle nose : EROWA Njdpfx Agswl Rh Njrjlg - Dielectric capacity : 600 [l]

Condition: new, Perfectly built to optimise grinding and accuracy efficiency. Auto cross with hydraulic longitudinal. Manual vertical axis. Table longitudinal travel by sensor and solenoid valve - continuous lubrication. Specification Perfect D4080AH Saddle type surface grinder Table size 400 x 800mm Max. Grinding surface 400 x 800mm Max. distance centre of spindle to table 500mm (Option: 650mm) Table speed 5 ~ 25m/min Table guideway V & Flat way Auto. Cross feed increment approx. 0.5mm ~ 20mm Rapid power cross feed approx. 1100mm/min (60Hz) 900mm/min (50Hz) Cross feed on hand wheel 1 rev 5mm 1 gra 0.02mm Rapid power head elevation 550mm/min (60Hz) 450mm/min (50Hz) Vertical feed with MPG 1 rev 2mm 1 gra 0.01mm Auto down feed (Option) 0.001mm ~ 0.999mm/time Wheel speed 60Hz/50Hz 1750rpm (60Hz) 1450rpm (50Hz) Wheel dimensions 406 x 50 x 127mm Spindle motor 5HP Hydraulic pump motor 2HP Auto. Cross feed motor 1/5HP Standard Equipment Grinding wheel and wheel flange Flange extractor Wheel balancing arbor and base Wheel dresser with diamond Levelling screws and plates Tool box and tools Working light Manual Nedpenzh Uijfx Agrolg AD5 Automatic downfeed control Magnetic chuck and demagnetiser Coolant system with paper filter

Condition: good (used), Year of construction: 1994, Ref. no.: 17540 Manufacturer: ARBURG Type: 270 C 500-100 RUNHOUR Only 100 Year of construction: 1994 Clamping unit Clamping force: 50 ton Opening stroke: 350 mm Distance between tie bars: 270 X 270 mm Mould height min.: 200 mm Platen size (h x v): 405 X405 mm Injection unit Screw diameter: 25 mm Injection volume: 67 cm³ Shot weight: 61 g Injection pressure: 2500 bar Measurements and weight Dimensions: 3,3 X 1,5 X 2,0 m Machine weight: 2400 kg Further information: Laboratory Machine with Exceptionally Low Operating Hours The offered ARBURG 270 C 500-100 was manufactured in 1994 and originates from the training and laboratory department of a university. The machine was not used in regular production and was mainly operated for educational and testing purposes. Nodpfoyiz U Tex Agrslg The control system shows only approximately 100 operating hours and just 867 machine cycles. The machine is equipped with a hydraulic drive system and the proven ARBURG Dialogica control unit. In addition, it features an integrated crane system to facilitate mould and component changes. The scope of supply also includes an unused spare screw with a diameter of 15 mm and a complete additional plasticizing unit, providing extra flexibility for different applications. Due to its exceptionally low usage, documented history, and valuable additional equipment, this machine represents a rare opportunity on the used machinery market.

Condition: used, Year of construction: 2008, functionality: fully functional, The Bruderer BSTA 500-110B is a 500 kN Swiss-built high-speed stamping press, fitted with a BSV 75T double servo feeder for precision two-track strip feeding. Capable of up to 750 strokes per minute with B2 touch-screen control. Including sound insulating cabin. Nominal force: 500 kN (50 tons) Year of manufacture: 2008 Stroke rate: 100–750 spm (variable) Adjustable stroke: 19 / 25 / 34 / 43 / 51 / 57 / 64 mm Ram height adjustment: 64 mm Press table area: 1080 x 650 mm Control: B2, IPC-based touch-screen press control, programmable memory for fast retooling BSV 75T DOUBLE SERVO FEEDER Type: tandem dual-feed servo unit, independently controlled tracks Max. strip width: 70 mm per track Max. material thickness: 2 mm Feed length: variable, freely programmable Feed angle: variable Pilot release angle: variable No clamping/gripper bars — strip held by driven feed rollers during stamping Nodpfx Agezh Nnwjrslg Designed for parallel advancing of two strips or feeding pre-profiled/pre-stamped strip

Condition: ready for operation (used), Year of construction: 2015, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, number of axes: 3, This 4-axis AgieCharmilles FORM 30 die-sinking EDM machine was manufactured in 2015. It features an X-axis travel of 600 mm, Y-axis travel of 400 mm, and Z-axis travel of 400 mm. If you are looking to get high-quality die-sinking capabilities, consider the AgieCharmilles FORM 30 machine we have for sale. Contact us for further details. Nledpfoy T R D Hsx Agrjg

Condition: refurbished (used), Year of construction: 2026, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 350 mm, workpiece weight (max.): 700 kg, total height: 2,530 mm, total width: 1,213 mm, total length: 2,326 mm, table width: 500 mm, table length: 575 mm, warranty duration: 12 months, With the genius 700, a new dimension of die-sinking EDM begins for you. High rapid traverse speeds and reduced non-productive times ensure the genius 700 processes your jobs exceptionally quickly. The ratio of table size to travel distance is unique in its class, enabling you to make optimal use of the table surface. Within its category, the machine offers by far the greatest dielectric fluid height above the table. Adjusting the dielectric with the infinitely adjustable tank is quick and simple. The machine features high rigidity thanks to preloaded roller guides. The C-axis moment of inertia is comparatively high at 0.6 kg/m². In addition, it is equipped with a high-precision measuring system. Even demanding EDM processes can be handled on the genius 700 efficiently and with maximum precision. On-the-fly filter changes prevent downtime, and the centralized lubrication unit shortens maintenance times. The genius 700 can be connected from two sides, offering flexible positioning. The height-adjustable control panel is ergonomically designed and allows for seated operation. Travel X – Y: 400 x 350 mm Travel Z: 350 mm Table size (L x W): 575 x 500 mm Distance, table – quill or chuck max./min.: 550/200 mm Dielectric fluid above table: 420 mm Dimensions (W x D x H): 1213 x 2326 x 2530 mm Total weight (without fluids): 3200 kg Workpiece weight: 700 kg Electrode weight with rotary: 15 kg Electrode weight without rotary: 50 kg with manual securing Resolution X – Y – Z: 0.001 mm (optionally 0.0001 mm) Resolution C: 0.001° Dielectric tank capacity: 330 liters Generator: IPMtec (integrated) Work current: 52 A total; optionally 100 A total (+ 48 A) Booster: 196 A total (+ 96 A) Extraction capacity: 200 m³/h (55 l/sec) Required cooling output: 2.5 kW Floor load: approx. 2.1 N/mm² Number of support feet: 3 Load per foot: 2 t Foot plate diameter: ø 110 mm Air flow rate: 10 l/min Required air pressure: min. 6 bar T-slots: Number / width / spacing: 4 slots / 10 mm / 3 x 100 mm Nsdpfx Ageyh Nfberslg Paper star filter: 1 piece Flushing unit: 1 pressure connection, 1 suction connection, 1 fine volumetric pressure connection Flushing flow regulator: infinitely adjustable Programming software: PROGmodEDM

Condition: reconditioned (used), Year of construction: 1999, operating hours: 25,984 h, machine/vehicle number: 125128, travel distance X-axis: 320 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 320 mm, workpiece weight (max.): 550 kg, total height: 2,790 mm, total width: 2,540 mm, total length: 1,910 mm, table width: 880 mm, type of input current: three-phase, table length: 560 mm, table height: 225 mm, workpiece length (max.): 880 mm, workpiece width (max.): 550 mm, workpiece height (max.): 225 mm, year of last overhaul: 2025, In very good condition: Refurbished Charmilles Roboform 2000+ completely refurbished with 16-fold RTC changer. Extensive maintenance according to dealer prescrition performed: all air-valves and tubing replaced, filters replaced, motors refurbished with new bearings and cleaned up, fans replaced, screen replaced. C-axis seals have been replaced and is accurately aligned again. This is a 64A machine. Software and documentation is provided, onsite installation including warranty can be discussed! Optionally floppy drives can be exchanged for USB drives. Tested and fully functional. Can be viewed and tested in working order. Immediately available! Nljdpfx Agjw Ad Idorog

Condition: used, Year of construction: 2007, operating hours: 128,688 h, functionality: fully functional, machine/vehicle number: 642672, 128,688 h active time (total time the machine was switched on) Nodpfx Ajym N Najgrjlg 21,821 h operating time (net time in which the machine was actively used)
